- Page 1 Free Standing Electric Cooker Instructions for installation and use KD6E35...
-
Page 2: Table Of Contents
Contents Introduction Installation Safety Information Features Control Panel Clock/Minute Minder Operation Temperature Conversion Chart Sealed Hob Grill Pan and Handle Grill Guide to Grilling Top Oven Cookery Notes Main Oven Cookery Notes Oven Temperature charts Care and Cleaning Cooking Results Not Satisfactory? Something Wrong With Your Cooker? If it Still Won’t Work.../ Disposal of the appliance Key Contacts / Guarantee Information... -
Page 3: Introduction
Introduction Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: Installation
Installation WARNING – THIS APPLIANCE MUST BE EARTHED. MAINS CONNECTION UK Household: Your cooker should have been checked to ensure that the voltage corresponds with your supply voltage, this is stated on the rating plate, which is situated on the outer rear panel.The model number and the serial number are located on the front of the cooker, as shown on the Features page. - Page 5 Installation NOTE: The rear of your cooker needs to be a required distance away from the wall.The two buffers at the rear of the Hob determine this distance. Splashback A splashback is also supplied, to prevent food from falling down the back of your cooker. To fit: Remove the two buffers from the rear of the hob - retain to one side.
-
Page 6: Safety Information
Safety Information When used properly your appliance is completely safe but as with any electrical product there are certain precautions that must be observed. PLEASE READ THE PRECAUTIONS BELOW BEFORE USING YOUR APPLIANCE. Always Remove all packing from the appliance before switching on for the first time. Understand the controls prior to using the appliance. - Page 7 Safety Information Never Never stare at Halogen heating units Never leave children unsupervised where a cooking appliance is installed as all surfaces will be hot during and after its use. Never allow anyone to sit or stand on any part of the appliance. Never store items above the appliance that children may attempt to reach.
-
Page 8: Features
Features 2000W Red Spot 2000W Sealed Splash Back 2000W Red Spot 1500W Red Spot Clock/Minute Minder Control panel Model number and Serial number Conventional label Grill Grill pan food support Grill pan with Top oven/grill fixed/detachable rod shelf handle Top oven wirework shelf supports Main oven... -
Page 9: Control Panel
Control Panel Main oven Hob ON Top oven neon neon neon Clock / Minute Minder Left Right Grill Left Main Right rear rear front front oven oven Operating In common with all cookers having controls sited above the grill controls when the compartment, care must be taken when setting the controls, due grill is in use to the hot air expelled from the grill compartment. -
Page 10: Clock/Minute Minder Operation
Clock/Minute Minder CLOCK OPERATION To set the Time of Day: 00.00 Step 1 Check that the electricity supply to the cooker is turned on. Step 2 When switched on, the display will show 0.00 flashing intermittently. Step 3 Press the “ “... -
Page 11: Minute Minder Operation
Clock/Minute Minder MINUTE MINDER OPERATION To set the Minute Minder: 00.20 Step 1 Press the ‘+’ button until the required time is set. A “Bell”symbol will light up. Each press adjusts the time in 10 second intervals, up to a maximum of 99 minutes 50 seconds. -
Page 12: Temperature Conversion Chart
Temperature Conversion Chart Main Main ˚F Conventional Mark Oven Oven – – The recommended temperatures given are for conventional and fan Temperatures ovens. When using a fan oven it will be necessary to reduce the cooking time by 10 minutes per hour and lower the temperature by up to 20˚C. Also, in the majority of cases, it is not necessary to pre-heat the oven. -
Page 13: Sealed Hob
Sealed Hob USE OF HOTPLATES Under no circumstances should the hob be used with aluminium foil in contact with the hob surface. Turn the control to 6 for fast cooking. To cook more slowly or simmer, turn the control to a lower setting according to the size of the saucepan and the amount of liquid.The small Hotplate is specially for smaller pans, low temperature cooking and simmering. - Page 14 Sealed Hob General Information CHOICE OF UTENSILS Every Electric Hob deserves the right choice of utensils. We recommend for optimum performance the use of good quality utensils. Never Always Use good quality flat-based Use gauze, metal pan PANS SHOULD NOT cookware on all electric heat diffusers, asbestos mats and sources.
-
Page 15: Grill Pan And Handle
Grill Pan and Handle Grill pan handle Please note that if a fixed handle is required, the grill pan cannot be kept in the Main Fan Oven compartment with the door closed but may be stored in the Top compartment when the appliance is not in use. Warning: Ensure when using grill pan handle in the detachable manner it is centralised and secure. -
Page 16: Grill
Grill CAUTION - ACCESSIBLE PARTS MAY BECOME HOT WHEN THE Setting the Grill GRILL IS IN USE. CHILDREN SHOULD BE KEPT AWAY. GRILLING SHOULD NEVER BE UNDERTAKEN WITH THE DOOR CLOSED. Door in grilling position The grill control is designed to provide variable heat control of either the twin grill elements on together or the single left hand grill element only, depending upon which direction the control knob is rotated. -
Page 17: Guide To Grilling
Guide To Grilling Pre - heat the grill for 5 minutes on maximum control setting before grilling GRILL CHART Food Grill Setting Approximate Cooking time Toasting of Bread 4 / Max 3 - 10 mins. products 4 / Max for 4 mins. Small cuts of meat, reduce to lower 10 - 20 mins. -
Page 18: Top Oven Cookery Notes
Top Oven Cookery Notes The top oven should be used to cook small quantities of food. The oven is designed so that the grill element operates at a reduced heat output, this is combined with a heating element situated underneath the floor of the oven. -
Page 19: Main Oven Cookery Notes
Main Oven Cookery Notes The oven is fitted with wirework shelf supports and two rod shelves. To heat the oven turn the knob clockwise, selecting the require temperature between 80°C (176°F) and 230°C (450°F) as recommended in the temperature chart. The pilot light will immediately come on and remain on until the oven reaches the required temperature. - Page 21 Note: If soft margarine is used for cake making, temperatures recommended by the manufacturers should be followed. Temperatures recommended in this chart refer to cakes made with block margarines or butter only.
-
Page 22: Care And Cleaning
Care and Cleaning TURN OFF THE MAIN SWITCH AND ENSURE THE COOKER IS COLD BEFORE CLEANING. BEFORE SWITCHING ON AGAIN, ENSURE THAT ALL CONTROLS ARE IN THE OFF POSITION. NEVER USE BIOLOGICAL WASHING POWDER, HARSH ABRASIVES, SCOURING PADS, AEROSOL CLEANERS OR OVEN CHEMICAL CLEANERS OF ANY KIND, UNLESS SPECIFIED BELOW. - Page 23 Care and Cleaning Oven shelf supports The shelf supports are removable and dishwasher safe. To remove hold the support at the front and pull away from the oven side, this can then be cleaned in a sink or a dishwasher. When removed it allows access to the oven side, which can be cleaned with warm soapy water.
-
Page 24: Main Oven
Care and Cleaning Grill: Remove the grill pan and the wire grid food support, it is best to wash these items immediately after each use to prevent stains from being burnt on when used again. Wipe out the Grill compartment, use a fine steel wool soap pad to remove stubborn stains from the compartment. -
Page 25: Cleaning The Doors
Care and Cleaning Take particular care not to damage the inner surface of the door inner glass that is coated with a heat reflective layer. Do not use scouring pads, or abrasive powder, which will scratch the glass. Ensure that the glass panel is not subjected to any sharp mechanical blows. -
Page 26: Cooking Results Not Satisfactory
Cooking Results Not Satisfactory? Problem Check Grilling Uneven cooking front Ensure that the grill pan is positioned centrally below to back the grill element. Fat splattering Ensure that the grill is not set to too high a setting. Baking (General) Uneven rising of cakes Ensure that the oven shelves are level by using a spirit level on the rod shelf and adjusting the wheels/feet. -
Page 27: Something Wrong With Your Cooker
Something Wrong with your Cooker? Before contacting your nearest Service Centre/Installer, check the problem guide below; there may be nothing wrong with your cooker. Problem Slight odour or small amount of This is normal and should cease after a short period. smoke when grill / oven used for first time Nothing works... -
Page 28: If It Still Won't Work
If It Still Won’t Work... Contact the Service Office ( UK: 08709 066 066 If something is still wrong with your appliance after you have been through the ‘Something Wrong’ list: 1. Switch off and unplug the appliance from the mains. 2. -
Page 30: After Sales Service
After Sales Service No one is better placed to care for your Indesit appliance during the course of its working life than us – the manufacturer. Essential Contact Information Indesit Service We are the largest service team in the UK and Ireland offering you access to 400 skilled telephone advisors and 1000 fully qualified engineers on call to ensure you receive fast, reliable, local service. - Page 31 Guarantee 12 months Parts and Labour Guarantee Your appliance has the benefit of our manufacturer’s guarantee, which covers the cost of breakdown repairs for twelve months from the date of purchase. This gives you the reassurance that if, within that time, your appliance is proven to be defective because of either workmanship or materials, we will, at our discretion, either repair or replace the appliance at no cost to you.
- Page 32 5 Year Parts Guarantee Indesit also offers you a free 5 year parts guarantee. This additional guarantee is conditional on you registering your appliance with us and the parts being fitted by one of our authorised engineers. There will be a charge for our engineer’s time. To activate the extra parts warranty on your appliance, simply...
