- Page 1 Industrial Ethernet Switches JetNet 2205 Series Installation Guide V1.4 Page 1 of (37) JetNet 2205 Series Installation Guide...
- Page 2 JetNet 2205 Installation Guide DOCUMENT CHANGE SUMMARY Initial Release Content update Content revision Content revision Content revision JetNet 2205 Series Installation Guide Page 2 of (37)
-
Page 3: Limitation Of Liability
(such as translation, transformation, or adaptation) without written permission from Beijer Electronics and/or its affiliates ("Beijer"). BEIJER reserves the right to revise or change this content from time to time without obligation on the part of BEIJER to provide notification of such revision or change. - Page 4 Trademarks ⚫ BEIJER, the BEIJER logo, and JetNet are trademarks of Beijer Electronics and/or its affiliates. Wi-Fi Alliance, Wi-Fi, the Wi-Fi logo, the Wi-Fi CERTIFIED logo, Wi-Fi Protected Access (WPA), the Wi-Fi Protected Setup logo, and WMM are registered trademarks of Wi-Fi Alliance. Wi-Fi Protected Setup™, Wi-Fi Multimedia™, and WPA2™...
-
Page 5: Table Of Contents
Electrical Safety Information ..............22 2.2. Environment and Enclosure Guidelines ............22 2.3. Package Contents .................. 23 2.4. Validating Operational Function ..............23 2.5. Installing the Switch ................24 Installation Requirements ............... 24 JetNet 2205 Series Installation Guide Page 5 of (37) - Page 6 Overview ..................30 Considerations ................... 31 Grounding the Device ................31 Wiring a Relay ..................34 Wiring Power Inputs ................34 Disconnecting Power Inputs ..............36 Power Supply Specifications ..............37 JetNet 2205 Series Installation Guide Page 6 of (37)
- Page 7 In no event will Beijer Electronics be responsible or liable for indirect or consequential • damages resulting from the use or application of this equipment.
- Page 8 1. When using a fiber optic port, never look at the transmit laser while it is powered on. Also, never look directly at the fiber port and fiber cable end when they are powered on. If you need further assistance, please contact Beijer Electronics Corp. JetNet 2205 Series Installation Guide...
- Page 9 Else it may cause the unit to a fire, electric shock or malfunction. • Modules should not be placed near inflammable materials. A fire may result if it is not handled properly. JetNet 2205 Series Installation Guide Page 9 of (37)
-
Page 10: Safety Instruction
(persons, workplace and packing) is well grounded. Avoid touching conductive components. I.III. Certification Note! For specific information relating to certification of this module type, see the separate certification document summary. The following certification information applies to JetNet 2205 series models: CE compliance ⚫ FCC part 15b compliance ⚫... -
Page 11: Introduction
With enhanced EMC and reliability design features, the JetNet 2205 Series is perfectly suited industrial application. Main Features The JetNet 2205 Series support the features. All features are not available in each model. For device specific features review the device’s datasheet to obtain further details. •... -
Page 12: Switch Models
JetNet 2205 Installation Guide Switch Models The JetNet 2205 series is available in the following models. Switch Model Description Image JetNet 2205 Industrial 5 x RJ45 10/100 base-TX Ethernet ports JetNet 2205f Industrial 4 x RJ45 10/100 base-TX Ethernet ports... -
Page 13: Technical Specifications
Technology IEEE Standards • IEEE 802.3x Flow Control • IEEE 802.1p QoS Switch Store and Forward technology Technology Performance MAC Address 1K MAC address table Packet Buffer 448 Kbits packet buffer JetNet 2205 Series Installation Guide Page 13 of (37) - Page 14 IEC/EN61000-6-2, IEC/EN61000-6-4, EN55032/55035 EMI: FCC Class B, CE/Class B Shock Compliance with IEC 60068-2-27 Regulatory Vibration Compliance with IEC 60068-2-6 Free Fall Compliance with IEC 60068-2-32 Safety IEC 62368-1, UL 62368-1 JetNet 2205 Series Installation Guide Page 14 of (37)
-
Page 15: Front Panel
JetNet 2205 Installation Guide 1.3. Front Panel Described in this section are the front panel components of the JetNet 2205 series switches. JetNet 2205 The LEDs and ports for the JetNet 2205 are located on the front panel of the switch as illustrated in the following illustrations. -
Page 16: Jetnet 2205F
See Front Panel LEDs on page 17 for further details System LED RJ-45 console ports Console/Terminal Port (RJ45) for device management/debug Fiber port 100BASE SC Type Fiber 2205f-s:Single-mode 30km 2205f-m:Multi-mode 2 km JetNet 2205 Series Installation Guide Page 16 of (37) -
Page 17: Front Panel Leds
Front Panel LEDs The system LEDs are used to monitor the switch activity and performance. The following illustration depicts the front panel on a JetNet 2205 Series. A specific LED panel is dependent on a specific JetNet model. Figure 3: Front Panel LEDs for JetNet 2205 Series No. -
Page 18: Rear View
JetNet 2205 Installation Guide 1.4. Rear View The following rear view illustrates the rear view of a JetNet 2205 Series device. For demonstration purposes a single sample is illustrated. Varying models may differ in shape and form. Figure 4: Rear Panel of JetNet 2205 Series No. -
Page 19: Bottom View
JetNet 2205 Installation Guide 1.5. Bottom View The following bottom view illustrates the bottom view of a JetNet 2205 Series device. The power inputs and relay connectors are located on the bottom panel of the switch as illustrated in the following illustrations. -
Page 20: Dimensions
1.6. Dimensions The power inputs and relay connectors are located on the rear panel of the switch as illustrated in the following illustrations. JetNet 2205 Figure 6: Dimensions of 5-Port JetNet 2205 JetNet 2205 Series Installation Guide Page 20 of (37) -
Page 21: Jetnet 2205F
JetNet 2205 Installation Guide JetNet 2205f Figure 7: Dimensions of 5-Port JetNet 2205f JetNet 2205 Series Installation Guide Page 21 of (37) -
Page 22: Chapter 2. Hardware Installation
It may be difficult to ensure electromagnetic compatibility in other environments without appropriate precautions due to conducted and radiated disturbances. This equipment is provided as open-type equipment. Enclosures must be designed appropriately to JetNet 2205 Series Installation Guide Page 22 of (37) -
Page 23: Package Contents
2.3. Package Contents After unpacking the device, validate the contents to ensure you have received all the included components. • JetNet 2205 series includes a model: industrial Ethernet switch, model may include JetNet 2205, JetNet 2205f • Documentation — Quick Installation Guide 2.4. -
Page 24: Installing The Switch
Fan and blowers in cooling mechanisms can draw dust and other particles, resulting in contaminant buildup inside the chassis, resulting in system malfunction. In order to ensure the best performance of this equipment, it must be installed in a dust-free environment JetNet 2205 Series Installation Guide Page 24 of (37) -
Page 25: Din Rail Mounting
If the installation is accurate, the bottom part of the DIN rail should be fully inserted into the release tab. Figure 8: Installing the DIN-Rail Kit The following is an illustration of a completed DIN installation. JetNet 2205 Series Installation Guide Page 25 of (37) -
Page 26: Removing The Din-Rail Mounting Kit
Rotate the lower section of the device towards yourself and away from the DIN rail. When the bottom portion is no longer in contact with the DIN rail, lift the device directly upwards to detach it from the rail. JetNet 2205 Series Installation Guide Page 26 of (37) -
Page 27: Ethernet Cable Wiring
Pin 6 TD- → ← Pin 3 TD+ Pin 3 RD+ Pin 3 TD+ Pin 1 RD+ → → Pin 6 TD- Pin 6 RD- Pin 6 TD- Pin 2 RD- → → JetNet 2205 Series Installation Guide Page 27 of (37) - Page 28 1000Base-TX: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (100m) • IEEE 802.3af: 4-pair UTP/STP Cat. 5 cable, EIA/TIA-568 100-ohm (100m) • IEEE 802.3at: 4-pair UTP/STP Cat. 5e / 6 cable, EIA/TIA-568 100-ohm (100m) JetNet 2205 Series Installation Guide Page 28 of (37)
-
Page 29: Data And Power Ports
Description RX + and V port - RX - and V port - TX + and V port + TX – and V port + 4, 5, 7, 8 Not applicable JetNet 2205 Series Installation Guide Page 29 of (37) -
Page 30: Connecting Power Inputs
AC mains by double or reinforced insulation when unit with DC power. If need further assistance, please contact Beijer Electronics Corp. for further information. Furthermore, the chassis ground screw terminal should be connected to the panel or chassis ground. -
Page 31: Considerations
Grounding the Device Follow the grounding procedure instructions and observe these warnings to ensure your equipment is adequately connected to earth ground: JetNet 2205 Series Installation Guide Page 31 of (37) - Page 32 Install the lug and the wire assembly over the grounding hole and secure with the ground-lug screw (60 in-lb). Connecting the other end of the grounding wire to a grounding point. JetNet 2205 Series Installation Guide Page 32 of (37)
- Page 33 JetNet 2205 Installation Guide Figure 13: Installing a Ground Lug and Wire JetNet 2205 Series Installation Guide Page 33 of (37)
-
Page 34: Wiring A Relay
Avoid using any power components that are not explicitly designated for the switch device. To service or wire the switch, it is essential to power down the device and disconnect the power cord. JetNet 2205 Series Installation Guide Page 34 of (37) - Page 35 Ensure the terminal block is secure by pressing it firmly in the receptor. If necessary, tighten the screws on the terminal block. If there is no visible gap between the terminal block and the receptor, it indicates that the terminal block is correctly seated. JetNet 2205 Series Installation Guide Page 35 of (37)
-
Page 36: Disconnecting Power Inputs
Figure 16: Installing Power Cabling in a Terminal Block Ensure the terminal block is secure by pressing it firmly in the receptor. If necessary, tighten the screws on the terminal block. JetNet 2205 Series Installation Guide Page 36 of (37) -
Page 37: Power Supply Specifications
JetNet 2205 Installation Guide Power Supply Specifications Table 1 Power Supply Specifications - JetNet 2205 Series Model Input Range Power Consumption JetNet 2205 10-60 VDC JetNet 2205f JetNet 2205 Series Installation Guide Page 37 of (37)
