JLG 260MRT Operating Instructions

JLG 260MRT SCISSOR LIFT OPERATING INSTRUCTIONS &
Quick Start Guide
The ground control station and platform control station emergency stop buttons
(RED) must be set to "ON" in order to operate this machine.
1. Travelling and steering – Place the key selector switch on the ground
control station to platform operation. On the platform control station,
position the lift/drive switch to the drive position
- To move unit forward and backward: Grab the joystick and pull the
trigger on the back side. Push forward to move forward and pull
backward to drive the unit backward.
- To steer the unit: At the top of the joystick there is a rocker switch. Push
the left side of the switch to turn the wheels left and push the right side
of the switch to turn the wheels to the right.
2. Raising and lowering platform – On the platform control station, position
the lift/drive switch to the lift position
- To raise and lower platform – Grab the joystick and squeeze the trigger
on the back side. Pulling the joystick will raise the platform and pushing
the joystick will lower the platform.
3. When unit is not in use – Make sure to push the emergency stop button
when the machine is not in use. This will preserve the battery and avoid any
accidents.
4. Getting power to the platform – If you are using electric tools while in the
air, there is a power outlet on the platform. In order to power the outlet,
you must grab the plug from the front of the machine and plug it into a
power source. This will provide the power to the platform outlet.
5. Switching fuel mode – This unit is equipped with dual fuel capability, letting
you use gas or propane to operate.
