HOME OWNERS INSTRUCTIONS & OPERATING MANUAL
Packing Check list
Package 1
1 off
1 off
1 off
1 off
1 off
This appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience and knowledge if they have been given supervision
or instruction concerning use of the appliance in a safe way and understand the hazards involved!
Children shall not play with the appliance!
Cleaning and user maintenance shall not be made by children without supervision.
Children of less than 3 years should be kept away unless continuously supervised.
Children aged from 3 years and less than 8 years shall only switch on/off the appliance provided that it
has been placed or installed in its intended normal operation position and they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
Children aged from 3 years and less than 8 years shall not plug in, regulate and clean the appliance or
perform user maintenance.
BFM EUROPE LTD
FLAMONIK ENCHANT & RAPTURE ELECTRIC FIRE
Model No.: B-160940 & B-160940-1 & B-160950
Article No.: MH36BLC/P & MH36MR & MH27BLC/P
Electric fire
Remote control handset and battery
Instructions manual and fixing kit
Coal fuel bed or crystal beads (depending on model)
Fascia
IMPORTANT
Page 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Celsi B-160940
Summary of Contents for Celsi B-160940
- Page 1 HOME OWNERS INSTRUCTIONS & OPERATING MANUAL FLAMONIK ENCHANT & RAPTURE ELECTRIC FIRE Model No.: B-160940 & B-160940-1 & B-160950 Article No.: MH36BLC/P & MH36MR & MH27BLC/P Packing Check list Package 1 1 off Electric fire 1 off Remote control handset and battery...
-
Page 2: Important Instructions
WALL-MOUNTED ELECTRIC FIREPLACE/HEATER IMPORTANT INSTRUCTIONS PLEASE READ THE INSTRUCTIONS CAREFULLY BEFORE INSTALLATION AND/OR USE OF THIS ELECTRIC FIRE AND RETAIN FOR FUTURE REFERENCE. WHEN USING ELECTRICAL APPLIANCE, BASIC PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND INJURY TO PERSONS, INCLUDING THE FOLLOWING IMPORTANT SAFETY ADVICE. - Page 3 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER IMPORTANT INSTRUCTIONS DO NOT cover the heater. The meaning of figure is “WARNING! DO NOT COVER”. This is to avoid over-heating of the product. DO NOT leave the heater unattended while it is in use. Always turn the appliance to the OFF position and unplug it from the electrical outlet when not in use.
-
Page 4: Installation Preparation
WALL-MOUNTED ELECTRIC FIREPLACE/HEATER INSTALLATION PREPARATION CAUTION: This carton includes a GLASS panel! Always use extreme caution when handling glass. Failure to do so could result in personal injury or property damage. PRODUCT SPECIFICATION Voltage…………………………………230 V AC, 50Hz Total Watts……………………………1.8kW (2X900 Watts) Fire Dimensions Rapture 27”... - Page 5 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER INSTALLATION PREPARATION WANING! DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER. IMMEDIATELY CALL A QUALIFIED SERVICE TECHNICIAN TO INSPECT AND TO REPLACE ANY PART OF THE ELECTRICAL SYSTEM IF NECESSARY. · Open the packaging carefully and remove the foam. ·...
-
Page 6: Installation Instructions
WALL-MOUNTED ELECTRIC FIREPLACE/HEATER INSTALLATION INSTRUCTIONS Step 1: Using a screwdriver loosen the two screws that secure the wall mounting bracket to the top of the appliance and remove the wall mounting bracket as shown below (Figure 1). Figure 1 Step 2: Choose a solid and plain wall. Position the mounting bracket where the appliance is to be installed on the wall and ensure that the bracket is level. - Page 7 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER INSTALLATION INSTRUCTIONS Step 4: Fix the mounting bracket using the four screws supplied (Figure 4). Step 5: Hang the appliance on the hooks at the bottom of the bracket and push the top of the appliance into the mounting bracket. Now fix the appliance to the mounting bracket by refitting the two M4×8 screws which were removed in step 1(Figure 5).
- Page 8 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER INSTALLATION INSTRUCTIONS Step 7: Fit the appliance front fascia by locating the two tabs into the slots on top of the electric fire as shown below . (Figure 6) Secure the fascia in place at both sides using the two supplied screws. Figure 6 NOTE: Removal of the electric fire is carried out by following the previous steps in reverse order.
- Page 9 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER OPERATING INSTRUCTIONS The Fireplace/Heater Unit On the top right side plate of the fireplace/heater unit is the control panel. This panel contains the buttons to properly operate the fireplace/heater unit. Refer to below figure for placement of the control buttons.
- Page 10 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER Lock or unlock heat function mode: When the Main Power button is on, pressing and holding this H_heat Control button 10 seconds to enter heating function locked mode, the fuel bed lights will flicker 6 times. Then every time you press the button, there are 6 times flash only the fuel bed lights but no heating function in this mode.
- Page 11 WALL-MOUNTED ELECTRIC FIREPLACE/HEATER 3. The battery has two sides, one with a button feature, and the other is flat. 4. Insert the battery the button side into the remote control, and make sure the battery is firmly seated. 5. Reinstall the battery cover, making sure it clicks into position. 6.
-
Page 12: Maintenance Instructions
WALL-MOUNTED ELECTRIC FIREPLACE/HEATER These remote control buttons work exactly the same as the buttons on the front panel of the fireplace/heater. See the FIREPLACE/HEATER section above to review the side plate panel button functions, and familiarize yourself with the remote control. NOTE: Whatever the heat function is on or off,when you press the low heat button or the high heat button,the uplights will flash one time at 0.3 second interval. -
Page 13: Quality Guarantee
WALL-MOUNTED ELECTRIC FIREPLACE/HEATER QUALITY GUARANTEE BFM EUROPE LTD GORDON BANKS DRIVE, TRENTHAM LAKES STOKE-ON-TRENT ST4 4TJ Technical Queries: 01782 339039 Service Fault Enquiries: 01782 339008 Please note there are no user replaceable parts on this appliance. Issue 2 BFM EUROPE LTD Page 13... - Page 14 Check out our full range of Heating Products Central Heating Controls Honeywell Heating Controls Danfoss Heating Controls Radiator Valves Fernox Sentinel Magnaclean Warmup underfloor heating Water Heaters Hand Dryers...
