INSTALLATION INSTRUCTIONS
Before you start please read the instructions.
Planning your installation will save you time and effort.
FAILURE TO INSTALL APPLIANCES CORRECTLY IS DANGEROUS AND
COULD LEAD TO PROSECUTION.
Please take care when handling - we recommend the use of protective gloves during
installation.
Installation should only be carried out by a qualified installer or engineer. We
recommend that the appliance is connected by a competent person who is a member of
a "Competent Person Scheme" who will comply with the required local regulations.
Our policy is one of constant development and improvement, therefore we cannot
guarantee the strict accuracy of all of our illustrations and specifications. Changes may
have been made subsequent to publishing.
Please keep to the following points most carefully;
Although every care has been taken to ensure this appliance has no burrs, or sharp
edges, we recommend that you wear protective gloves when installing and moving
this appliance. This will prevent injury.
Ensure that you route all mains cables well clear of any adjacent heat source.
Installations should be carried out in line with the National Regulations applicable for
this product type.
Please ensure that the user has this copy of the handbook, and the appliance is in
place.
Leisure 602DITC LPG
Part Number: 083737901
Date: 02/08/19
Advertisement
Related Manuals for Belling Leisure 602DITC
Summary of Contents for Belling Leisure 602DITC
- Page 1 Installations should be carried out in line with the National Regulations applicable for this product type. Please ensure that the user has this copy of the handbook, and the appliance is in place. Leisure 602DITC LPG Part Number: 083737901 Date: 02/08/19...
-
Page 2: Regulations And Standards
REGULATIONS AND STANDARDS Prior to installation, ensure that the local distribution conditions (nature of the gas and gas pressure) and the adjustment of the appliance are compatible. The adjustment conditions are stated on the data badge. This appliance is not connected to a combustion evacuation device. It shall be installed and connected in accordance with current installation regulation. - Page 3 Outside the UK, refer to National regulations of the country of installation. In the Republic of Ireland, refer to relevant Irish Standards for correct ventilation requirements. Important: • Do not allow the weight of the appliance to be carried on the fixing holes in the front frame. •...
-
Page 4: Installation Dimensions
INSTALLATION Installation dimensions min 570 mm 602DITC min 560 mm 602 - 604mm DITC - 745 mm 560 mm 552 mm 140 mm Batten Dimensions (50 mm x 25 mm) 530 mm All sizes are nominal, and some variation is to be expected. The ‘depth’ of the cooker, as given, is to the front of the fascia panel and excluding knobs and handles. - Page 5 600 mm 90 mm 90 mm 450 mm 650 mm...
-
Page 6: Connect To The Electricity Supply
CONNECT TO THE GAS / ELECTRICITY SUPPLY Connect to the gas supply Important: • Rigid pipe work must be used for this installation. • The 10mm bundy inlet connection is located at the base of the appliance. Other inlet sizes may be fitted at the customers request or to suit the country of destination.
