PS-8 Series Gas Detector
for use in semiconductor manufacturing plant
Instruction Manual for Installation
Keep this manual for easy reference.
Read and understand this manual carefully before using this product correctly.
This manual describes the standard model. If your unit has end-user-specific options, this manual will be
superseded by your delivery specifications.
Instruction Manual No.
GAE-178-00
December 2024
