Owner's Manual
LT-30
Laptop Cart
™
55208
Important
Before using this product:
• Read this manual
• Comply with all safety and operating instructions
• Ensure all parts and correct quantities are included
Any parts damaged during shipment must be reported
within 15 days of receipt. To report information regard-
ing missing parts or damage, to purchase parts or
accessories, or if you have any questions, please
contact us.
Thank you for purchasing Spectrum products!
Spectrum Industries, Inc
925 First Avenue, Chippewa Falls, WI 54729 USA
800 235 1262
715 723 6750
www.spectrumfurniture.com
Spectrum product page:
http://bit.ly/LT30cart
0116090R2 Page 1 of 9
Advertisement
Table of Contents
Related Manuals for Spectrum Industries LT-30 55208
Summary of Contents for Spectrum Industries LT-30 55208
- Page 1 Thank you for purchasing Spectrum products! Spectrum Industries, Inc 925 First Avenue, Chippewa Falls, WI 54729 USA 800 235 1262 715 723 6750 www.spectrumfurniture.com...
- Page 2 If servicing is necessary, please • For added safety, plug the cart into a grounded outlet controlled by a GFI contact Spectrum Industries for assistance. (Ground Fault Interrupter) circuit breaker. • Damaged electrical components can create signifi cant hazards to users and Warning - Relocating audio and/or video equipment to furniture not specifi cally is not covered by the warranty.
-
Page 3: Assembly & Set-Up
Assembly / Setup 1. Assemble handle 4mm hex wrench (included) 1. Attach the handle gusset and handle mounts to the bottom of the handle using 1/4-20 x 15mm JC bolts as shown in Figure 1. Do not tighten completely. handle handle mount 1/4-20 x 15mm JC bolts... - Page 4 3. Attach cord wrap brackets 4mm hex wrench 1. Attach the cord wrap brackets to the side panels (left and right-side) with (included) 1/4-20 x 15mm JC bolts as shown in Figure 3A and tighten securely. Be sure the brackets are facing away from each other as shown. 2.
-
Page 5: Cord Management
4. Cord management 1. Using the cord management slots in the trays, and Velcro straps provided, bundle the charge cords. Figure 4 shows a typical wiring example. Be sure to leave enough slack in the power cord to allow the tray to be pulled out. 2. -
Page 6: Power Connections
5. Power connections Open all doors. Move the lower trays to provide access to the base panel. Route the power cord through the lower grommet. Figure 5. Secure the power cord to the base panel using cord clips. Additional accessories can be powered from the power plug from the cycle charger. Note: The master switch on the cycle charger needs to be switched to the ‘AUX’... -
Page 7: Timer Operation
The purpose of the cycle timer is to prevent power overload while charging laptops in conjunction Cycle Timer / Charger with peripheral components. The charge mode is independent of the auxiliary mode to minimize risk of power overage. The cycle timer / charger intermittently charges two sets of outlets (12+12 for the LT-24, 15+15 for the LT-30) using a timed switch that provides accurately timed alternating charging/ switching between side A and B. -
Page 8: Door Stop Adjustment
Door stop adjustment 4mm hex wrench If necessary, the offset door stop can be rotated slightly to adjust (included) the closed position of the doors and lock rods. 1. To rotate, loosen the JC bolt slightly with a 4mm hex wrench. Figure 6. 2. -
Page 9: Warranty Statement
Warranty Statement WE WILL MAKE IT RIGHT FOR YOU! Spectrum is committed to provide complete customer satisfaction. Each of our products is manufactured from the best materials available and each product is stringently monitored throughout the production process through our P.A.C.E. program (Product Assurance to meet Customer Expectations). We expressly warrant that Spectrum products will be of good quality and workmanship and free from defect for the period set out in the warranty table below from the date of delivery.
