Snorkel S3370RT Operating Instructions

OPERATING INSTRUCTIONS & SPECIFICATIONS
Quick Start Guide
The ground control station and platform control station emergency stop buttons
(RED) must be set to "ON" in order to operate this machine.
1.
Operating from Ground Controls
- Starting Unit – Set the battery switch to the on position. The
emergency stop switch should be pulled out. Set the ground/platform
switch to "ground". If unit is cold, press the glow plug switch down for
no more than 20 seconds. Press and hold the start switch down until
engine starts
- Raising/Lowering the Platform – To raise the platform, press and
hold the Lift/Lower switch up while holding the "enable" switch
down. To lower the platform – press and hold the Lift/Lower switch
down while holding the "enable" switch down
2.
Operating from Platform Controls
- Starting Unit – Set the battery switch to the "on" position. The
emergency stop switch should be pulled out. Set the ground/platform
switch to "platform". Enter the platform and close the gate. If unit is
cold, press the glow plug switch down for no more than 20 seconds.
Press and hold the START switch down until the engine starts.
- Driving the Unit – Set the SPEED switch to turtle (slow) until
comfortable increasing the speed. Set the Lift/Drive selector switch to
DRIVE. Squeeze and hold the Safety Control against the joystick
controller.
To go forward, push the joystick controller forward.
To go in reverse, pull the joystick controller toward you.
Snorkel S3370RT SCISSOR LIFT
