REPAIR PARTS
MANUAL
Part Number 12696B
March 2011
Serial number 000000 and after

Advertisement

Table of Contents
loading

Related Manuals for Snorkel S2770RT

Summary of Contents for Snorkel S2770RT

  • Page 1 REPAIR PARTS MANUAL Part Number 12696B March 2011 Serial number 000000 and after...
  • Page 2 Dealer rental fleet, whichever comes first. Any part or parts which, upon examination by the Snorkel Service Department, are found to be defective, will be replaced or repaired, at the sole discretion of Snorkel, through its local Authorized Dealer at no charge.

  • Page 3: Table Of Contents

    Table of Contents Table of Contents General Specifications Inspection....... . 17 Installation and connection .
  • Page 4 Table of Contents Section 3. - Electrical Section 2. - Hydraulics Electrical Schematic drawing - Auto Level ..3-3 Hydraulic assembly ......2-2 Colour coded wiring circuit .

  • Page 5: General Specifications

    General Specifications General Specifications SR3370 SPECIFICATIONS SR3370 12.12m 39' 2” Nominal working height 1200mm 48” Roll out deck size 0 to 4.5kph 0 to 2.8mph Drive speed (below 2.4m) 0 to 0.35kph 0 to 0.22mph Drive speed (above 2.4m) 450kg 990lbs Safe working load - Main deck...

  • Page 6: General Specifications Sr2770

    General Specifications General Specifications SR2770 SPECIFICATIONS SR2770 10.28m 33' 9” Nominal working height 1200mm 48” Roll out deck size 0 to 4.5kph 0 to 2.8mph Drive speed (below 2.4m) 0 to 0.9kph 0 to 0.6mph Drive speed (above 2.4m) 580kg 1280lbs Safe working load - Main deck...

  • Page 7: Engine Data

    General Specifications Engine Data ENGINE MAKE KUBOTA(gasoline) KUBOTA (LPG) KUBOTA (diesel) Model WG750-G D905-B Fuel gasoline diesel no. 2-D Fuel Grade Unleaded 85 octane ASTM no. 2-D (motor method) Gas Processors ASTM D975 Association Standard centane no. > 44 2140 Do not use gasoline (For operating temp.

  • Page 9: Maintenance Information

    This Maintenance and Repair Parts manual covers operated valves. current production machines only. While Snorkel has attempted in every way to Electrical confirm that all information in this manual is correct, Electrical (Section 3), contains listings and...

  • Page 10: Maintenance Schedules

    - blocked or the weight removed by a suitable lifting device before disconnecting the Maintenance schedules hydraulic hose from the motor/pump unit to the lift Snorkel has established a Preventive Maintenance cylinder. Schedule that includes: When raising a portion of the machine, be sure that Daily Maintenance (Operator’s Inspection)

  • Page 11: Daily Maintenance

    Maintenance Information Daily Maintenance Pre-operational inspection (Set the KEY SWITCH to off before starting this inspection). COMPONENTS SERVICE REQUIRED Fuel level Visually inspect Water separator (diesel engines only) Visually inspect (condition) Fuel leaks Visually inspect (hoses, connections, etc) Engine Oil Check oil level (between dipstick lines) Engine coolant Check fluid level and radiator hoses...

  • Page 12: 90 Day Or 150 Hour Maintenance

    Maintenance Information 90 Day or 150 Hour Maintenance (Trained Service Technician) COMPONENTS SERVICE REQUIRED RECOMMENDED LUBRICANT OR FURTHER INSTRUCTIONS Daily maintenance Perform maintenance as per schedule Preventive inspection Perform inspection, complete form Retain copy of checklist maintenance checklist Placards & decals inspection Inspect using drawing and parts listing Replace any missing or in section 1 (repair parts)

  • Page 13: Lubricants

    The drawing locates the lubrication points of the SR Lubricants Lubrication Specific lubricants as recommended by Snorkel, Refer to the above lubrication drawing for location should be used in maintaining your unit. If in doubt of the following item numbers.

  • Page 14: Engines (Item 5)

    DANGER If questions still remain, contact Snorkel for further Lead-acid batteries contain sulfuric acid information.
  • Page 15 Maintenance Information DANGER Lead-acid batteries produce flammable and explosive gases. NEVER allow smoking, flames or sparks around batteries. SR3370 & SR2770 – 12696B Rev B page 13...

  • Page 16: Preventive Inspection Maintenance

    Maintenance Information Preventive inspection maintenance 90 day or 150 hour checklist OK OK - No Service Required Serial Number Corrective Action Required Corrected, (Record description of corrective action). Inspection Procedures Codes CHECK (1) Weld cracks, dents and/or rust BASE CONTROL STATION (2) Installation Key switch, main power ON - OFF (4) (3) Leaks...
  • Page 17 Maintenance Information CHECK CHECK ENGINE HYDRAULIC RESERVOIR & RETURN FILTER Air filter (5) Translucent hydraulic oil reservoir (3,5) Belts and hoses (5) Filler/breather cap (6) Hydraulic pump (4) Hydraulic fluid level (2,5) Engine oil (5) Return filter (2,5,6) Engine START - STOP (4) Return filter element (5) Electric throttle (4) Engine coolant level (5)

  • Page 18: Torque Chart

    Maintenance Information Torque chart PROPERTY CLASS 8.8 PROPERTY CLASS 10.9 TENSILE STRESS NOM SIZE TORQUE (N.m) TORQUE (N.m) CLAMP CLAMP AREA LOAD LOAD PITCH LUBED LUBED (mm ) k=0.15 k=0.15 k=0.20 k=0.20 x 0.5 5.03 2 200 1.32 0.99 2 990 1.79 1.34 M3.5 x 0.6...

  • Page 19: Servicing Stc Fittings

    NOTE: 5. Check the Back-Up-Ring B to ensure it is An STC release tool kit is available from Snorkel, not damaged. Verify that it is at the front of Part Number 12791K the O-Ring groove prior to reconnecting the fitting.

  • Page 20: Seal Replacement Instructions

    Maintenance Information 2. Align the STC fitting on the hose assembly Inspect to verify proper location of O-Ring in with the STC connector, and push the hose the connector (See Figure 3). Leakage could fitting into the mating STC connector until occur if installed incorrectly.

  • Page 21: Auto Level System Troubleshooting

    Maintenance Information Auto Level System Troubleshooting WARNING If the auto level system fails to level the Incorrect use of the EZcal could lead to machine there could be electrical or safety issues and result in damage to the hydraulic problems. machine.

  • Page 22: Ezcal Auto Level Calibration Procedure

    ACCESS LEVEL 1 NOTE: If none of the above indicates a problem contact 7. Press [RIGHT ARROW] twice to display Snorkel or your local service agent. machine setup The display screen will show: EZcal auto level calibration procedure DANGER...
  • Page 23 Maintenance Information MACHINE SETUP: CALIBRATE LEVEL: CHANGE DEFAULTS YES:ENTER.NO:ESC 9. Press [ENTER] 14. Press [ESC] to abort the calibration or The display screen will show: [ENTER] to proceed with the calibration process. If [ENTER] is selected the display screen DEFAULTS: should show: 1=SR2770 CALIBRATE LEVEL:...

  • Page 24: To Order Service Or Repair Parts

    Maintenance Information To order service or repair parts Manuals When placing an order for service or repair parts, Manuals are available from Snorkel to support any please have the following information available for of the machines that we produce. your machine.

  • Page 25: Section 1. - Repair Parts

    Section 1. - Repair Parts Section 1 Chassis assembly SR3370 ....1-2 Chassis assembly drawing SR3370 ... . 1-3 Chassis assembly drawing SR2770 .

  • Page 26: Chassis Assembly Sr3370

    Chassis assembly SR3370 Chassis assembly SR3370 Item Part No Description 11662-1 Clamp bar 11662-2 Rubber packing 11683 Cover, drive valve 12445 Micro switch 12554-5 Step foldment 12554-6 Rubber step hanger 12566 Sliding block weldment 12566-2 Wear pad, slider block base 12566-3 Wear pad, slider block top 12569...
  • Page 27 Chassis assembly drawing SR3370 TITLE Chassis Assembly Page 1-3 DWG. A16111 Snorkel Model SR3370...
  • Page 28 Chassis assembly drawing SR2770 TITLE Chassis Assembly Page 1-4 Snorkel Model SR2770...

  • Page 29: Chassis Assembly Sr2770

    Chassis assembly SR2770 Chassis assembly SR2770 Item Part No Description 11662-1 Clamp bar 11662-2 Rubber packing 11683 Cover, drive valve 12445 Micro switch 12554-5 Step foldment 12554-6 Rubber step hanger 12566 Sliding block weldment 12566-2 Wear pad, slider block base 12566-3 Wear pad, slider block top 12569...

  • Page 30: Steer Axle Assembly

    Steer axle assembly Steer axle assembly Item Part No. Description 11492-1 Lock tab 11699A Steer cylinder assembly 12555-9 Steer axle, lower plate 12556 Tie rod weld 12558 Steer hub weld, right 12562 Wheel hub front 12563 Wheel tyre assembly, right hand, foam filled 12564 Wheel tyre assembly, left hand, foam filled 12570...
  • Page 31 Steer axle assembly drawing TITLE Steer Axle Assembly Snorkel Models SR3370 Page 1-7 & SR2770...
  • Page 32 Drop axle assembly drawing (FOUR PLACES) TITLE Drop Axle Assembly Snorkel Models SR3370 Page 1-8 & SR2770 February 2007 Revision...

  • Page 33: Drop Axle Assembly

    Drop axle assembly Drop axle assembly Item Part No. Description 11642A Axle cylinder assembly 11794 Mounting bracket, magnetic switch 12557 Swing arm 12557-10 Motor cover 12561 Wheel hub, rear 12563 Wheel tyre assembly, right hand, foam filled 12564 Wheel tyre assembly, left hand, foam filled 12571 Motor, hydraulic braked 12769-1...

  • Page 34: Tray Assembly, Hydraulic And Electrical

    Tray assembly, hydraulic and electrical Tray assembly, hydraulic and electrical Item Part No Description 302-0049 Switch, battery disconnect 2022-005 Clamp 2069 Anti-corrosive pads 3602-06 Hex nut 3603-05 Plain washer 3603-06 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3604-05012 Pan head screw 3605-10 Spring washer 3606-06025...
  • Page 35 Tray assembly, hydraulic and electrical drawing TITLE Tray Assembly, Hydraulic and Electrical, Snorkel Models Page 1-11 SR3370 & SR2770...
  • Page 36 Engine side tray assembly draw ing TITLE Engine Side Tray Assembly Snorkel Models SR3370 Page 1-12 & SR2770...

  • Page 37: Engine Side Tray Assembly

    Engine side tray assembly Engine side tray assembly Item Part No Description 2022-003 Clamp 3603-06 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3605-08 Spring washer 3610-06016 Metric bolt 3610-06020 Metric bolt 3610-08030 Metric bolt 3610-10050 Metric bolt 3610-10055 Metric bolt 3611-06 Nyloc nut 3611-08...

  • Page 38: Cable Operated Emergency Bleed Down Sr3370

    Cable operated emergency bleed down SR3370 Cable operated emergency bleed down SR3370 Item Part No Description 12726 Bleed down handle 12724 Bridge plate 12722 Bleed down cable (short) to lower lift cylinder 12723 Bleed down cable (long) to upper lift cylinder 12722 Bleed down cable (short) lower lift cylinder 12723...
  • Page 39 Cable operated emergency bleed down drawing SR3370 TITLE Cable Operated Emergency Bleed Down Assembly Page 1-15 Snorkel Model SR3370...
  • Page 40 Cable operated emergency bleed down drawing SR2770 TITLE Cable Operated Emergency Bleed Down Assembly Page 1-16 Snorkel Model SR2770 DWG. 00000...

  • Page 41: Cable Operated Emergency Bleed Down Sr2770

    Cable operated emergency bleed down SR2770 Cable operated emergency bleed down SR2770 Item Part No Description 12748 Bleed down handle and cable to lift cylinder 12748 Bleed down cable 3603-06 Plain washer 3605-06 Spring washer 3610-06012 Bolt 12648 Valve lever 3611-06 Nyloc nut 3641-06...

  • Page 42: Scissor Arm Assembly Sr3370

    Scissor arm assembly SR3370 Scissor arm assembly SR3370 Item Part No Description 3603-06 Plain washer 3603-10 Plain washer 3605-06 Spring washer 97563-9 Tek screw 3606-06025 Countersunk socket head screw 3610-06020 Metric bolt 3610-10020 Metric bolt 3610-10025 Metric bolt 3610-10040 Metric bolt 3611-06 Nyloc nut 3611-10...
  • Page 43 Scissor arm assembly drawing SR3370 TITLE Scissor Arm Assembly Snorkel Model SR3370 Page 1-19...
  • Page 44 Scissor arm assembly drawing SR2770 TITLE Scissor Arm Assembly Page 1-20 Snorkel Model SR2770...

  • Page 45: Scissor Arm Assembly Sr2770

    Scissor arm assembly SR2770 Scissor arm assembly SR2770 Item Part No Description 3603-06 Plain washer 3603-10 Plain washer 3605-06 Spring washer 3606-06016 Countersunk socket head screw 3606-06025 Countersunk socket head screw 3610-06020 Bolt 3610-10020 Bolt 3610-10025 Bolt 3610-10040 Bolt 3611-06 Nyloc nut 3611-10 Nyloc nut...

  • Page 46: Outrigger Installation

    Outrigger Installation Outrigger Installation Item Part No Description 11305 Foot weld assembly 11366-1 Stabiliser bush 11366-2 Spacer, stabiliser bush 11369 Pin, foot swivel 12036A Cylinder assembly 11367-2 Pilot check valve 11492-4 Lock tab 12036-4 Microswitch mount plate 12036-5 Sliding spacer 12036-6 Compression spring 12036-7...
  • Page 47 Outrigger Installation - drawing TITLE Outrigger Installation Snorkel Models SR3370 Page 1-23 & SR2770...
  • Page 48 Platform assembly drawing TITLE Platform Assembly Snorkel Models SR3370 Page 1-24 & SR2770...

  • Page 49: Platform Assembly

    Platform assembly Platform assembly Item Part No Description 3603-05 Plain washer 3603-06 Plain washer 3603-08 Plain washer 3603-10 Plain washer 3605-06 Spring washer 3605-08 Spring washer 3606-06025 Metric countersunk screw 3610-05016 Metric bolt 3610-06012 Metric bolt 3610-06016 Metric bolt 3610-08020 Metric bolt 3610-10020 Metric bolt...
  • Page 50 Platform assembly Platform assembly Item Part No Description 9980003 Foam pipe wrap 11695R Handrail latch, right 12700A Upper control box assembly page 1 - 26 Rev B SR3370 & SR2770 – 12696B...

  • Page 51: Fuel Tank Assembly, Diesel Fuel

    Fuel tank assembly, diesel fuel Fuel tank assembly, diesel fuel Item Part No Description 3603-10 Plain washer 3610-10050 Metric bolt 3611-10 Nyloc nut 3618-10 Hose clamp 3618-11 Hose clamp 3618-14 Hose clamp 561706 Tank, 13 gallon 563726 Elbow, male, BSPT 605256 Cap, vented, standard 11955...

  • Page 52: Engine Assembly, Kubota D905

    Engine assembly, Kubota D905 Engine assembly, Kubota D905 Item Part No Description 3040174 Solenoid, 24V 1650-010 Relay, 12V 2022-002 Clamp 2065-002 Plug-in relay base 3603-06 Plain washer 60021-008 3603-10 Plain washer 3605-08 Spring washer 3605-10 Spring washer 3610-06020 Metric bolt 3610-06025 Metric bolt 3610-08020...
  • Page 53 Engine assembly, Kubota D905 drawing TITLE Engine Assembly Kubota D905 Snorkel Models SR3370 & SR2770 Page 1-29...

  • Page 55: Upper Control Box Mounting Assembly

    Upper control box mounting assembly Upper control box mounting assembly Item Part No. Description 3603-06 Plain washer 3605-06 Spring washer 3610-06012 Metric bolt 3610-06020 Metric bolt 3611-06 Nyloc nut 11690-16 Security pin 12749 Wrist support 12750-25 Plug, round 12751 Hand grip, foam 12756 Star washer with end cap 72404...

  • Page 56: Placards And Decals Installation

    Decal, foam tyres 451986 Decal, interlocks 476706 Decal, explosive fumes, (outside cabinet door & fuel tank) 12574 Decal, danger with alarm 569295 Decal, Snorkel logo 560240 Decal, lower control box 12689 Decal, upper control box 560272 Decal, emergency stop upper box 605726...

  • Page 57: Placards And Decals Drawing

    Placards and decals drawing Placards and decals drawing RIGHT HAND SIDE LEFT HAND SIDE REAR END FRONT END SR3370 & SR2770 – 12696B Rev B page 1 - 33...
  • Page 59 Section 2. - Hydraulics Section 2 Hydraulic assembly ......2-2 4 wheel drive hydraulic schematic drawing..2-3 Hose Part Numbers and Colour Codes.

  • Page 60: Hydraulic Assembly

    Hydraulic assembly Hydraulic assembly Item Part No Description 12568A Stabiliser valve block assembly 12568-1 Stabiliser directional valve Item Part No Description 12567A Main manifold valve block assembly 12567-1 Stabiliser divert valve 12567-2 Compensator check 12567-3 Steering flow control 12567-4 Steering directional valve 12567-5 Steering relief shuttle 12567-6...
  • Page 61 NOTE 1: SR3370 = 2200PSI, SR2770 = 2800PSI NOTE 2: Adjustable Flow Control SR3370 CE Units Only TITLE Hydraulic schematic NOTE 3: Main Relief SR3370 = 3200PSI, SR2770 = 3100PSI Snorkel Models SR3370 & SR2770 - (Rev 30/04/08 ->) Page 2-3...

  • Page 63: Hose Part Numbers And Colour Codes

    As such colour 1 is the closest to the fitting, Hose part numbers and colour codes colour 2 the next colour then 3, 4 etc… Snorkel Colour ID Hose Use Part Number...

  • Page 64: Manifold Assembly, Main

    Manifold assembly, main Manifold assembly, main Item Part No Description 12567A Main manifold valve block assembly 12567-1 Stabiliser divert valve 12567-2 Compensator check 12567-3 Steering flow control 12567-4 Steering directional valve 12567-5 Steering relief shuttle 12567-6 Steering pilot check 12567-2 Steering relief check 12567-8 Steering relief valve...

  • Page 65: Manifold Assembly, Main Drawing

    Manifold assembly, main drawing Manifold assembly, main drawing SR3370 & SR2770 – 12696B Rev B page 2 - 7...

  • Page 66: Manifold Assembly, 4 Wheel Drive

    Manifold assembly, 4 wheel drive Manifold assembly, 4 wheel drive Item Part No Description 12569A 4 wheel drive manifold block assembly 12770-350606 Adapter, 90 elbow, 9/16" UNO -> 3/8" STCF 12770-330806 Adapter, straight, 3/4" UNO -> 3/8" STCF 12770-330606 Adapter, straight, 9/16" UNO -> 3/8" STCF 12770-330808 Adapter, straight, 3/4"...

  • Page 67: Manifold Assembly, Stabilisers

    Manifold assembly, stabilisers Manifold assembly, stabilisers Item Part No Description 12568A Stabiliser valve block assembly 12568-1 Stabiliser directional valve 12770-330606 Adapter, straight, 9/16" UNO -> 3/8" STCF 12770-330808 Adapter, straight, 3/4" UNO -> 1/2" STCF SR3370 & SR2770 – 12696B Rev B page 2 - 9...

  • Page 68: Hydraulic Oil Tank Assembly

    Hydraulic oil tank assembly Hydraulic oil tank assembly Item Part No Description 3603-06 Plain washer 3603-10 Plain washer 3610-10050 Metric bolt 3611-06 Nyloc nut 3611-10 Nyloc nut 3618-11 Hose clamp 3618-26 Hose clamp 3618-32 Hose clamp 11430-1 Base plate weld 11430-5 Gasket 11487...

  • Page 69: Hydraulic Oil Tank Assembly Drawing

    Hydraulic oil tank assembly drawing Hydraulic oil tank assembly drawing H Y D R A U C H E L IC F L U F L U ID L E V E U S E L E V P R E IT H M IU P L A...

  • Page 70: Steer Axle Cylinder

    Steer axle cylinder Steer axle cylinder Item Part No. Description 3624-27 Permaglide bush 12770-340406 Adapter, male SAE to female STC 11699 Steer cylinder 12770-330406 Adapter, male SAE to female STC, straight 11699K Seal kit page 2 - 12 Rev B SR3370 &...

  • Page 71: Axle Cylinder

    Axle cylinder Axle cylinder Item Part No. Description 3626-3 Flanged permaglide bush 11368-2 Solenoid valve and coil (Prior to Serial Number NZ070116) 12835-1 Cartridge (from Serial Number NZ070116) 12835-2 Coil (from Serial Number NZ070116) 11642 Axle cylinder 12770-350606 Adapter, Male SAE to female STC, 90 adjustable 11642K Seal kit...

  • Page 72: Main Lift Cylinder Assembly

    Main lift cylinder assembly Main lift cylinder assembly Item Part No Description 3603-06 Plain washer 3605-06 Spring washer 3610-06012 Metric bolt 7031-001 Adaptor, elbow 90 9/16 JICM -> 9/16 UNO 7035-001 Plug 12770-340808 Adaptor, elbow 45 1/12 UNO -> 1/2 STC F 11687 SR lift cylinder 56112-6...

  • Page 73: Section 3. - Electrical

    Section 3. - Electrical Section 3 Electrical Schematic drawing - Auto Level ..3-3 Colour coded wiring circuit ....3-5 Ground control box assembly drawing .
  • Page 74 page 3 - 2 Rev B SR3370 & SR2770 – 12696B...
  • Page 75 P2-9 TILT P2-10 OUTPUT P2-11 SPEED SWITCH GP106 J1.3 (J5R) HIGH OUTPUT OUTRIGGER VALVES A X L E S W I T C H S TITLE Electrical Schematic, Standard, Auto Level, Snorkel Models Page 3-3 Revision C SR3370 & SR2770...

  • Page 77: Colour Coded Wiring Circuit

    +12V Out RED/BLACK Run Solenoid (Hold) Run Solenoid (Pull) BLACK Run Solenoid Earth Run Solenoid (Pull) Starter Solenoid Glow Plug Temperature Sender Engine Casting TITLE Colour Coded Wiring Circuit Snorkel Models 12815-3 Revision B SR3370, SR2770 & SR2255 Page 3-5...
  • Page 78 Ground control box assembly drawing CLIP OUT FOR GAS CLIP OUT ONLY FOR DUAL FUEL DUAL FUEL DUAL FUEL ONLY CLIP OUT FOR LP ONLY TITLE Ground control box assembly Snorkel Models SR3370 Page 3-6 & SR2770...

  • Page 79: Ground Control Box Assembly

    Ground control box assembly Ground control box assembly Item Part No Description 560351 Ground control box assembly, Kubota D905 diesel units 560222 Ground box (see page 3 - 8) 560240 Decal, ground control 3040068 Circuit breaker 20 amp 3044167 Terminal #10 spade 16/14 wire SR3370 &...

  • Page 80: Ground Box

    Ground box Ground box Item Part No Description 560222 Ground box, complete 560229 Ground electrical box 560224 Alarm board/daughter board 560223 Relay board/mother board 3020013 Switch, toggle 446836 Switch, push/pull emergency stop, CE only 446826 Contact block, CE only 3020015 Switch, toggle 3020016 Switch, toggle...
  • Page 81 Ground box drawing - sheet 1 TITLE Ground Box, Sheet 1 Snorkel Models SR3370 & SR2770 Page 3-9...
  • Page 82 Ground box drawing - sheet 2 TITLE Ground Box Sheet 2 Snorkel Models SR3370 Page 3-10 & SR2770...

  • Page 84: Platform Control Box Assembly

    Platform control box assembly Platform control box assembly Item Part No Description 560221 Platform control box assembly 560228 Platform control box 560332 Switch, push button 560225 Joystick controller 560376 Internal wire harness 446836 Switch, push/pull emergency stop 0070967 Corrosion inhibitor 3020097 Switch, toggle 560377...

  • Page 85: Sheet 1

    Platform Control Box Assembly drawing Sheet 1 AUTO STOW AUTO LEVEL lb lb TITLE Platform Control Box Assembly Sheet 1, Snorkel Models SR3370 & SR2770 Page 3-13...
  • Page 86 INPUT FROM JSR (JS 15) ONLY IF LOWER PLATFORM SWITCH IS MADE! NOTE: JS 18 T’S IN CONTROL CABLE TO J1.6 AND J12.1 JS 7 JS 10 TITLE Platform Control Box Assembly Sheet 2, Snorkel Models Revised 16-08-2006 Page 3-14 SR3370 & SR2770...

  • Page 87: Section 4. - Options

    Section 4. - Options Section 4 AC outlet at platform, 230 volt ....4-2 Flashing light installation ..... 4-3 Fuel gauge option .

  • Page 88: Ac Outlet At Platform, 230 Volt

    AC outlet at platform, 230 volt AC outlet at platform, 230 volt Item Part No Description 10967-3 PDL enclosure 10967-1 Residual current device (with appliance inlet pins) 1814 M20 nylon cable gland 10967-2 Appliance inlet 2500-014 Switch outlet 1812 3 core x 1.5 tpe flex cable RIGHT-HAND SIDE TOE BOARD DECK...

  • Page 89: Flashing Light Installation

    Flashing light installation Flashing light installation Item Part No Description 3610-06016 Bolt 12034 Guard, strobe light 3604-05020 Screw, pan head 3603-05 Plain washer 1866-003 Strobe, amber 1866-002 Bracket, strobe light 3611-05 Nyloc nut 3603-06 Plain washer 3611-06 Nyloc nut 3605-06 Spring washer SR3370 &...

  • Page 90: Fuel Gauge Option

    Fuel gauge option Fuel gauge option Item Part No Description 11507 Fuel gauge option 11430-9 Top plate fuel tank 0070483 Fuel gauge 11430-5 Gasket 11430-1 Base plate weld 3611-06 Nylock nut page 4 - 4 Rev B SR3370 & SR2770 – 12696B...
  • Page 91 Parts index - Page locator 230 Volt AC outlet at platform, 4-2 AC outlet at platform, 230 volt AC, 4-2 Decal and placards installation, 1-32 Gradeability, 2-3, 2-4 Ground clearance, 2-3, 2-4 Ground control box assembly, 3-7 Insulation rating, 2-3, 2-4 Joystick controller, 3-12 Key switch, 3-8 Lift time, 2-3, 2-4...
