Setup
How to Load Paper Roll
1. Use thermal paper (2 " x 50').
2. Locate the paper compartment on your Dejavoo device.
3. Insert thermal paper roll into the open compartment with
paper feeding from the bottom.
4. Leave a few inches of paper hanging out over the top of the
roll.
Note: Some payment terminals may include a separate device for
printing receipts. The Dejavoo QD5's receipt printer is built into the
terminal.
How to Turn On/Off
1. Power On: Press and hold down the power button on the
side of your device until your Dejavoo QD5 activates.
2. Power Off: Press and hold down the power button on the
side of your device until your Dejavoo QD5 powers off.
3. If prompted, confirm that you want to turn your Dejavoo
QD5 off.
How to Set Up an Ethernet or Wi-Fi Connection
Connect to Ethernet
1. Before getting started, ensure your ethernet cable is
functional and securely plugged into the open port on your
Dejavoo device.
2. Access the Core Menu on your Dejavoo QD5.
3. When prompted, select the UTILITY option.
4. Select COMMUNICATIONS.
5. Select LOCAL PARAMS.
6. You will then be asked to select a connection option, such as
WIFI or ETHERNET. When prompted, select ETHERNET.
7. For Mode: select MODE to confirm.
8. For Static IP: select STATIC to confirm.
9. Use the device's touchscreen to select your desired
configuration option, then confirm.
Connect to Wi-Fi
1. Access the SETTINGS menu on your Dejavoo device.
2. Select either COMM SETUP or WLAN.
3. At this point, you will be presented with a series of available
connection options: WIFI, ETHERNET, BLUETOOTH, etc.
Select WIFI.
