- Page 1 Part No. Z1-109-820, IA001704 Mar. 2011 OPERATION MANUAL High Voltage Digitalmeter 149-10A www.valuetronics.com...
- Page 2 • If you find any incorrectly arranged or missing pages in this manual, they will be replaced. If the manual gets lost or soiled, a new Operation Manual can be purchased. In either case, please contact your Kikusui agent, and provide the "Kikusui Part No." given on this page.
-
Page 3: Power Requirements Of This Product
• Use a fuse element having a shape, rating, and characteristics suitable for this product. The use of a fuse with a different rating or one that short circuits the fuse holder may result in fire, electric shock, or irreparable damage. 149-10A www.valuetronics.com... - Page 4 Brown (LIVE) Green/Yellow (GND) Green or Green/Yellow (GND) Plug for USA Plug for China Plug for Europe NEMA5-15 CEE7/7 GB1002 Provided by Kikusui distributor/agent Kikusui agents can provide you with suitable power cord. For further information, contact Kikusui distributor/agent. 149-10A www.valuetronics.com...
-
Page 5: Safety Precautions
Fuse • With products with a fuse holder on the exterior surface, the fuse can be replaced with a new one. When replacing a fuse, use the one which has appropriate shape, ratings, and specifications. 149-10A www.valuetronics.com... - Page 6 Also handle carefully when relocating tall products as they can fall over easily. • Be sure the operation manual be included when the product is relocated. 149-10A www.valuetronics.com...
- Page 7 , i t i s r e c o m m e n d e d t h a t p e r i o d i c maintenance, checking, cleaning, and calibration be performed. Service • Internal service is to be done by Kikusui service engineers. If the product must be adjusted or repaired, contact Kikusui distributor/agent. 149-10A...
-
Page 8: Safety Symbols
Describes technical terms used in this manual. Indicates action prohibited. Indicates general warning, caution, risk of danger. When this mark is indicated on the product, refer the relevant section of the Operation Manual. Indicates a grounding (earth) terminal. Indicates a chassis grounding terminal. 149-10A www.valuetronics.com... -
Page 9: Table Of Contents
3.1 Description of Front Panel 3.2 Description of Rear Panel 3.3 Description of Side Panel 3.4 Measuring Method Chapter 4 SPECIFICATIONS __________________ 15 Chapter 5 CALIBRATION _____________________ 16 5.1 Calibration of Digitalmeter Chapter 6 BLOCK DIAGRAM __________________ 17 149-10A www.valuetronics.com... -
Page 10: Chapter 1 General Description
Chapter 1 GENERAL DESCRIPTION Kikusui Model 149-10A High Voltage Digitalmeter measures AC and DC voltages of up to 10 kV, with a high accuracy. As the meter input impedance is as high as 1000MΩ, the meter is best suited for measurement of voltages of high source impedance circuits. -
Page 11: Chapter 2 Precautions
Immediately upon receipt of the device, inspect it for any damage which might have been sustained while in transportation. If any signs of damage are found, contact Kikusui distributor/agent. 2.2 Notes for Use 1. Be sure to connect securely between the meter and the measured voltage source with the supplied cord. - Page 12 A and B of the measured object are shorted through the earth-ground and the measured object is adversely affected. In order to prevent this, be sure to earth-ground securely the 149-10A and to identify correctly the high voltage and low voltage lines of the measured object (refer to 3.4.1 Measuring Procedure) and to...
-
Page 13: Chapter 3 Operation Method
For grounding the casing to the earth. Fuse: 0.5 A fuse 3.3 Description of Side Panel CALIBRATION (AC/DC): Semi-fixed resistors for calibration of AC and DC voltages, respectively. Do not touch these resistors except when calibrating the instrument. 149-10A www.valuetronics.com... -
Page 14: Measuring Method
2. Connect the AC power cord to an AC power line outlet of the correct voltage, and turn ON the POWER switch. To measure with highest accuracy, warm up the 149-10A for at least 15 minutes. 3. Securely connect the LOW terminal of the front panel to the low line of the measured voltage source using the cord (supplied). - Page 15 Measured object Earth ground Securely ground the low voltage side to a good earth ground. High voltage cable Fig. 3-3 Note: For the 149-10A Digitalmeter, grounding may be done via the protective grounding terminal on the rear panel. 149-10A www.valuetronics.com...
- Page 16 Eo < E ≤ 1.01 x Eo As above, when the source impedance is lower than 10MΩ, the error caused impedance-wise is less than 1%. Measurement can be done with an accuracy of this error plus meter accuracy. 149-10A www.valuetronics.com...
-
Page 17: Chapter 4 Specifications
0˚C to 35˚C (32˚C to 95 C), 80% RH and humidity: External dimensions : Overall Dimentions Maximum dimensions: Weight Approx. 3 kg (6.6 lbs) 1 set AC power cord High voltage test cords (TL05-TOS) Accessories HTL2.5DH Operation manual 149-10A www.valuetronics.com... -
Page 18: Chapter 5 Calibration
(b) Before calibration, warm up the 149-10A for at least 60 minutes. 3. Set the 149-10A in the DC mode, apply a calibration voltage of 10 kV DC to the input terminal of the 149-10A, and so adjust CALIBRATION (DC) semi-fixed resistor on the side panel of the 149-10A that it displays 10.000. -
Page 19: Chapter 6 Block Diagram
Chapter 6 BLOCK DIAGRAM 149-10A www.valuetronics.com...
