Owner's Manual
Media Manager V2 Lectern
LH Drawer
RH Drawer
55236
55237
55242
55243
Standard Media Manager V2
with LH drawer, Heavy-Duty casters & surround
CAUTION:
Before using this product, read this manual and follow
all safety and operating instructions.
Before you begin, please make sure all parts and
proper quantities are included. Any parts damaged
during shipment must be reported within 15 days of
receipt. To report information regarding damages or if
you have any questions, please call 1-800-235-1262.
To purchase parts or accessories, please contact us at
www.spectrumfurniture.com
1-800-235-1262
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
Chippewa Falls, WI 54729, USA
Standard Media Manager V2
with Overbridge Control Console
55236HDS
Media Manager V2 with Overbridge Control Console,
LH drawer & Heavy-Duty casters
55242HD
shown with optional insert panel (shaded)
0102134R5 Page 1 of 12
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Spectrum Industries Media Manager V2
Summary of Contents for Spectrum Industries Media Manager V2
- Page 1 Standard Media Manager V2 55242 55243 with Overbridge Control Console Standard Media Manager V2 Media Manager V2 with Overbridge Control Console, with LH drawer, Heavy-Duty casters & surround LH drawer & Heavy-Duty casters 55236HDS 55242HD shown with optional insert panel (shaded)
-
Page 2: Assembly & Set-Up
Safety • Read this owner’s manual before assembly or operation. • Do not allow children to move lectern. • Move slowly and carefully when mobile. • For indoor use only. Do not install or store the lectern where it will be exposed to weather. - Page 3 1/4-20 x 5/8” Note: The rack rails are factory-installed in PHM screws the Media Manager on the side opposite the (2 per bracket) document camera drawer. Media Manager V2 section view rack rails and brackets in right position Figure 2A...
- Page 4 Quick-release door hinge operation To remove door: Open door wide enough to be able to access the quick-release hinge. Support door with one hand. With other hand, push-down on the quick-release hinge lever until the upper hinge pin clears the upper hinge pin hole. Figure 3A. Hold the quick-release hinge lever down while tipping the top of the door away from the lectern.
-
Page 5: Cord Management
Cord management 4mm hex wrench The audience-side logo panel can be removed to provide access to internal wiring. 1. Remove the (6) 1/4-20 x 15mm JC bolts and remove the panel. Figure 4A. 2. Cords can be accessed through the two openings behind the panel. 3. - Page 6 Changing cord reel position (if equipped) Phillips Screwdriver 1. Remove all equipment from the lectern. 2. Lock all four casters. Carefully tip the lectern on its back-this may require 3-4 people. 3. Remove the (4) 1/4-20 x 5/8” PHM screws from the cord reel mounting bracket. See Figure 5. 4.
- Page 7 Overbridge insert panel (overbridge lecterns only) 4mm hex Drill wrench Note: The insert panel shown (shaded) is not included with the lectern or over- bridge. This option needs to be ordered separately to complete the overbridge. Measuring Drill bit device 1.
- Page 8 Media Manager V2 overbridge panel blank (flat view) 2” grommet 2” grommet max cutout area Figure 7B ™ Note: The Overbridge Control Console been designed for many of the currently avail- able controllers on the market, however, modified cutouts should be reviewed to ensure clearance of brackets, keyboard slides, or other objects under the worksurface.
- Page 9 Cord reel operation Operating Instructions: 1. To latch cord - Pull cord out to full length. Allow the cord to retract 1-2 feet back into the reel. Pull the cord out slowly. When a ‘click’ is heard, the cord will latch in place. 2.
- Page 10 Options Custom-cut logo panel Media Manager V2 Overbridge Insert Panel (audience-side) Rear Rack Rail Kit for overbridge version only-contact Spectrum ⁄ ”W x 9”H 11RU to specify cutout size(s) & position(s)- 55241 55238 overbridge not available separately (includes two 2” grommets w/ covers)
-
Page 11: Rack-Mount Accessories
Rack-mount accessories Pull-Out Shelf (3RU) Cantilever Shelf (2RU) Cantilever Shelf (3RU) Pull-Out Shelf (2RU) ⁄ ”W x 21 ⁄ ”D ⁄ ”W x 18”D x 3 ⁄ ”H ⁄ ”W x 18”D x 5 ⁄ ”H ⁄ ”W x 17 ⁄... -
Page 12: Warranty
Warranty WE WILL MAKE IT RIGHT FOR YOU! Spectrum is committed to provide complete customer satisfaction. Each of our products are manufactured from the best materials available and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations). Our Customer Service Help Line 1-800-235-1262 is ready to provide immediate attention to any questions, comments or concerns.
