Clam Jason Mitchell 200XT PRO THERMAL Manual
Hide thumbs Also See for Jason Mitchell 200XT PRO THERMAL:

Advertisement

Quick Links

SPECIFICATIONS
Part Number: 116843
Set Up Size: L 113 x W 74 x H 82
Packed Size: L 74 x W 45 x H 27 folded seats
W e i g h t: 148 lbs.
Fishable Area: 34 sq.ft
Instructions: 106990
Please contact customer service directly at the E-mail or phone number listed below for any
quality issues. ONCE USED THIS PRODUCT CANNOT BE RETURNED TO STORE.
** Warranty cannot be honored without an original, dated receipt **
IMPORTANT-PLEASE READ:
This product is warranted to the original retail purchaser (from an authorized dealer) and is non-transferable.
Clam Outdoors has a three year manufacturer's defect warranty from the date of original purchase. Warranty
does not cover cracked or worn bases (if runner kits have not been installed as recommended), cracked
windows, tent tears or cuts, or broken or bent hoops due to high wind weather conditions or unattended use.
Defective parts will be replaced or repaired (at the manufacturer's option) if found to be defective within three
years from the date of original purchase. Warranty will be void if product has been subject to neglect, misuse,
improper installation, misapplication, alteration, accident including but not limited to improper maintenance, or
use of unauthorized parts or attachments. Please read the entire owner's manual to ensure proper installation,
use, storage and care of your Clam Shelter.
To submit a warranty claim request, please use one of the following methods:
https://clamoutdoors.com/pages/warranty-form
▪ Email:
customerservice@clamcorp.com
In your request, please include your full name, address, phone number, a copy of your receipt, a brief description
of the problem, and pictures to clearly show the area(s) of concern. Our Warranty Department will review your
request, and a Clam representative will contact you regarding your claim status. All returns must be shipped to
us postage pre-prepaid.
It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of
warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is
not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss
of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to
use, or the repair or replacement of Clam products. Clam reserves the right to make alterations or
modifications in its products at any time, which in its opinion, may improve the performance and efficiency of
the product. Clam shall not be obligated to make such alterations or modifications to products already in service
Clam contact information
Customer Service Hrs: 9am to 4pm, Monday – Friday Central Standard Time
Clam Outdoors
Attn: Customer Service
12135 Brockton Lane
Rogers, MN 55369
Phone: 763-231-4120
CLAMOUTDOORS.COM
WARRANTY INFORMATION
** REGISTER YOUR PURCHASE ONLINE AT CLAMOUTDOORS.COM **
LIMITATION OF LIABILITY
MODEL 16843

Advertisement

loading
Need help?

Need help?

Do you have a question about the Jason Mitchell 200XT PRO THERMAL and is the answer not in the manual?

Questions and answers

Summary of Contents for Clam Jason Mitchell 200XT PRO THERMAL

  • Page 1 It is expressly understood that Clam Outdoors Inc., liability for its products, whether due to breach of warranty, negligence, strict liability, or otherwise, is limited to the repair of the product as stated above. Clam is not liable for any injury, loss, damage, or expense, whether direct or consequential, including but not limited to loss of use, income, profit, or damage to material arising in connection with the sale, installation, use of, inability to use, or the repair or replacement of Clam products.
  • Page 2: Parts List

    EXTRUSION, V-CHANNEL 106918 KIT, SPRDR POLES, X200 XT 104899 TUBE, SEAT RAIL, X200 102759 ASSY, DELUXE SEAT 102841 CONSOLE, CLAM CENTER 108829 ASSY, BATTERY BRKT/HRDWR 115490 ASSY, 4-POST, ROD HOLDER 106166 SEAT COVER, TRAP SHELTERS, BACK 106167 SEAT COVER, TRAP SHELTERS, BOTTOM...
  • Page 3 HARDWARE FASTENERS REFERENCE...
  • Page 4 *IT IS BEST TO USE THE AID OF ANOTHER PERSON DURING ASSEMBLY. Visit Clam’s website (www.clamoutdoors.com) and or our YouTube channel (Clam Outdoors) for shelter build how to videos INSTALL ANY RUNNER KIT OPTIONS BEFORE ASSEMBLING SHELTER. REFER TO RUNNER KIT INSTRUCTIONS STEP-1 1.INSTALL BRACKETS TO BOTH SIDES WITH FASTENERS AS SHOWN AND SECURELY...
  • Page 5 STEP-2 1.INSTALL SEAT RAIL BRACKETS TO BOTH SIDES WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. 2 INSTALL SEAT RAIL SUPPORT TO BRACKETS WITH FASTENERS AS SHOWN. TO BOTH SIDES AND SECURELY TIGHTEN. INSTALL CAP AND ALIGN SLOT WITH BOLT HOLE IN TUBE.
  • Page 6 STEP-3 CHOOSE WHICH LOCATION YOU PREFER TO HAVE BATTERY LOCATED. LIGHT POLE WIRE WILL NEED TO BE ABLE TO REACH BATTERY. 1. INSTALL BATTERY BRACKET, ASSEMBLY (108829) AS SHOWN USING 5/16” DRILL BIT (REFER TO INSTALLATION MANUAL THAT IS INCLUDED WITH KIT) STEP-4 1.INSTALL, STRAIGHT AND BENT POLES TO BRACKETS TO BOTH SIDES WITH FASTENERS AS SHOWN AND SLIGHTLY TIGHTEN.
  • Page 7 STEP-5 DO NOT CUT ANY OF YOUR POLES 1. ASSEMBLE THE HALF HOOP TO LIGHT STICK AS SHOWN. 2. SLIDE HINGE CLIP INTO PLACE AND SNAP INTO THE TWO HOLES LOCATED IN HOOP POLE CLIP CLIPS TO BE USED ON LIGHT STICK HOOP ASSEMBLY ONLY.
  • Page 8 STEP-6 1. INSTALL TWO COLLARS TO EACH HOOP POLE AS SHOWN ALIGN COLLAR WITH THE HOLES IN HOOP AS SHOWN COLLAR TAB IS PLACED INSIDE OF TUBE...
  • Page 9 STEP-7 2. ATTACH THE EXTENSION POLES TO THE 1. SLIDE HOOP POLES OVER HINGE CLIP ASSEMBLY WITH FASTENERS TUBE EXTENSIONS AND LOCK INCLUDED WITH CLIP ASSEMBLY AS SHOWN. INTO PLACE WITH COLLARS. HINGED POLE MUST ROTATE FREELY ONCE TIGHTENED. COMPLETED HOOP POLE ASSEMBLY AT THIS POINT SHOULD MOVE FREELY AND LOOK LIKE THE FOLLOWING PICTURE.
  • Page 10 STEP-8 1. INSTALL ROD HOLDERS WITH FASTENERS AS SHOWN. CHOOSE A LOCATION YOU PREFER TO HAVE YOUR ROD HOLDER AND MARK HOLES ON BASE. 1. DRILL MARKINGS WITH 5/16” DRILL AND INSTALL WITH FASTENERS AS SHOWN.
  • Page 11 STEP-9 1. ROTATE SWIVEL AND ASSEMBLE SEAT COMPONENTS WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. ROTATE SWIVEL 45 DEGREES TO ASSEMBLY COMPONENTS 2. ASSEMBLE THE BLOCK WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. SAME BLOCK STYLE MUST BE ALIGNED TO EACH OTHER...
  • Page 12 3. ATTACH SWIVEL ASSEMBLY TO BOTTOM OF SEAT WITH FASTENERS AS SHOWN AND SECURELY TIGHTEN. 4. ASSEMBLE THE 20” SEAT RAIL TO FRONT BRACKET WITH COMPONETS, HAMMOCK AND FASTENERS AS SHOWN AND SECURELY TIGHTEN. THE FABRIC HAMMOCK IS PACKAGED WITH THE TENT...
  • Page 13 5. SLIDE THE SEAT RAIL THRU THE SEAT BLOCKS AS SHOWN WHILE LIFTING HAMMOCK OVER SEAT BLOCKS. 6. ASSEMBLE THE REAR BRACKET WITH COMPONETS AND FASTENERS AS SHOWN AND SECURELY TIGHTEN.
  • Page 14 STEP-10 USE LATCH TO SECURE SEAT ASSEMBLY STEP-11 1. DRAPE THE TENT OVER THE HOOP POLES. ATTACH THE TENT TO THE POLES ON THE INSIDE WITH THE VELCRO STRAPS. 2. SLIDE THE REMAINING HOOP POLE THROUGH THE SLEEVE IN THE FRONT OF THE TENT. 3.
  • Page 15 STEP-12 Visit Clam’s website (www.clamoutdoors.com) and or our YouTube channel (ClamOutdoors) for shelter build how to videos HEAT THE MOLDING (102814) WITH A BLOW DRYER, HEAT GUN OR SOAK IN HOT WATER MAKING IT PLIABLE DETAIL-B 8” Approx. BOTH SIDES...
  • Page 16 STEP-13 LIGHT TUBE CABLE ASSEMBLY DIMMER SWITCH BATTERY CABLE CONNECTOR RED TO POSITIVE BATTERY TERMINAL ( + ) BLACK TO NEGATIVE BATTERY TERMINAL ( - ) DIMMER SWITCH CABLE THERE IS AN APRON ATTACHED TO THE X200 TENT TO HELP REDUCE WIND INTRUSION.
  • Page 17: Tips For Use

    (NOTE: Pulling behind an ATV or snowmobile may result in premature wear of the base). ▪ In windy conditions it is advised to secure your shelter to the ice using Clam’s Ice Anchor Kit 108064) and Ice Anchor Installation Tool (PN 108348).
  • Page 18: Safety Instructions

    SAFETY INSTRUCTIONS Please fully understand and follow all safety instructions as outlined. Failure to do so could result in severe injury or death. ▪ DO NOT USE OPEN FLAME HEATERS IN YOUR ICE SHELTER. INJURY OR DEATH MAY RESULT FROM FIRE IF TENT FABRIC IS EXPOSED TO OPEN FLAME. THE TENT IS NOT FIREPROOF, BUT THE FABRIC IS TREATED WITH A FIRE RETARDANT THAT MEETS CPAI-84 SPECIFICATIONS.
  • Page 19: Frequently Ask Questions

    FREQUENTLY ASK QUESTIONS Fish Trap FAQ’s Q: Should I install a runner kit/hyfax to the base of my shelter? A: The warranty on our shelters does not cover cracked or worn bases if a runner kit has not been installed. Additionally, bases will wear much quicker without a runner kit installed. Q: The zipper on my shelter freezes up and/or sticks.
  • Page 20 Q: There are cracks on the inside finish of the fabric of my shelter. Is this normal? Can anything be done to fix this? A: It is normal for some of the dark colored coating to come off the inside of the tent, particularity on a non- thermal tent.
