- Page 1 HES-W3/02 Wireless Contents hoist limit switch Safety instructions Product description Installation Commissioning Operation Service ans maintenance Technical data User manual Issue A - 07/2024 This document has the order no. 31-820-19-1003-83903454-EN...
-
Page 2: Table Of Contents
Replacing the batteries ................17 Technical data ....................20 VERSION OVERVIEW Issue Date Description Editor 07/2022 Creation of the user manual Ben Abdelbari 2024-07-15 Layout corrections © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... - Page 3 About this manual & Co. KG. Keep this manual in a safe place and ensure that it is available to all users. The contents of this manual are subject to change. WIKA Mobile Control do not provide any guar- Liability disclaimer antee for this material, including the associated guarantee regarding marketability and suitability for certain intended purposes.
- Page 4 Instructions for avoiding the possibly damaging situation. NOTE Usage instructions and information, but no dangerous situation. HINT Supplementary comments and recommendations for the user. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
-
Page 5: Safety Instructions
Never clean the device with a high pressure cleaner! Have damage to the foils repaired professionally without delay! IMPORTANT Check the function! © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... -
Page 6: Fcc Conformity Declaration
Safety instructions 1.1 FCC conformity declaration © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... -
Page 7: Product Description
2 Product description 2.1 General The APEX HES-W3/02 is a battery operated limit switch for the detection of the hoist limit condition, e.g. on the lifting rope of a crane. The wireless module with integrated battery compartment serves recognition and the wireless transmission of the hoist limit condition to suitable wireless receivers. -
Page 8: Use For The Intended Purpose
Product description 2.3 Use for the intended purpose The APEX HES-W3/02 is a wireless sensor and serves the detection and wireless transmission of the hoist limit condition. Typical area of application is the hoist limit detection for the hoisting gear on cranes. -
Page 9: View Of Device
Product description 2.6 View of Device Antenna Mounting plate Pairing button Link LED Battery compartment Action cable © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... -
Page 10: Dimensions
Product description 2.7 Dimensions (all dimensions in mm) Figure 2: Dimensions of the APEX HES-W3/02 © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... -
Page 11: Installation
Installation 3 Installation The APEX HES-W3/02 hoist limit switch is supplied complete with mounting accessories: hoist limit switch weight, antenna and a battery. Installation can therefore be performed simply and quickly. The hoist switch is intended to use on the point of the boom or alternatively on a boom extension. -
Page 12: Mounting The Apex Hes-W3
If the mounting place is not easy to access, you should only mount the wireless sensor after commissioning and establishment of the radio link! In order to mount the APEX HES-W3/02 it is pushed onto the mounting bolt and secured with a cot- ter pin: 3.3 Mounting the hoist switch weight... -
Page 13: Mounting The Antenna
Finally, check the free movement of the weight and the function of the hoist limit switch. 3.4 Mounting the antenna An angled antenna is included in the scope of supply of the APEX HES-W3/02. If not already mounted, screw the antenna hand-tight onto the antenna socket on the top of the de- vice. -
Page 14: Commissioning
The pairing mode is signalized by a yellow LED: Once a link is established the yellow LED will turn off, and the APEX HES-W3/02 will be sending its state to the parent receiver. -
Page 15: Operation
The APEX HES-W3/01 will go operational immediately after inserting the battery. In a default con- figuration the device is in energy saving mode unless it connects to its assigned active receiver. When a link is established between the APEX HES-W3/02 it will start updating its status. 5.1 Pairing button and LED Pressing the pairing button for 5s will start the pairing process. - Page 16 NOTE Constantly losing the link between the device and its receiver means, the position of the an- tenna is not suitable. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
-
Page 17: Service And Maintenance
Service and Maintenance 6 Service and Maintenance The APEX HES-W3/02 does not contain any serviceable parts. Both the actual switching element Service and the electronic components are sealed. If you notice malfunctions, you should switch the device off by removing the battery, and have it... - Page 18 (ensure proper orientation) IMPORTANT The positive pole of the battery must be oriented to the cover of the battery holder! © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
- Page 19 Check for proper operation prior to restarting machine operation by manually actuating the switch and observing the correct switch output on the receiver side. © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
-
Page 20: Technical Data
19Ah battery with a duty cycle of 33% and at 20°C default duration, can be configured (1s..15s) Open field, direct line of sight © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk... - Page 21 Examples Structure Completeness Illustrations, photos Drawings, diagrams Tables Did you discover any errors in this manual? If so, on which page? © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
- Page 22 WIKA Mobile Control GmbH & Co. KG Technische Dokumentation Hertzstr. 32-34 76275 Ettlingen Germany Thank You ! © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
- Page 23 Notes © 2024 WIKA Mobile Control GmbH & Co. KG · www.wika-mc.com 31-820-19-1003-83903454-EN.docx / 2024-07-15 / Issue A / YIBI-rk...
