User Manual
for S6 Series Hybrid Inverter
Applicable models
S6-EA3P5KAA-NV-ND-H
S6-EA3P6KAA-NV-ND-H
S6-EA3P8KAA-NV-ND-H
S6-EA3P10KAA-NV-ND-H
Applicable System
Three phase system
Version 1.0, Release Date: 02,2025

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the S6-EA3P5KAA-NV-ND-H and is the answer not in the manual?

Questions and answers

Related Manuals for SOLIS S6-EA3P5KAA-NV-ND-H

Summary of Contents for SOLIS S6-EA3P5KAA-NV-ND-H

  • Page 1 User Manual for S6 Series Hybrid Inverter Applicable models S6-EA3P5KAA-NV-ND-H S6-EA3P6KAA-NV-ND-H S6-EA3P8KAA-NV-ND-H S6-EA3P10KAA-NV-ND-H Applicable System Three phase system Version 1.0, Release Date: 02,2025...

  • Page 2: Table Of Contents

    Contents 1. Introduction ……………………………………………………………………………………………………………………………… 1.1 Product Description ……………………………………………………………………………………………………………… 1.2 Packaging ………………………………………………………………………………………………………………………………… 2. Safety & Warning ……………………………………………………………………………………………………………… 2.1 Safety ………………………………………………………………………………………………………………………………………… 2.2 General Safety Instructions ………………………………………………………………………………………………… 2.3 Notice For Use ………………………………………………………………………………………………………………………… 2.4 Notice for Disposal ……………………………………………………………………………………………………………… 3. Overview …………………………………………………………………………………………………………………………………… 3.1 Intelligent LED Indicators …………………………………………………………………………………………………...

  • Page 3: Introduction

    The S6 Series is designed for residential hybrid systems, which can work with batteries to optimize self-consumption. The unit can operate in both off- and on-grid modes. This manual covers the S6 Series inverter model listed below: S6-EA3P5KAA-NV-ND-H, S6-EA3P6KAA-NV-ND-H, S6-EA3P8KAA-NV-ND-H, S6-EA3P10KAA-NV-ND-H Figure 1.1 Front side view Battery Input...

  • Page 4: Packaging

    1. Introduction User Manual 1.2 Packaging Please ensure that the following items are included in the packaging with your machine: Inverter x1 Back Plate x1 Fixing Screws(M4*12) x4 AC Grid x1 RJ45 connector x6 Battery Connector x1 CAN cable x1 Eastron Meter x1 Manual User Manual x1...

  • Page 5: Safety & Warning

    2. Safety & Warning User Manual 2.1 Safety The following types of safety instructions and general information appear in this document as described below: DANGER: “Danger” indicates a hazardous situation which if not avoided, will result in death or serious injury. WARNING: “Warning”...
  • Page 6 2. Safety & Warning User Manual WARNING: To reduce the risk of fire, over-current protective devices (OCPD) are required for circuits connected to the inverter. The DC OCPD shall be installed per local requirements. All photovoltaic source and output circuit conductors shall have isolators that comply with the NEC Article 690, Part II.

  • Page 7: Notice For Use

    2. Safety & Warning User Manual 2.3 Notice for Use The inverter has been constructed according to the applicable safety and technical guidelines. Use the inverter in installations that meet the following specifications ONLY: 1. Permanent installation is required. 2. The electrical installation must meet all the applicable regulations and standards. 3.

  • Page 8: Overview

    3. Overview User Manual 3.1 Intelligent LED Indicators There are five indicators on the The S6 Series Inverter (Battery, Power, WiFi, Ethernet and Bluetooth) which indicate the working status of the inverter. The Bluetooth Antenna or WiFi datalogger shall be installed at the Antenna/COM port of the hybrid inverter before local debugging.

  • Page 9: Password Reset

    3. Overview User Manual 3.2 Password Reset When the password of the owner or the installer needs to be reset,please long press the Inverter indicator for 5s. If the reset command is successfully triggered,the status indicator will be blue and blink for 3s at the frequency of 0.5s, then restore the original state of the indicator.

  • Page 10: Installation

    4. Installation User Manual 4.1 Select a Location for the Inverter To select a location for the inverter, the following criteria should be considered: Exposure to direct sunlight may cause output power derating. It is recommended to avoid installing the inverter in direct sunlight. It is recommended that the inverter is installed in a cooler ambient which doesn't exceed 104℉/40℃.
  • Page 11 4. Installation User Manual Install on a wall or strong structure capable of bearing the weight of the machine. Install vertically with a maximum incline of +/- 5 degrees, exceeding this may cause output power derating. To avoid overheating, always make sure the flow of air around the inverter is not blocked.

  • Page 12: Mounting The Inverter

    4. Installation User Manual 4.2 Mounting the Inverter Dimensions of mounting bracket: unit:mm Figure 4.3 Inverter wall mounting Once a suitable location has be found accordingly to 4.1 using figure 4.3 mount the wall bracket to the wall. The inverter shall be mounted vertically. The steps to mount the inverter are listed below: 1.

  • Page 13: Pe Cable Installation

    4. Installation User Manual 4.3 PE Cable Installation An external ground connection is provided at the right side of inverter. Prepare OT terminals: M4. Use proper tooling to crimp the lug to the terminal. Connect the OT terminal with ground cable to the right side of inverter. The torque is 2N.m. Grounding screw Grounding screw Figure 4.5 Connect the external grounding conductor...

  • Page 14: Battery Power Cable Installation

    4. Installation User Manual 4.4 Battery Power Cable Installation 1. Take out the two pre-made battery power cables from the package. Cable length: 1 meter. Cross section area is 8mm². Figure 4.6 2. Connect the battery ends to the battery module positive and negative terminals. 3.

  • Page 15: Ac Cable Installation

    4. Installation User Manual 4.5 AC Cable Installation This is AC terminals on the inverter and the assembly steps are similar. AC Grid Port is to connect to the grid. AC-GRID terminal Figure 4.9 4.5.1 AC Grid Port Connection Describe Numerical value Cable diameter 14~17mm...
  • Page 16 4. Installation User Manual 2. Disassemble the AC Grid Connector and set the parts on the cable. A: Body B: Seal body C: Nut Figure 4.11 3. Crimp wires, screw torque 0.8N·m±0.1N·m. AC Grid Figure 4.12 4. Push Housing into Body until you hear a “click” sound. Housing Click Figure 4.13...
  • Page 17 4. Installation User Manual 6. Push the AC Grid Connector into the AC Grid Port on the inverter and rotate the rotatory ring on the AC Grid connector to the direction as marked “LOCK” on the connector. (Hold the Body while rotating the ring). Click Figure 4.15 NOTE:...

  • Page 18: Communication Cable Installation

    4. Installation User Manual 4.6 Communication Cable Installation 4.6.1 Protective Cover for Communication Ports Figure 4.18 Inverter in the package is with a protective cover assembled to protect the communication ports. Step 1. Use Phillips screwdriver to take out the 4 screws on the cover. Step 2.
  • Page 19 4. Installation User Manual 4.6.2 Communication Port Definition Reserved DO/DI RS485 Meter Figure 4.19 Port Function Used for CAN communication between inverter and Lithium battery BMS. Used for RS485 communication between inverter and the smart Meter meter. It is necessary to realize the normal hybrid control logics. (Optional)To realize Demand Response or Logic interface function, this function may be required in UK and Australia.
  • Page 20 4. Installation User Manual 4.6.3 BMS Port Connection Take out the pre-made CAN cable from the package and connect one end to battery CAN port and then connect another end to the inverter BMS port. Cable Length: 3 meters. Figure 4.20 NOTE: RJ45terminal Pin definition of the BMS Port is following...
  • Page 21 4. Installation User Manual 4.6.4.2 For DRED Control Function (For AU and NZ Only) DRED means demand response enable device. The AS/NZS 4777.2 :2020 required inverter need to support demand response mode(DRM). This function is for inverter that comply with AS/NZS 4777.2 :2020 standard.

  • Page 22: Meter Installation

    Make sure the AC cable is totally isolated from AC power before connecting the Smart Meter and CT. The Solis hybrid inverter is able to connected standard Eastron meters to fulfill the control logic of the self-consumption mode, export power control, monitoring, etc.
  • Page 23 4. Installation User Manual...

  • Page 24: Inverter Remote Monitoring Connection

    The USB type COM port at the bottom of the inverter can connect to different kinds of Solis data loggers to realize the remote monitoring on Soliscloud platform. To install Solis data loggers, please refer to corresponding user manuals of Solis data loggers.

  • Page 25: Commissioning & Shutdown

    5. Commissioning & Shutdown User Manual 5.1 Preparation of Commissioning Ensure all the devices are accessible for operation, maintenance and service. Check and confirm that the inverter is firmly installed. Space for ventilation is sufficient for one inverter or multiple inverters. Nothing is left on the top of the inverter or battery module.
  • Page 26 5. Commissioning & Shutdown User Manual Step 4: Connect with Bluetooth. Turn on Bluetooth switch on your mobile phone and then open the Soliscloud APP. Click “More Tools”->”Local Operation”->”Connect with Bluetooth” < Local Operation Register Register Hello, Hello, Welcome to SolisCloud Welcome to SolisCloud Username/Email Username/Email...
  • Page 27 5. Commissioning & Shutdown User Manual Step 7: After the log in for the first time, initial settings are required. Step 7.1: Set the inverter Date and Time. You can set to follow the time on your mobile phone. Step 7.2: Set the battery model. It must be based on the battery model that is actually connected to the inverter.

  • Page 28: Shutdown Procedure

    Step 9: Change Password. If the Owner forgot the password, please contact the installer. Installer log in and go to “Setting”->”More”->”Change Password” to reset the password for owner’s account. If Installer forgot the password, please contact Solis service team. More More...

  • Page 29: Maintenance

    6. Maintenance User Manual S6 Series inverter does not require any regular maintenance. However, cleaning the heatsink will help inverter dissipating heat and increase the lifetime of inverter. The dirt on the inverter can be cleaned with a soft brush. CAUTION: Do not touch the surface when the inverter is operating.

  • Page 30: Troubleshooting

    7. Troubleshooting User Manual Message Name Information Description Troubleshooting Suggestion 1. Turn on the device in the ON/OFF Setting. Control device to shutdown 1. Confirm whether the inverter is connected to an external EPM/meter to prevent reverse current. 2. Confirm whether the inverter is controlled The device's output is under LmtByEPM by an external third-party device.
  • Page 31 7. Troubleshooting User Manual Message Name Information Description Troubleshooting Suggestion 1. Grid side fault, restart the device. Surge Alarm On-site grid surge If it is still not eliminated, please contact the manufacturer's customer service. Grid voltage exceeds the OV-G-V01 upper voltage range Grid voltage exceeds the UN-G-V01 lower voltage range...
  • Page 32 7. Troubleshooting User Manual Message Name Information Description Troubleshooting Suggestion 1. Confirm whether the battery model selection Wrong battery brand selection BatName-FAIL is consistent with the actual one. 1. Can failure is a failure of communication between inverter and battery. Check cable conditions.
  • Page 33 7. Troubleshooting User Manual Message Name Information Description Troubleshooting Suggestion 1. Confirm that the grid is abnormal. 2. Confirm that the AC cable connection is not DCInj-FAULT The current DC component abnormal. (1037 DATA:0000) exceeds the limit 3. Restart the system, confirm that the fault continues.
  • Page 34 7. Troubleshooting User Manual NOTE: If the inverter displays any alarm message as listed in Table 7.1; please turn off the inverter and wait for 5 minutes before restarting it . If the failure persists, please contact your local distributor or the service center.

  • Page 35: Specifications

    8. Specifications User Manual Technical Data S6-EA3P5KAA-NV-ND-H S6-EA3P6KAA-NV-ND-H Battery Battery Type Li-ion Battery Voltage range 120 - 600Vdc Maximum charging Power Charge/discharge current 0-25A Battery Isc Battery Communication CAN/RS485 Output AC(Grid-side) Rated output power Max. apparent output power 5kVA 6kVA...
  • Page 36 8. Specifications User Manual Technical Data S6-EA3P5KAA-NV-ND-H S6-EA3P6KAA-NV-ND-H Protection Anti-islanding protection Insulation Resistor detection Residual current monitoring unit Output over current protection Output short protection Output over voltage protection Battery reverse protection Protection class / Over voltage category Ⅰ/Ⅱ (Battery), Ⅲ (Main)
  • Page 37 8. Specifications User Manual Technical Data S6-EA3P8KAA-NV-ND-H S6-EA3P10KAA-NV-ND-H Battery Battery Type Li-ion Battery Voltage range 120 - 600Vdc Maximum charging Power 10kW Charge/discharge current 0-50A Battery Isc Battery Communication CAN/RS485 Output AC(Grid-side) Rated output power 10kW Max. apparent output power 8kVA 10kVA Rated grid voltage...
  • Page 38 8. Specifications User Manual Technical Data S6-EA3P8KAA-NV-ND-H S6-EA3P10KAA-NV-ND-H Protection Anti-islanding protection Insulation Resistor detection Residual current monitoring unit Output over current protection Output short protection Output over voltage protection Battery reverse protection Protection class / Over voltage category Ⅰ/Ⅱ (Battery), Ⅲ (Main) General data Dimensions(W/H/D) 600*500*230mm...
  • Page 39 Ginlong Technologies Co., Ltd. No. 57 Jintong Road, Binhai Industrial Park, Xiangshan, Ningbo, Zhejiang, 315712, P.R.China. Tel: +86 (0)574 6578 1806 Tel: www.solisinverters.com Please adhere to the actual products in case of any discrepancies in this user manual. If you encounter any problem on the inverter, please find out the inverter S/N and contact us, we will try to respond to your question ASAP.

This manual is also suitable for:

S6 seriesS6-ea3p6kaa-nv-nd-hS6-ea3p8kaa-nv-nd-hS6-ea3p10kaa-nv-nd-h
