Owner's Manual
Owner's Manual
™
eVolve
Multi-Tech Cart
55480DW
base cart
55481DW
base cart + 8 wire dividers (for 8 units)
55482DW
base cart + 16 wire dividers (for 16 units)
55483DW
base cart + 24 wire dividers (for 24 units)
55484DW
base cart + 32 wire dividers (for 32 units)
CAUTION:
Before using this product, read this manual and follow
all safety and operating instructions.
Before you begin, please make sure all parts and
proper quantities are included. Any parts damaged
during shipment must be reported within 15 days of
receipt. To report information regarding damages or if
you have any questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
Chippewa Falls, WI 54729, USA
0112625 Page 1 of 10
Advertisement
Related Manuals for Spectrum Industries eVolve 55480DW
Summary of Contents for Spectrum Industries eVolve 55480DW
- Page 1 To report information regarding damages or if you have any questions, please call 1-800-235-1262. To purchase parts or accessories, please contact us at www.spectrumfurniture.com 1-800-235-1262 Thank you for purchasing Spectrum products! Spectrum Industries, Inc Chippewa Falls, WI 54729, USA 0112625 Page 1 of 10...
- Page 2 Safety Safety • Read this owner’s manual before assembly or operation. • Do not allow children to move cart. • Move slowly and carefully when mobile. • For indoor use only. Do not install or store the unit where it will be exposed to weather. Keep unit dry. •...
- Page 3 Divider panel & wire divider setup Divider panel & wire divider setup Note: Each divider panel can be installed in 2 different positions to accommodate different devices. For full-size laptops, the divider should be at the full-depth position, for tablets and netbooks, the divider should Full-size be at the mid position.
- Page 4 Divider panel in Full-size Laptops full-depth position up to 8 full-size laptops per shelf 8 wire dividers confi gured for full-size laptops with divider panel located in full-depth position 8 wire dividers per shelf Divider panel in Netbooks mid position up to 20 netbooks per shelf (10 per side) 10 wire dividers confi...
- Page 5 Cord Management - Storage Compartment Cord Management - Storage Compartment Route all device power/charge cords from the electrical compartment through the cord passage to the device storage compartment. Use the cord management bars above each storage bay to route the cords from the electrical compartment to each device as shown. Figure 7.
- Page 6 Cord Management - Electrical Compartment Cord Management - Electrical Compartment Large power supplies: Open the organizer door. Figure 9. Place power supplies into the storage shelves in door. Route charge cords to the devices in the storage compartment through the slot above the organizer (not shown).
-
Page 7: Warning Attention
Wheel Operation Wheel Operation Two directional, swivel locking 5” directional balloon wheels are provided and can be rotated and locked Brake Lever at 180° intervals to be rigid, or unlocked to be swivel. This provides control when transporting between classrooms, while allowing maneuverability in tight spaces. To lock the wheel direction, align each wheel with the cart width and depress the brake lever. - Page 8 eVolve Multi-Tech Cart Options eVolve Multi-Tech Cart Options Power Supply Tray Small Device Foam Module Wire Divider Kit storage for cords, power stores smart phones & other small devices 8 included supplies, or additional items 16 slots, slot size: ⁄ ”W x 5 ⁄...
- Page 9 Capacity Internal area 23”W x 21”D x 35 ⁄ ”H - device storage compartment ⁄ ”W x 4 ⁄ ”D x 35 ⁄ ”H - electrical compartment Total device capacities up to 16 full-size laptop/notebook computers (recommended maximum per cart) up to 32 netbooks up to 32 tablets Device storage shelves/bays...
-
Page 10: Warranty
Warranty Warranty WE WILL MAKE IT RIGHT FOR YOU! Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations). Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns.
