- Page 1 Under Desk Keyboard Tray with Swinging Height Adjustment MOUNT-KB08S Assembly Manual Individual Product SKUs MOUNT-KB08S MOUNT-KB08SW...
- Page 2 If you do not understand these directions, or if you have any doubts about the safety of the installation, please contact our product support team at 309-278-5303 or help@vivo-us.com for further assistance. Check carefully to make sure there are no missing or defective parts. Failure to report missing parts within 30 days may result in denial of free replacement.
-
Page 3: Package Contents
Package Contents A (x1) B (x2) C (x2) D (x1) Keyboard Connecting Plate Height Adjustable Keyboard Tray Set Bracket Set STop Included Hardware & Tools S-A (x18) S-B (x8) T-A (x1) M5x12mm Screw M5x14mm Screw Mounting Template Weight Capacity: Tools Needed: 11lbs Phillips (5kg) -
Page 4: Assembly Steps
Assembly Steps STEP 1 Assemble Keyboard Tray Set (A) by placing Connecting Plates (B) into the insets on underneathside of Tray. Secure with M5x12mm Screws (S-A) and a Phillips screwdriver. STEP 2 Install Keyboard Stop (D) onto assembled Keyboard Tray (A) using M5x12mm Screws (S-A) and a Phillips screwdriver. - Page 5 STEP 3 Secure Height Adjustable Bracket Set (C) to the sides of Keyboard Tray (A) using M5x12mm Screws (S-A) and a Phillips screwdriver. STEP 4 Turn the tray over so that the topside is up. Unfold the Adjustable Brackets (C) by pressing down on the Levers and pulling the Top Bracket up.
- Page 6 STEP 5 Hold Mounting Template (T-A) to the underside of desk 0.5” (12mm) from the edge, and mark hole locations. Underside of Desk 0.5”(12mm) Pre-Drilling instructions: Drill mounting holes at marked locations using infographic below. Drill Bit: 1/8” (3mm) Hole Depth: 0.4”...
- Page 7 STEP 6 Add accessories to Tray. Adjustments Press and hold Levers simultaneously to swing the tray forward or back into position. Lever Hold Tray Evenly When Adjusting Make sure both sides of the Tray are level when adjusting the position. When in desired position, release both levers simultaneously for an even surface.
- Page 8 Need Help? We’re Here For You Monday-Friday from 7am-7pm CST Saturday 8am-4pm CST Email Us Chat with Live Agent Give Us a Call help@vivo-us.com www.vivo-us.com 309-278-5303 ext. 1 FOR MORE GREAT VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: WWW.VIVO-US.COM VIVO-us @vivo_us @VIVOus VIVO...
