INSTALLATION AND SERVICE MANUAL
separated combustion gas-fired unit heaters
All models approved for use in California by the CEC and
in Massachusetts. Unit heater is certified for residential and
commercial applications.
Inspection on Arrival
1. Inspect unit upon arrival. In case of damage, report it
2. Check rating plate on unit to verify that power supply meets
3. Inspect unit upon arrival for conformance with description of
Table of Contents
Inspection on Arrival . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Special Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
SI (Metric) Conversion Factors. . . . . . . . . . . . . . . . . . . . . . . . . 3
Before you Begin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Unit Location. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Unit Components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Dimensions. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Service/Troubleshooting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Unit Wiring Diagram . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
Serial/Model Number/Replacement Parts . . . . . . . . . . . . . . . 22
Commercial Warranty. . . . . . . . . . . . . . . . . . . . . . . . Back Cover
THIS MANUAL IS THE PROPERTY OF THE OWNER.
model HDS and HDC
FOR YOUR SAFETY
The use and storage of gasoline or other
flammable vapors and liquids in open containers
in the vicinity of this appliance is hazardous.
IMPORTANT
The use of this manual is specifically intended
for a qualified installation and service agency.
All installation and service of these units must
be performed by a qualified installation and
service agency.
immediately to transportation company and your local
Modine sales representative.
available electric power at the point of installation.
product ordered (including specifications where applicable).
Combustible Material and Service Clearances . . . . . . . . . 4
Unit Mounting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Venting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Gas Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
High Altitude Accessory Kit . . . . . . . . . . . . . . . . . . . . . 13-14
Electrical . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15-16
Operation. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
6-584.12
5H0800020000
April 2018

Advertisement

loading
Need help?

Need help?

Do you have a question about the HDS Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Modine Manufacturing HDS Series

  • Page 1 6-584.12 5H0800020000 April 2018 INSTALLATION AND SERVICE MANUAL separated combustion gas-fired unit heaters model HDS and HDC All models approved for use in California by the CEC and in Massachusetts. Unit heater is certified for residential and commercial applications. FOR YOUR SAFETY The use and storage of gasoline or other flammable vapors and liquids in open containers in the vicinity of this appliance is hazardous.
  • Page 2: Special Precautions

    SPECIAL PRECAUTIONS SPECIAL PRECAUTIONS THE INSTALLATION AND MAINTENANCE INSTRUCTIONS IN THIS CAUTION MANUAL MUST BE FOLLOWED TO PROVIDE SAFE, EFFICIENT AND TROUBLE-FREE OPERATION. IN ADDITION, PARTICULAR CARE MUST BE EXERCISED REGARDING THE SPECIAL 1. All literature shipped with this unit should be kept for PRECAUTIONS LISTED BELOW.
  • Page 3: Before You Begin

    SPECIAL PRECAUTIONS / SI (METRIC) CONVERSION FACTORS BEFORE YOU BEGIN CAUTION CAUTION 18. The unit should be isolated from the gas supply piping system by closing its field installed manual shut-off valve. 1. All literature shipped with this unit should be kept for future This manual shut-off valve should be located within 6' of use for servicing or service diagnostics.
  • Page 4: Unit Location

    UNIT LOCATION UNIT LOCATION Table 4.1 - Clearances DANGER Clearance to Recommended Service Unit Side Combustible Material Clearance Appliances must not be installed where they may be exposed to a potentially explosive or flammable atmosphere. HDS/HDC Top and Bottom 1" 6"...
  • Page 5: Unit Mounting

    UNIT MOUNTING Figure 5.2 - Unit Heater Turned 180° (30-75 units only) CAUTION (Access panel and heated air outlet change sides) 1. Do not install units below 7' measured from the bottom of the unit to the floor in commercial applications (unless unit is properly guarded to provide user protection from moving parts) and 5' measured from the bottom of the unit to the floor in residential applications.
  • Page 6: Installation - Venting

    INSTALLATION - VENTING A4. Refer to Table 6.1 for total equivalent vent pipe lengths, WARNING making the vent system as straight as possible. The equivalent length of a 3” elbow is 1’ and for a 4” elbow is 5’. 1. Gas fired heating equipment must be vented - do not Table 6.1 - Vent Pipe Diameters, Transitions, and operate unvented.
  • Page 7 INSTALLATION - VENTING A10. When the vent passes through a combustible INTERIOR A14. Do NOT vent this appliance into a masonry chimney. wall or floor, a metal thimble 4" greater than the vent A15. Do NOT use dampers or other devices in the vent or diameter is necessary.
  • Page 8: Section B - Vertical 2-Pipe Vent System Installation

    INSTALLATION - VENTING Section B – Vertical 2-Pipe Vent System Table 8.1 - Minimum Height from Roof to Lowest Installation Discharge Opening Rise X (in) Roof Pitch Min Height H (ft) j B1. This section applies to vertically vented 2-pipe (one Flat to 6/12 1.00 combustion air inlet pipe and one vent pipe) vent systems...
  • Page 9: Section C - Horizontal 2-Pipe Vent System Installation

    INSTALLATION - VENTING Section C – Horizontal 2-Pipe Vent System C10. Maintain a 1/4" per foot downward slope away from the heater and place a drip leg with clean out near the exit of Installation the vent as shown in Figure 9.1, or allow the condensate C1.
  • Page 10: Section D - Concentric Vent System Installation

    INSTALLATION - VENTING Section D – Concentric Vent System CAUTION Installation D1. This section applies to both horizontally and vertically The concentric vent adapter box must be installed inside of vented concentric vent systems as defined in “Section A – the structure or building.
  • Page 11 INSTALLATION - VENTING Table 11.1 - Concentric Vent Pipe Sizes D9. Slide the combustion air pipe over the vent pipe and attach to the air inlet of the concentric adapter box, as shown Single Wall Pipe Type B Vent Pipe j in Figure 11.1, using at least 3 corrosion-resistant sheet metal screws.
  • Page 12: Gas Connections

    INSTALLATION - GAS CONNECTIONS GAS CONNECTIONS Figure 12.1 - Recommended Sediment Trap/Manual Shut-off Valve Installation - Side or Bottom Gas WARNING Connection 1. All field gas piping must be pressure/leak tested prior to operation. Never use an open flame. Use a soap solution or equilavent for testing.
  • Page 13 INSTALLATION - HIGH ALTITUDE ACCESSORY KIT HIGH ALTITUDE ACCESSORY KIT Manifold Pressure Adjustment The inlet pressure to the unit must be confirmed to be within Modine’s gas-fired equipment standard input ratings are acceptable limits (6-7" W.C. for natural gas and 11-14" W.C. for certified by ETL.
  • Page 14 INSTALLATION - HIGH ALTITUDE ACCESSORY KIT If the heating value of the gas being supplied is different than the values shown in Tables 13.1 and 13.2, use the following equation to determine the appropriate manifold pressure for the altitude and gas heating value being supplied. Equation 14.1 - Manifold Pressure for Derated Gas WHERE: = Manifold Pressure (in.
  • Page 15: Installation - Electrical Connections

    INSTALLATION - ELECTRICAL CONNECTIONS ELECTRICAL CONNECTIONS 9. Separated combustion models include a factory installed on/ off toggle switch. The function of this switch is to disconnect W ARNING power to the unit for maintenance or to shut the unit off in warm weather.
  • Page 16 INSTALLATION - ELECTRICAL CONNECTIONS Blower Curve Models (HDC 60-125 Only) ELECTRICAL CONNECTIONS Speeds Location of thermostat should be determined by heating requirements and be mounted on an inside wall about 5' above floor level where it will not be affected by heat from the unit Medium High or other sources, or drafts from frequently opened doors.
  • Page 17: Operation

    INSTALLATION - OPERATION OPERATION 9. Check that all horizontal deflector blades are open a minimum of 30° as measured from vertical. IMPORTANT 10. Turn on power to the unit at the disconnect switch. 11. Check the thermostat, ignition control, gas valve, and supply fan blower motor for electrical operation.
  • Page 18: Control Operating Sequence

    CONTROL OPERATING SEQUENCE / UNIT COMPONENTS CONTROL OPERATING SEQUENCE Upon a call for heat from the thermostat, power is supplied to already started it will start shortly. If a flame is not sensed for the power exhauster motor. The unit will go through a purge any reason the main valve will close and there will be a short period and then the direct spark igniter will be energized.
  • Page 19 DIMENSIONS / GENERAL PERFORMANCE DATA - HDS/HDC Figure 19.1 - Dimensional Drawings 13.5" BETWEEN 3/8"-16 MOUNTING HOLES 14.9" BETWEEN 3/8"-16 MOUNTING HOLES (MODEL SIZES 100 AND 125 ONLY) (MODEL SIZES 100 AND 125 ONLY) 10.0" 3.5" Table 19.1 - Dimensions (inches) Propeller Model Size - HDS Blower Model Size - HDC Dimension...
  • Page 20 SERVICE / MAINTENANCE / TROUBLESHOOTING 1. Service air moving components annually. WARNING a. Check fan for fit on motor shaft and for damage to blades. 2. Keep unit free from dust, dirt, grease, and foreign matter, When servicing or repairing this equipment, use only factory- paying particular attention to: approved service replacement parts.
  • Page 21: Unit Wiring

    UNIT WIRING Wiring Diagram Selection Since internal or factory wiring may vary depending on type. The following wiring diagram represents a unit equipped the controls manufacturer, the wiring diagrams must be with a single stage gas valve, and direct spark ignition. appropriately selected with the proper gas valve and ignition Figure 21.1 - Unit Heater Wiring Diagram (Single and Two Stage, Direct Spark Ignition) GR, (G)
  • Page 22: Serial & Model Number / Replacement Parts

    SERIAL & MODEL NUMBER / REPLACEMENT PARTS Figure 22.1 - Model Number Designations (Remove access cover to locate) HDS 45 HDS - Tubular Separated Factory Installed Option Digit Combustion Propeller Unit N - None HDC - Tubular Separated Combustion Blower Unit Future A - All MBH Input...
  • Page 23 THIS PAGE INTENTIONALLY LEFT BLANK 6-584.12...
  • Page 24: Commercial Warranty

    Vertical Unit Ventilators, Ventilators, Geothermal Units EIGHTEEN MONTHS FROM DATE OF SHIPMENT FROM SELLER, WHICHEVER OCCURS FIRST Burners High Intensity Infrared Units Sheet Metal Parts All Products Modine Manufacturing Company 1500 DeKoven Avenue Racine, WI 53403 Phone: 1.800.828.4328 (HEAT) www.modinehvac.com © Modine Manufacturing Company 2018...
  • Page 25: Table Of Contents

    6-584.12 5H0800020000 Avril, 2018 MANUEL D'INSTALLATION ET DE MAINTENANCE appareils de chauffage alimentés au gaz à combustion séparée modèles HDS et HDC Tous les modèles approuvés pour une utilisation en Californie par le CEC et au Massachusetts. L'appareil de chauffage est certifié pour des applications résidentielles et commerciales.
  • Page 26: Précautions Particulières

    PRÉCAUTIONS PARTICULIÈRES PRÉCAUTIONS PARTICULIÈRES ATTENTION LES INSTRUCTIONS D'INSTALLATION ET D'ENTRETIEN DE CE MANUEL DOIVENT ÊTRE RESPECTÉES POUR ASSURER UN FONCTIONNEMENT SÉCURITAIRE, EFFICACE ET SANS PROBLÈMES. IL CONVIENT ÉGALEMENT DE RESPECTER RIGOUREUSEMENT LES PRÉCAUTIONS PARTICULIÈRES 1. Toute la documentation livrée avec l'appareil doit être conservée pour CI-APRÈS.
  • Page 27: Facteurs De Conversion Métrique (Si)

    PRÉCAUTIONS PARTICULIÈRES / FACTEURS DE CONVERSION SI (SYSTÈME MÉTRIQUE) / EMPLACEMENT D'INSTALLATION AVANT DE COMMENCER ATTENTION ATTENTION 18. L'appareil doit pouvoir être isolé de la conduite d'alimentation en gaz par la fermeture d'un robinet d'arrêt manuel posé à l'installation. Ce 1.
  • Page 28: Emplacement D'installation

    EMPLACEMENT D'INSTALLATION EMPLACEMENT D'INSTALLATION Tableau 4.1 - Dégagements DANGER Dégagement Distance minimum recommandé pour la Les appareils ne doivent pas être installés à un endroit où ils risquent Côté appareil des matières combustibles maintenance d'être exposés à une atmosphère potentiellement explosive ou inflammable.
  • Page 29: Montage De L'appareil

    MONTAGE DE L'APPAREIL Figure 5.2 – Appareil tourné de 180° (modèles 30-75 seulement) ATTENTION (Panneau d'accès et sortie d'air réchauffé changent de côté) 1. Dans le cas d'applications commerciales, les appareils ne doivent pas être installés à une hauteur de moins de 2,1 m (7 pi), mesurée entre le dessous et le plancher (à...
  • Page 30 INSTALLATION – ÉVACUATION A4. Pour les longueurs totales de tuyau d'évacuation équivalentes, en AVERTISSEMENT créant le système d'évacuation le plus droit possible, voir le tableau 6.1. The equivalent length of a 3” elbow is 1’ and for a 4” elbow is 5’. Tableau 6.1 - Diamètres de tuyau d'évacuation, transitions et 1.
  • Page 31 INSTALLATION – ÉVACUATION inférieur à 204 °C (400 °F). Installez un raccord en té au point bas du A14. Cet appareil ne doit PAS être relié à une cheminée en maçonnerie. système de ventilation et fournissez un collecteur de condensats avec A15.
  • Page 32 INSTALLATION – ÉVACUATION Section B – Installation d'un système d'évacuation Tableau 8.1 – Hauteur minimale de l'orifice de sortie le plus bas verticale à 2 tuyaux au-dessus du toit B1. Cette section s'applique aux systèmes d'évacuation des gaz à 2 tuyaux Hauteur X (po) Pente du toit Hauteur min.
  • Page 33: Ventilation

    INSTALLATION – ÉVACUATION Section C – Installation d'un système d'évacuation C10. Maintenez une pente de 1/4 po par pied à l'écart de l'appareil de chauffage et placez une purge avec regard de nettoyage près de la horizontal à 2 tuyaux sortie de l'évacuation, comme illustré...
  • Page 34 INSTALLATION – ÉVACUATION Section D – Installation d'un système d'évacuation ATTENTION des gaz concentrique D1. Cette section s'applique aux systèmes d'évacuation des gaz La boîte adaptatrice concentrique doit être installée à l'intérieur de la concentriques horizontaux et verticaux tels que définis dans la structure ou du bâtiment.
  • Page 35 INSTALLATION – ÉVACUATION D9. Glissez le tuyau d'air de combustion sur le tuyau d'évacuation et D14. Installez le tuyau d'évacuation et le tuyau d'air de combustion entre attachez-les à la prise d'air de la boîte adaptatrice d'évacuation l'appareil de chauffage et la boîte adaptatrice concentrique, comme concentrique (figure 11.1), à...
  • Page 36: Raccordements Au Gaz

    INSTALLATION – RACCORDEMENTS DE GAZ RACCORDEMENTS DE GAZ Figure 12.1 - Installation recommandée : piège à sédiments et robinet d'arrêt manuel – Pour un raccordement latéral ou par AVERTISSEMENT le bas ARRIVÉE DE GAZ 1. Toutes les tuyauteries de gaz extérieures doivent être soumises à des essais de pression et d'étanchéité...
  • Page 37: Ensemble D'accessoires Pour Haute Altitude

    INSTALLATION – ENSEMBLE D'ACCESSOIRES POUR HAUTE ALTITUDE ENSEMBLE D'ACCESSOIRES POUR HAUTE ALTITUDE Régler de pression au collecteur La pression d'arrivée dans l'appareil doit être confirmée dans les limites Les valeurs nominales d'entrée standard des appareils au gaz de Modine acceptables (6 à 7 po C.E. pour le gaz naturel et 11 à 14 po C.E. pour le sont certifiés par ETL.
  • Page 38 INSTALLATION – ENSEMBLE D'ACCESSOIRES POUR HAUTE ALTITUDE Si la valeur de chauffage du gaz fourni est différente des valeurs des tableaux 13.1 et 13.2, utilisez l'équation suivante pour déterminer la pression appropriée au collecteur pour l'altitude et la valeur de chauffage du gaz fourni.
  • Page 39: Raccordements Électriques

    RACCORDEMENTS ÉLECTRIQUES AVERTISSEMENT 1. Débranchez l'alimentation avant d'effectuer des branchements pour éviter tout risque d'électrocution et d'endommagement de l'appareil. 2. Tous les branchements et câblages doivent être faits en stricte conformité avec le schéma fourni avec l'appareil. Tout câblage différent de celui du schéma peut créer des risques de dommages matériels ou de blessures.
  • Page 40 INSTALLATION – BRANCHEMENTS ÉLECTRIQUES Courbe de soufflante, modèles HDC 60-125 seulement RACCORDEMENTS ÉLECTRIQUES Vitesses Le thermostat de commande sera installé en fonction des besoins de chauffage, sur une cloison intérieure à environ 1,5 m (5 pi) au-dessus Basse Moyenne Haute du plancher et de façon à...
  • Page 41: Mode D'emploi

    INSTALLATION – FONCTIONNEMENT FONCTIONNEMENT 10. Mettez l'appareil sous tension au niveau du sectionneur. 11. Vérifiez le thermostat, l'allumeur, le robinet de gaz, puis mettez la soufflante Avant la mise en service sous tension. Si le fonctionnement n'est pas normal, revérifiez avec le schéma de câblage.
  • Page 42: Éléments Constitutifs

    SÉQUENCE FONCTIONNELLE DE SYSTÈME DE COMMANDE SÉQUENCE FONCTIONNELLE DE SYSTÈME DE COMMANDE Lorsque le thermostat détecte une demande de chaleur, le moteur de la il démarrera peu après. Si une flamme n'est pas détectée (pour une raison soufflante d'extraction démarre. L'appareil effectue un cycle de purge avant quelconque), la soupape principale se referme et l'appareil effectue un bref que l'allumeur direct par étincelle soit mis sous tension.
  • Page 43: Dimensions

    DIMENSIONS ET PERFORMANCES GÉNÉRALES – HDS/HDC Plans cotés Figure 19.1 - TROUS DE MONTAGE 34,3CM ENTRE LE 3/8"-16 TROUS DE MONTAGE 37,8CM ENTRE LE 3/8"-16 TROUS DE MONTAGE TYPE 9,5 x 25 mm (MODÈLE TAILLE 100 ET 125 SEULEMENT) (MODÈLE TAILLE 100 ET 125 SEULEMENT) SUPPORTS (3/8 po X 1 po) LONG DE FIXATION...
  • Page 44: Maintenance/Dépannage

    ENTRETIEN – MAINTENANCE – DÉPANNAGE AVERTISSEMENT 1. Entretien annuel des composants de transport de l'air. a. Vérifiez que l'hélice du ventilateur est bien fixée sur l'arbre du moteur et que ses pales ne sont pas endommagées. 2. L'appareil doit être nettoyé de toute accumulation de poussière, saleté, Pour l'entretien et les réparations de cet appareil, n'utiliser que des graisse et matières étrangères, avec une attention particulière portée pièces d'origine certifiées.
  • Page 45: Schéma De Câblage De L'appareil

    CÂBLAGE DE L'APPAREIL Choix du schéma de câblage Le câblage interne ou posé en usine et le câblage dépend du modèle Le schéma suivant est celui d'un appareil équipé d'un régulateur à un de contrôleur installé et il est important de choisir les schémas qui étage, avec allumage direct à...
  • Page 46: Numéro De Série/Modèle Et Pièces De Rechange

    NUMÉRO DE SÉRIE ET DE MODÈLE ET PIÈCES DE RECHANGE Figure 22.1 - Composition du numéro de modèle (ouvrir le panneau d'accès) HDS 45 HDS - Ventilateur axial à combustion Chiffre d'option installée à l'usine séparée tubulaire N - Aucun HDC - Soufflante à...
  • Page 47 PAGE VIERGE 6-584.12...
  • Page 48: Garantie Commerciale

    Modèles infrarouges de haute intensité Pièces en tôle Tous les produits Comme la Modine Manufacturing Company a un programme d'amélioration permanente de ses produits, elle se réserve le droit de modifier la conception et les caractéristiques techniques sans préavis. Modine Manufacturing Company...
