- Page 1 Free Standing Dual Fuel Cooker Instructions for installation and use KD643E KD641E...
-
Page 2: Table Of Contents
Contents Introduction Safety Information Oven Timer Operation (KD643E only) Hotplate Grill Ovens Oven Cooking Charts The “Slow Cook” Setting Care and Cleaning Something Wrong With Your Cooker? Installation If it Still Won’t Work... Key Contacts You must read these instructions prior to using your appliance and retain them for future use. -
Page 3: Introduction
Introduction Your new appliance is guaranteed* and will give lasting service. This guarantee is only applicable if the appliance has been installed in accordance with the installation instructions detailed in this booklet. To help make best use of your cooking equipment, please read this booklet carefully. The cooker is designed specifically for domestic use and responsibility will not be accepted for use in any other installation. -
Page 4: Safety Information
Safety Information Please read the precautions below before using your cooker. ALWAYS . . . ALWAYS make sure you understand the controls before using the cooker. ALWAYS check that all controls on the cooker are turned off after use. ALWAYS stand back when opening an oven door to allow heat to disperse. - Page 5 Safety Information NEVER . . . NEVER leave children unsupervised where the cooker is installed as all surfaces will get hot during and after use. NEVER allow anyone to sit or stand on any part of the cooker. NEVER store items that children may attempt to reach above the cooker. NEVER heat up unopened food containers as pressure can build up causing the container to burst.
-
Page 6: Oven Timer Operation (Kd643E Only)
Oven Timer Operation (KD643E only) The timer offers you the following features: 1. Time of Day 2. Automatic Cooking 3. Minute Minder AUTOMATIC COOKING The main oven can be controlled automatically. GUIDANCE ON AUTOMATIC COOKING 1. Select foods which will take the same time to cook. 2. - Page 7 Know your Timer (KD643E only) CLOCKFACE The timer incorporates a 24 hour clock. Ensure the correct time of day is always set, before using your cooker. SYMBOLS A ‘bell’ symbol will light up when you select a Minute Minder Period and will remain lit for the period set.
-
Page 8: Setting The Minute Minder
Electronic Clock & Automatic Oven Timer Operation (KD643E only) SETTING THE TIME OF DAY Step 1 Make sure all oven controls are turned Off. Step 2 Check the electricity supply to the cooker is turned on. Step 3 When switched on the display will show 0.00 and the Auto symbol, Step 4 Press &... -
Page 9: Auto Cooking Programmes
Electronic Clock & Automatic Oven Timer Operation (KD643E only) AUTO COOKING PROGRAMMES There are two Auto Cooking programmes that can be selected using your timer:– (a) To set the timer to switch the oven(s) On and Off Automatically (b) To set timer to switch on immediately and OFF automatically after a set cook period. a) TO SET THE TIMER TO SWITCH THE OVEN(S) ON AND OFF AUTOMATICALLY This allows you to cook at a specified time for a chosen period before the oven switches off Automatically. - Page 10 Electronic Clock & Automatic Oven Timer Operation (KD643E only) Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button. Note 2 When cooking automatically the End Time can be checked at any time by simply pressing the End Time button.
- Page 11 Electronic Clock & Automatic Oven Timer Operation (KD643E only) TO CANCEL AN AUTO COOKING PROGRAMME BEFORE THE COOK PERIOD HAS FINISHED. Step 1 Turn the oven control(s) to the OFF position. Step 2 Press the Manual button to return the oven(s) to “Manual” operation. Note 1 When cooking automatically the Cook Period can be checked at any time by simply pressing the Cook Period button.
-
Page 12: Hotplate
Hotplate The hotplate has two high speed burners and two simmering burners which will accommodate pans between 100mm (4”) and 230mm (9”) diameter. All pans should be positioned centrally over the burners. TO USE THE HOTPLATE 1. Press the ignition button and then push in and turn the control knob of the chosen burner anti-clockwise to the large flame symbol. - Page 13 Hotplate SAFETY REQUIREMENTS FOR DEEP FAT FRYING 1. Never fill chip pans more than one third full with oil or fat. 2. Never leave oil or fat unattended during the heating or cooling period. 3. Never heat fat or fry with a lid on the pan. 4.
-
Page 14: Grill
Grill CAUTION – ACCESSIBLE PARTS MAY BECOME HOT WHEN THE GRILL IS IN USE. YOUNG CHILDREN SHOULD BE KEPT AWAY. GRILLING SHOULD NEVER BE UNDERTAKEN WITH THE GRILL DOOR CLOSED. The grill control is designed to provide variable heat control of either the full width of the grill or just the left half. -
Page 15: Oven Cooking Charts
Ovens Both ovens have a thermostat light that will illuminate until the oven has reached the set temperature. It will then switch off and on during cooking as the thermostat maintains the temperature. Each shelf has a safety stop to prevent it from being pulled out too far when attending to food. -
Page 17: Oven Cooking Chart
OVEN COOKING CHART Note: If soft margarine is used for cake making, temperatures recommended by the manufacturers should be followed. Temperatures recommended in this chart refer to cakes made with block margarine only. -
Page 18: The "Slow Cook" Setting
The Plate Warming ‘S’ Setting The 90˚ setting on the main oven thermostat can be used for slow cooking. PREPARING FOOD FOR SLOW COOKING 1. All dishes cooked by the ‘S’ setting should be cooked for a minimum 6 hours. They will ‘hold’... -
Page 19: Care And Cleaning
Care and Cleaning Switch off the electricity supply and allow to cool before cleaning the cooker. Clean the cooker regularly and wipe up spills soon after they occur to prevent them from becoming burnt on. Never use biological washing powder, caustic cleaners, harsh abrasives, scouring pads, steam cleaners, aerosol cleaners or oven chemical cleaners of any kind. -
Page 20: Cleaning Method
Care and Cleaning COOKER FINISH Vitreous Enamel Hotplate, pan supports, hotplate front trim, burner caps, roasting dish, grill pan, main oven base, inside of grill compartment, inside of doors. Paint Side trims, plinth, fascia bottom trim, fascia end caps, side panels, door handles Aluminium Hotplate side trims, hotplate... -
Page 21: Cleaning The Doors
Care and Cleaning Take particular care not to damage the inner surface of the door inner glass that is coated with a heat reflective layer. Do not use scouring pads, or abrasive powder, which will scratch the glass. Ensure that the glass panel is not subjected to any sharp mechanical blows. -
Page 22: Something Wrong With Your Cooker
Something Wrong with your Cooker Before contacting your nearest Service Centre or Installer, check the problem guide below, there may be nothing wrong with your cooker. PROBLEM Ignition does not work. Hotplate burner. Burner ports Ignitor CHECK If all burners fail to ignite: Check that sparks appear at the burners;... - Page 23 Something Wrong with your Cooker PROBLEM Slight odour or small amount of smoke when grill / oven used first time Oven cooks too fast or too slow (KD643E only) Cannot set an “Auto Cook” programme or cannot get the timer to turn the oven on or off at the required times.
-
Page 24: Installation
This appliance is not designed to be connected to a combustion products evacuation device. It must be installed and connected in accordance with current installation regulations. particular attention should be given to the relevant requirements regarding ventilation. MODEL NUMBERS KD643E and KD641E Category Il (GB. IE) 2h3+... -
Page 25: Installation Instructions
Installation Instructions TECHNICAL DATA DIMENSIONS Height Width Depth GENERAL Gas connection Pressure test point Gas rate adjustment Aeration adjustment Electrical connection HOTPLATE Front left and rear right HOTPLATE Front right and rear left GRILL TOP OVEN MAIN OVEN 900 - 915mm 600mm 595mm (excluding door handles) ”... -
Page 26: Unpacking The Cooker
Installation Instructions SPACE FOR FIXING The cooker can be close fitted below hotplate level. This requires a minimum distance of 600mm between cupboard units of hotplate height. When installing next to a tall cupboard, partition or wall, for a minimum distance of 400mm above hotplate level, allow a side clearance of at least 65mm. -
Page 27: Stability Bracket
Installation Instructions LEVELLING Two rear wheels and two front feet are fitted which can be adjusted up or down to set the height (915mm) and level the cooker. The rear wheels can be raised or lowered from the BACK of the cooker by adjusting the levelling screws ‘A’... -
Page 28: Electrical Installation
Electrical Installation Warning - THIS APPLIANCE MUST BE EARTHED The cooker must be connected by a qualified electrician to a suitable double - pole control unit with a minimum rating of 32A and a minimum contact clearance of 3mm, which should be fitted adjacent to (but not above) the cooker, in accordance with IEE regulations. - Page 29 Notes...
- Page 30 Notes...
-
Page 31: If It Still Won't Work
If It Still Won’t Work... Contact the Service Office (0870 6070805) If something is still wrong with your appliance after you have been through the ‘Something Wrong’ list: Switch off and unplug the appliance from the mains. Call your nearest Service Office or local importer. When you contact us we will want to know the following: 1. -
Page 32: Extended Warranty
Key Contacts Repair Service and Information Desk UK: 0870 6070805 (Open 8am to 5.30pm Mon - Fri 9am to 5pm Sat and 10am to 4pm Sun Closed Bank Holidays) Note: Our operators will require the following information:- Model Number: Serial Number: Extended Warranty To join: UK 0870 442 7661 (Open 8 to 8 Mon-Sun)
