- Page 1 SAI 33-W3 Standalone indicator Contents Safety instructions Product description Installation Commissioning Setting up a radio link Service and maintenance Technical data Appendix User manual Issue A - 07/2024 This document has the order no. 50-820-19-1000-83903406-EN...
-
Page 2: Table Of Contents
Service and Maintenance ................22 Technical data ....................23 VERSION OVERVIEW Issue Date Description Editor 03/2023 Creation of the user manual Ben Abdelbari 2024-07-08 Layout corrections © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... - Page 3 About this manual & Co. KG. Keep this manual in a safe place and ensure that it is available to all users. The contents of this manual are subject to change. WIKA Mobile Control do not provide any guar- Liability disclaimer antee for this material, including the associated guarantee regarding marketability and suitability for certain intended purposes.
- Page 4 Instructions for avoiding the possibly damaging situation. NOTE Usage instructions and information, but no dangerous situation. HINT Supplementary comments and recommendations for the user. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
-
Page 5: Safety Instructions
The device shouldn’t be used in proximity of radar systems or transmitters(e.g. radio, TV, mobile telephone etc.) or close to power supply systems. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 6: Fcc Conformity Declaration
Never clean the device with a high pressure cleaner! Have damage to the foils repaired professionally without delay 1.1 FCC Conformity declaration © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 7: Product Description
2 Product description 2.1 General The APEX SAI 33-W3 is a standalone idicator for the wireless coupling of APEX HES-W3 wireless hoist limit switches and APEX WSS-W3 wireless anemometers. If a hoist limit condition is reported by the hoist limit switch, a relay contact opens during this time. -
Page 8: Product Features
TV, mo- bile telephone etc.) or close to power supply systems. 2.4 Scope of supply The scope of supply of the APEX SAI 33-W3 with accessories consists of the following parts: APEX SAI 33-W3 ... -
Page 9: View Of Device
Bypass button Holding the button will bypass the digital output and toggle the alarm © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 10: Dimensions
Product description Display active selection cursor 2.7 Dimensions © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 11: Installation
The APEX SAI 33-W3 must be mounted in a suitable place on a sufficient firm surface with the con- nections facing downwards. The device may be used indoor and outdoor and is to be mounted such that the display is visible and operating push buttons can be reached by the machine operator. -
Page 12: Wiring Of The Central Connector
NOTE The APEX SAI-33-W3 can also be equipped with an additional CAN interface. Please refer to your supplier for more information. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 13: Commissioning
APEX SAI 33-W3. 4.1 Switching the device on After wiring the APEX SAI 33-W3, the device switches itself on as soon as the supply voltage is ap- How is the device powered on? plied. -
Page 14: Configuring The System
The menu display consists of 1 page with the following options to select: Display Sensors System © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... -
Page 15: Display Configuration
A2B condition NOTE If the A2B condition or error occurs the DO output will switch from high to low. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... - Page 16 Wind limit: exceeded when limit is set and not exceeded no limit set meter per second Unit: miles per hour © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
- Page 17 This screen will show a chess pattern on the screen, pushing the enter button will change the pat- tern to the negative. This screen is meant for testing (optical) the OLED display. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
-
Page 18: Sensors
In this menu the unit used for the winds speed sensor can be selected: Miles per hour or meter per second. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... - Page 19 The brightness of the display can be adjusted using this menu. Select “Disp.Bright” and adjust the brightness using the up and down arrows. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
- Page 20 DO2 can be the combination of both conditions above (WSS+A2B) NOTE Pressing and holding the STOP button will bypass the both digital outputs. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
-
Page 21: Setting Up A Radio Link
LED. NOTE Start the pairing procedure on the receiver first in this case the APEX SAI 33-W3 and then initiate the pairing on the APEX sensor. After a successful pairing the APEX sensors will be measuring and communicating its state to the parent receiver. -
Page 22: Service And Maintenance
Service and Maintenance 6 Service and Maintenance The APEX SAI 33-W3 does not contain any serviceable parts. Both the actual switching element and the electronic components are sealed. If you notice malfunctions, you should switch the device off, and have it checked and, if necessary, repaired immediately by an authorized service partner of WIKA Mobile Control. -
Page 23: Technical Data
Distance between mounting 102,1 mm holes Operating temperature range -40°C..+70°C Storage temperature range -40°C..+85°C Protection class IP65 open field, direct line of sight © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk... - Page 24 Examples Structure Completeness Illustrations, photos Drawings, diagrams Tables Did you discover any errors in this manual? If so, on which page? © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
- Page 25 WIKA Mobile Control GmbH & Co. KG Technische Dokumentation Hertzstr. 32-34 76275 Ettlingen Germany Thank You ! © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
- Page 26 Notes © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 50-820-19-1000-83903406-EN.docx / 2024-07-08 / Issue A / YBA-rk...
