- Page 1 600W PORTABLE POWER STATION MODEL NO: PPS600 PART NO: 8877140 OPERATING & MAINTENANCE INSTRUCTIONS ORIGINAL INSTRUCTIONS DL0924...
-
Page 2: Environmental Recycling Policy
INTRODUCTION Thank you for purchasing this CLARKE Portable Power Station. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety
5. DO NOT use any unofficial components or accessories. For replacement of any part or accessory, contact your CLARKE Parts & Service department listed at the bottom of this page. 6. When using the power station, strictly abide by the ambient temperature specified in this manual. -
Page 4: Overview - Rear
OVERVIEW - REAR NO DESCRIPTION NO DESCRIPTION DC Input Charging Port AC 230V Output Socket Battery Rescue Charging Port AC Output Socket ON/OFF Switch Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 5: Overview - Front
OVERVIEW - FRONT NO DESCRIPTION NO DESCRIPTION LED Light 2 x USB-A (DC 5V/3.1A) Socket LED Light ON/OFF Switch 10 DC 12V Car Type Socket LCD Screen ON/OFF Switch 11 DC USB Type C (PD 60W) Socket LCD Screen 12 DC Output Sockets ON/OFF Switch Parts &... -
Page 6: Lcd Display Overview
LCD DISPLAY OVERVIEW NO DESCRIPTION NO DESCRIPTION Power Station Failure - Overheat, Load Status Display Overload, Short Circuit Battery Run Time/Time to Full 10 Load Power Charge Battery 11 AC Output Voltage Battery High and Low 12 DC Output Temperature Fault Charge Icon 13 AC Output Charge Power... -
Page 7: Lcd Display Descriptions
LCD DISPLAY DESCRIPTIONS Icon No. Icon Fault Description and Handling Methods Inverter Fault Icon. Displayed when fault occurs (including: short circuit, overload, under voltage, over voltage, over temperature etc.) When under voltage occurs, there will be an alarm (10 seconds), the AC icon (13) in the display will flash and the green light of the AC switch will flash. - Page 8 1, 4 & 15 Battery Discharge Failure in Low Temperature (Low) Environment. • When the battery is protected against low temperature level I and the icons 1, 4 & 15 (Low) are displayed at the same time. • When the battery is protected against low temperature level II, LCD display is off, and the red light of the AC switch flashes.
- Page 9 Time for Fully Charged. Battery running time. Fan Icon. Appears when the fan is working. 5, 6, 7 & 8 Icon 5: Battery Charging Icon. Appears when charging Icon 6: Battery Charging Power. Appears when charging. Icon 7: Battery Percentage. Icon 8: Battery Power Display.
-
Page 10: Charging The Device
CHARGING THE DEVICE The battery power of the power station will be consumed during use. You can choose the following methods to charge the power station. CHARGING BY ADAPTER 1. Connect the AC plug cable to the adapter. 2. Insert the DC plug of the adapter into the charging port on the rear of the device. - Page 11 CHARGING BY SOLAR PANEL 1. Connect the solar panel charging cable to the solar panel. NOTE: CLARKE solar panels are sold separately, as follows: • SFP1 (6487078); Foldable Solar Panel 100W • SFP2 (6487079); Foldable Solar Panel 200W 2.
- Page 12 CHARGING BY THE BATTERY RESCUE PORT This method should only be used if the battery is seriously low and cannot be charged by normal methods. 1. You will need a USB Type C charging cable and plug (not supplied). 2. Unscrew the cover of the battery rescue port which is located on the rear of the power station.
- Page 13 CHARGING BY BATTERY 1. If charging through a separate battery, the user needs a battery clip adapter cable, as shown (not supplied). 2. Insert the DC plug of the adapter into the charging port on the rear of the device. 3.
-
Page 14: Operation
OPERATION LCD DISPLAY ON/OFF Short press the LCD switch to turn ON/ OFF the LCD screen (ON: the green indicator light on the button will be on, OFF: the indicator light will be off). Turn on any switch of DC, AC and the light, the LCD screen will also light up. -
Page 15: Storage And Maintenance
LED LIGHT Short press the LED switch for the 3 different settings of the light as follows: • 1 Press: Low Light • 2 Presses: High Light • 3 Presses: Flashing SOS mode • 4 Presses: Off NOTE: After the light has been on for over 1 minute in any setting, the light will turn off when the switch is next pressed. -
Page 16: Troubleshooting
TROUBLESHOOTING FAULT SOLUTION Battery high Put the power station in a cool and ventilated place so it can temperature be restored after the temperature is lowered. NOTE: DO NOT protection directly cool the power station by freezing, as this may damage it. - Page 17 The battery power is seriously low, charge it through the battery rescue port until screen is lit, then fully charge it in a usual way. If these remedies are unsuccessful, consult your CLARKE dealer. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
-
Page 18: Specification
IPX0 Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice. Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... -
Page 19: Declarations Of Conformity
DECLARATIONS OF CONFORMITY Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com...
