Owner's Manual
Flat Panel Display Cart V2
55267
42" Flat Panel Display Cart
55268
36" Flat Panel Display Cart
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 15 days of receipt. To report information regard-
ing missing parts or damage, to purchase parts or
accessories, or if you have any questions, please
contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
™
Spectrum product page:
http://bit.ly/FPDcart
0109195R3 Page 1 of 10
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Industries Flat Panel Display Cart V2
Summary of Contents for Spectrum Industries Flat Panel Display Cart V2
- Page 1 Owner’s Manual ™ Flat Panel Display Cart V2 55267 42” Flat Panel Display Cart 55268 36” Flat Panel Display Cart Important Before using this product: • Read this manual Spectrum product page: • Comply with all safety and operating instructions http://bit.ly/FPDcart...
-
Page 2: Hardware Package Contents
• For added safety, plug the cart into a grounded outlet controlled by a GFI parts or user-maintenance requirements. If servicing is necessary, please contact Spectrum Industries for assistance. (Ground Fault Interrupter) circuit breaker. • Damaged electrical components can create signifi cant hazards to users and Warning - Relocating audio and/or video equipment to furniture not specifi cally is not covered by the warranty. -
Page 3: Assembly & Set-Up
Assembly / Setup Attach handle 4mm hex wrench Determine which side of the cart you want the handle to be on. (included) Attach the handle to the cart side panel with (4) 1/4-20 x 15mm JC bolts. Figure 1. Tighten all JC bolts securely. The power cord can be wrapped around the handle when not in use. - Page 4 Attach universal flat screen stand base - optional Phillips screwdriver Note: If you have not purchased the Universal Flat Screen Stand option, you can disregard this step. The aluminum base included with the stand will mount directly to the worksurface. The black MDF base included with the Universal Flat Screen Stand is only used in stationary, non-mobile applications and is not needed or recommended on a cart instal- lation.
- Page 5 Quick-release door hinge operation The front and rear doors can easily be removed for equipment installation. To remove door, pull down the quick-release lever as shown in Figure 4A while removing the door. To re-attach the door, pull down the quick-release lever while inserting the door hinge pins into the hinge pin holes. Figure 4. Release the lever when the upper hinge pin is aligned with the upper hinge pin hole-this will secure the door.
- Page 6 Floor anchoring (Toe Kick versions only) 4mm hex Drill wrench 1. If your Flat panel display cart is equipped with a toe kick, and you wish to attach it to the floor, the (included) toe-kick will need to be detached from the cart. To detach, open the doors and remove the (4) 1/4- 20 x 40mm JC bolts (one on each corner) from inside the cart.
-
Page 7: Door Stop Adjustment
Door stop adjustment 4mm hex wrench If necessary, the door stops can be repositioned to adjust the (included) closed position of the doors and lock rods. 1. To reposition the stop, loosen the Phillips screw slightly with a screwdriver. Figure 7. 2. - Page 8 Options Universal flat screen stand Flip-up shelf Steel handle bolts to work surface-holds up to a mounts on left or right, (max 2 per unit) mounts on left or right- 50” diagonal flat screen 20”W x 24”D x 1” thick max 2 per unit 55278 (50 lbs max capacity)
-
Page 9: Rack-Mount Accessories
Rack-mount accessories Note: Rack-mount accessories with a depth greater than 21 ⁄ ”D will not fit in the Flat Panel Display Cart. Check the dimensions of all equipment be- fore installation. The following Spectrum rack-mount accessories will not fit: 97503 - Pull-out Shelf (3RU) LT-4 Laptop Storage Unit (7RU) Cantilever Shelf (2RU) Cantilever Shelf (3RU) -
Page 10: Warranty Statement
Warranty Statement WE WILL MAKE IT RIGHT FOR YOU! Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations). We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below from the date of delivery.
