- Page 1 Industrial 8-port Switches JetNet 2208 Series Installation Guide Page 1 of (37) JetNet 2208 Series Installation Guide...
- Page 2 JetNet 2208 Series Installation Guide DOCUMENT CHANGE SUMMARY V1.0 Initial release 202410 Page 2 of (37) JetNet 2208 Series Installation Guide...
- Page 3 (such as translation, transformation, or adaptation) without written permission from Beijer Electronics and/or its affiliates ("Beijer"). BEIJER reserves the right to revise or change this content from time to time without obligation on the part of BEIJER to provide notification of such revision or change.
- Page 4 JetNet 2208 Series Installation Guide Contents I. Safety Instruction ....................6 I.I. Symbols ....................... 6 II. Safety Warnings ....................7 III. Declaration of Conformity ................. 9 I.II. CE compliance ....................9 I.III. FCC Class B ....................9 1.1. Main Features ..................10 HW Function ..................
- Page 5 JetNet 2208 Series Installation Guide 2.1. Electrical Safety Information ..............25 2.2. Package Contents .................. 26 2.3. Installing the Switch ................27 Installation Requirements ............... 27 Installation Guidelines ................27 2.4. DIN Rail Mounting .................. 28 Removing the DIN-Rail Mounting Kit ............29 2.5.
- Page 6 JetNet 2208 Series Installation Guide I. Safety Instruction I.I. Symbols A Caution symbol indicates a potentially hazardous situation to you. A Warning symbol indicates situations that can be potentially lethal or extremely hazardous to you. An Attention symbol indicates potential damage to programs, devices, or data.
- Page 7 In no event will Beijer Electronics be responsible or liable for indirect or consequential damages resulting from the use or application of this equipment.
- Page 8 When connected to a fiber optic port, never look directly into the laser while it's powered on. Additionally, avoid looking directly into the fiber port or the end of the fiber cable when they are powered. • For further information, please contact Beijer Electronics Corp. Page 8 of (37) JetNet 2208 Series Installation Guide...
- Page 9 JetNet 2208 Series Installation Guide III. Declaration of Conformity I.II. CE compliance This product has been certified to meet CE environmental standards. It was tested under industrial conditions and found to be compliant. To prevent damage from electrostatic discharge and electromagnetic interference, we recommend using CE-certified industrial enclosures.
- Page 10 Chapter 1. Switch Overview The JetNet 2208 Series, comprising the JetNet 2208-T8, JetNet 2208T7-SC1-SM, and JetNet 2208-T7- SC1-MM models. The 8-Port Industrial Grade Switch represents a robust networking solution designed to meet the demanding requirements of industrial environments. Combining reliability, durability, and advanced features, this switch serves as a pivotal component in industrial automation, manufacturing, and other critical infrastructure applications.
- Page 11 JetNet 2208 Series Installation Guide Switch Models The JetNet 2208 series is available in the following models. Switch Model Description Picture JetNet 2208-T8 • 8-port Industrial Switch • 8 x RJ45 Ports JetNet 2208T7-SC1-SM • 8-port Industrial Switch • 7 x RJ45 Ports •...
- Page 12 JetNet 2208 Series Installation Guide JetNet 2208-T7-SC1-MM • 8-Port Industrial Switch • 7 x RJ45 Ports • 1 x Multi-mode Fibre with SC Connector Page 12 of (37) JetNet 2208 Series Installation Guide...
- Page 13 JetNet 2208 Series Installation Guide 1.2. Performance Specifications Description • IEEE 802.3 10Base-T • IEEE 802.3u 100Base-TX • IEEE 802.3u 100Base-FX (fiber model) IEEE standard • IEEE 802.3x Flow Control and Back Pressure • IEEE 802.3p CoS Store and Forward technology...
- Page 14 JetNet 2208 Series Installation Guide Specifications Description JetNet 2208-T8 / JetNet 2208-T7-SC1-SM / JetNet 2208-T7-SC1- • 1 x Power (Green on) Ethernet Port (RJ-45): • Speed 100Mbps Link (Amber on) • Speed 10Mbps link (Amber off) • Ethernet Activity (Green blinking) •...
- Page 15 JetNet 2208 Series Installation Guide 1.4. Environmental Requirements Storage and transportation Specifications Description Temperature range Storage -40 ° to +85°C Relative humidity Storage 0- 95 % RH non-condensing at ambient temperature Packaging box dimension 154 x 126 x 64.5 mm 1.5.
- Page 16 JetNet 2208 Series Installation Guide 1.6. Front Panel Described in this section are the front panel components of the JetNet 2208-T8 series switches. JetNet 2208-T8 The LEDs and ports for the JetNet 2208-T8 are located on the front panel of the switch as illustrated in the following illustrations.
- Page 17 JetNet 2208 Series Installation Guide JetNet 2208-T7-SC1-SM The LEDs and ports for the JetNet 2208-T7-SC1-SM are located on the front panel of the switch as illustrated in the following illustrations. Figure 2: Front Panel of JetNet 2208-T7-SC1-SM Item Description System LEDs...
- Page 18 JetNet 2208 Series Installation Guide JetNet 2208-T7-SC1-MM The LEDs and ports for the JetNet 2208-T7-SC1-MM are located on the front panel of the switch as illustrated in the following illustrations. Figure 3: Front Panel of JetNet 2208-T7-SC1-MM Item Description System LEDs...
- Page 19 Front Panel LEDs The system LEDs are used to monitor the switch activity and performance. The following illustration depicts the front panel on a JetNet 2208 Series. A specific LED panel is dependent on a specific JetNet model. Figure 4: Front Panel LEDs for JetNet 2208 Series...
- Page 20 JetNet 2208 Series Installation Guide 1.7. Rear View The following view illustrates the rear view of a JetNet 2208 Series device. For demonstration purposes a single sample is illustrated. Varying models may differ in shape and form. Figure 5: JetNet 2208 Series Rear Panel...
- Page 21 JetNet 2208 Series Installation Guide 1.8. Bottom View The following view illustrates the bottom view of a JetNet 2208 Series device. The power input and grounding connector are located on the bottom panel of the switch as illustrated in the following illustrations.
- Page 22 JetNet 2208 Series Installation Guide 1.9. Dimensions The power inputs and relay connectors are located on the rear panel of the switch as illustrated in the following illustrations. JetNet 2208-T8 Figure 7: 8-Port JetNet 2208-T8 Dimensions Page 22 of (37)
- Page 23 JetNet 2208 Series Installation Guide JetNet 2208-T7-SC1-SM Figure 8: 8-Port JetNet 2208-T7-SC1-SM Dimensions Page 23 of (37) JetNet 2208 Series Installation Guide...
- Page 24 JetNet 2208 Series Installation Guide JetNet 2208-T7-SC1-MM Figure 9: 8-Port JetNet 2208-T7-SC1-MM Dimensions Page 24 of (37) JetNet 2208 Series Installation Guide...
- Page 25 JetNet 2208 Series Installation Guide Chapter 2. Hardware Installation 2.1. Electrical Safety Information Voltage, frequency, and current requirements must be met according to the manufacturer's label. Using a power source other than those specified may cause improper operation, damage to the equipment, or pose a fire hazard.
- Page 26 JetNet 2208 Series Installation Guide 2.2. Package Contents After unpacking the device, validate the contents to ensure you have received all the included components. • JetNet 2208 series industrial switch • Documentation — Installation Guide Page 26 of (37) JetNet 2208 Series Installation Guide...
- Page 27 JetNet 2208 Series Installation Guide 2.3. Installing the Switch Installation Requirements The fastest way to install the product is by choosing the DIN rail mount option. Moreover, this option efficiently utilizes the available rail space. To secure the switch, you can use the metal DIN rail kit provided. It can be attached to the back of the device, allowing for mounting on a standard DIN rail: •...
- Page 28 JetNet 2208 Series Installation Guide 2.4. DIN Rail Mounting Place the rear panel of the switch in front of the DIN rail, ensuring that the top part of the DIN rail clip securely hooks over the top of the rail. This arrangement is depicted in the following illustration.
- Page 29 JetNet 2208 Series Installation Guide Figure 11: Example of an Installed DIN Rail Kit Hold the bottom of the switch and gently tilt it upward. If you encounter resistance, it indicates that the switch has been properly installed. If you do not experience any resistance, it is advisable to restart the installation process from the beginning.
- Page 30 JetNet 2208 Series Installation Guide Figure 12: Removing a DIN Rail 2.5. Ethernet Cable Wiring You should use data-quality twisted-pair cabling (rated CAT5 or higher) for RJ45 connectors. For optimal performance, shielded cabling should be used. Additional protection may be provided by shielded cabling.
- Page 31 JetNet 2208 Series Installation Guide Figure 13: Mounting a Switch in a Rack Note!! Ethernet cables use pins 1, 2, 3, and 6 of an 8-pin RJ-45 connectors. The signals of these pins are converted by the automatic MDI-X function, as shown in the table below:...
- Page 32 JetNet 2208 Series Installation Guide 2.6. Connecting Power Inputs Overview Before servicing or wiring the switch, power it down and disconnect the power cord. Ensure that the power has been turned off before disconnecting modules or cabling. Only the voltage specified on the type plate can be used with the device.
- Page 33 JetNet 2208 Series Installation Guide Considerations Before wiring the device, consider the following guidelines: • For better management and servicing, label all wiring and cabling to the various devices. • Earthing conductors must have at least a 3.31 mm cross section.
- Page 34 JetNet 2208 Series Installation Guide If the ground wire is insulated, strip it to 0.5 inch (12.7 mm) ± 0.02 inch (0.5 mm). Prepare the Grounding Screw and Wire Insert the Earth Ground Screw with the green-yellow wire (wire size: 20 AWG minimum) and tighten it.
- Page 35 JetNet 2208 Series Installation Guide 2.8. Wiring a Relay The two contacts on the side and the front two contacts on the 4-contact terminal block connector are for the DC inputs. As illustrated in the following figure, the side and front view of a terminal block are displayed.
- Page 36 JetNet 2208 Series Installation Guide To wire the power inputs: Ensure that the power is disconnected from both the switch and the power converter before proceeding. Follow these steps: Loosen the Screws: Locate the input terminal block connector on your equipment.
- Page 37 Isolation: Double or reinforced insulation is required when using the unit with DC power to separate it from the AC mains. For further assistance or information, contact Beijer Electronics Corp. Table 1 Power Supply Specifications - JetNet 2208 Series Model Input Range...
