SPECIFICATIONS
Part Numbers: 115955
Set Up Size: (L 109" x W 42" x H 70")
Packed Size: (L 56" x W 42" x H 30") with seats
W e i g h t: 89 lbs.
Fishable Area: 14 sq.ft.
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a three year manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked
windows, tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use. Defective
parts will be replaced or repaired (at the manufacturer's option) if found to be defective within three year from the
date of original purchase. Warranty will be void if product has been subject to neglect, misuse, improper
installation, misapplication, alteration, accident including but not limited to improper maintenance, or use of
unauthorized parts or attachments. Please read the entire owner's manual to ensure proper installation, use, storage
and care of your Clam Shelter.
.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description
of the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your
request, and a Clam representative will contact you regarding your claim status. All returns must be shipped to us
postage pre-prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty,
negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any
injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income,
profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or
replacement of Clam products. Clam reserves the right to make alterations or modifications in its products at
any time, which in its opinion, may improve the performance and efficiency of the product. Clam shall not be
obligated to make such alterations or modifications to products already in service.
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
CLAMOUTDOORS.COM
WARRANTY INFORMATION
LIMITATION OF LIABILITY
MODELS 15955

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X100 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Clam X100 Series

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any...
  • Page 2: Parts List

    PARTS LIST QTY. PART NO. DESCRIPTION 105039 BASE, X100 TRAP SHELTER 106504 TUBE, HOOP, X100 106611 HOOP POLE, LIGHT STICK 106655 TENT, X100 PRO THERMAL 102814 EXTRUSION, U-CHANNEL 101840 ASSY, REAR SPRDR POLE 106509 TUBE, SEAT RAIL SUPPORT, 38.03 102759 ASSY, DELUXE SEAT 106166 SEAT COVER, TRAP SHELTERS, BACK...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4: Required Tools

    REQUIRED TOOLS #2 AND #3 PHILLIPS HAND SCREW 3/8 AND 7/16 COMBINATION WRENCH OR SOCKETS #2 PHILLIPS SCREW BIT 3/16 AND 3/8 DRILL BIT POWER DRILL...
  • Page 5 *IT IS BEST TO USE THE AID OF ANOTHER PERSON DURING ASSEMBLY. STEP 1 Visit Clam’s website (www.clamoutdoors.com) and or our YouTube channel (ClamOutdoors) for shelter build how to videos INSTALL ANY RUNNER KIT OPTIONS BEFORE ASSEMBLING SHELTER. REFER TO RUNNER KIT INSTRUCTIONS 1.
  • Page 6 STEP 3 1. INSTALL BATTERY HOLDER ASSEMBLY WITH FASTENERS AS SHOWN CHOOSE WHICH LOCATION YOU PREFER TO HAVE BATTERY LOCATED. LIGHT POLE WIRE WILL NEED TO BE ABLE TO REACH BATTERY. 1. DRILL MARKINGS WITH 5/16” DRILL AND INSTALL WITH FASTENERS AS SHOWN.
  • Page 7 STEP 5 DO NOT CUT ANY OF YOUR POLES 1. ASSEMBLE LIGHT STICK, TO HALF POLES AS SHOWN STEP 6 1. LAY THREE HOOP POLES TOGETHER ON THE GROUND AND ASSEMBLY WITH FASTENERS AS SHOWN. LIGHT STICK POLES SHOULD MOVE EASILY, DO NOT OVERTIGHTEN DO NOT USE THIS HOLE...
  • Page 8 STEP 7 1. LAY ASSEMBLED HOOP POLES ON TOP OF BASE AND ATTACH BOTH SIDES AS SHOWN. CENTER POLE WILL HAVE TWO SPACERS LIGHT CONNECTION CORD SAME SIDE POLES SHOULD MOVE EASILY, DO NOT AS BATTERY BRACKET OVERTIGHTEN...
  • Page 9 STEP 8 LIGHT TUBE CABLE ASSEMBLY DIMMER SWITCH BATTERY CABLE CONNECTOR RED TO POSITIVE BATTERY TERMINAL ( + ) BLACK TO NEGATIVE BATTERY TERMINAL ( - ) DIMMER SWITCH CABLE 1. INSERT ROPE ENDS THRU HOLES IN FRONT OF BASE AND KNOT EACH END. LIGHT STICK (114271) WIRE TO BE POSITIONED TO SAME SIDE AS BATTERY HOLDER!!
  • Page 10 STEP 9 1. ROTATE THE SWIVEL PLATE SO THAT THE SLOTTED HOLE WILL ALIGN WITH HOLE IN SEAT ASSEMBLY IN A POSITION THAT WILL BE ACCESSIBLE AS SHOWN. 2. LOOSELY ASSEMBLE THE SEAT ASSEMBLY TO THE SWIVEL USING 4 SCREWS 3..
  • Page 11 STEP 10 1. DRAPE THE TENT, OVER THE HOOP POLES. ATTACH THE TENT TO THE POLES ON THE INSIDE WITH THE VELCRO STRAPS. 2. SLIDE THE REMAINING HOOP POLE THROUGH THE SLEEVE IN THE FRONT OF THE TENT. 3. ATTACH THE LAST HOOP POLE TO THE FRONT BRACKET AS SHOWN, DO NOT TIGHTEN MUST MOVE FREELY SLIDE HOOP THRU FRONT OF TENT SLEEVES.
  • Page 12 STEP 11 Visit Clam’s website (www.clamoutdoors.com) and or our YouTube channel (ClamOutdoors) for shelter build how to videos HEAT THE MOLDING (102814) WITH A BLOW DRYER, HEAT GUN OR SOAK IN HOT WATER MAKING IT PLIABLE 8” Approx. DETAIL-B THE FRONT HOOP POLE SHOULD...
  • Page 13: Tips For Use

    (NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base). ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit (PN 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 14: Frequently Asked Questions

    Q: What will help keep mice or rodents from eating the tent of my Clam or Fish Trap? A: We recommend that you keep your tent in a sealed plastic tote with laundry dryer sheets or moth balls. If the shelter is stored in a barn or shed take the tent off the house and store it in a rodent-free environment such as in your home.
  • Page 15 We do ship to Canada otherwise, we are only set up to ship warranty or replacement parts required to MAINTAIN a Clam shelter (tents, poles, parts, patch kits, etc.). No accessories – see a local dealer or an online dealer of Clam products.
