  • Page 1 10/100 Mbps PoE Switch Quick Start Guide UD38017B-A...

  • Page 2: Applicable Models

    Preface Applicable Models This manual is applicable to DS-XS00-P series 10/100 Mbps PoE switches. Symbol Conventions The symbols that may be found in this document are defined as follows. Symbol Description Provides additional information to emphasize or supplement important points of the main text.

  • Page 3: Product Introduction

    1 Introduction 1.1 Product Introduction DS-XS00-P series switches are 10/100 Mbps PoE switches, providing PoE power supply technology on the basis of network access to ensure stable data upload. The devices are reliable, easy to install and maintain, and equipped with rapid switching functions.

  • Page 4: Rear Panel

    Note  Ports 1 and 2 of DS-XS06-P and DS-XS10-P switches are high- priority ports used to prioritize network transmission in key service areas.  Ports 1 to 4 of DS-XS06-P switch and ports 1 to 8 of DS-XS10-P switch support up to 300-meter network transmission. Rear Panel DS-XS06-P/DS-XS10-P Switch Table 1-2 Port/Indicator Description...

  • Page 5: Installation

    Indicator/Port Description Used for connection to a grounding Grounding cable to protect the switch from ⑦ Terminal lightning. 2 Installation Please select an appropriate installation method according to the actual needs. Note The following figure is for illustration only. The actual device prevails.
  • Page 6 3.1.1 With Grounding Bar If a grounding bar is available at the installation site, follow the steps below. Steps 1. Connect one end of the grounding cable to the binding post on the grounding bar. 2. Connect the other end of the grounding cable to the grounding terminal of the device and tighten the screw.
  • Page 7 Note Connect a PoE RJ45 port of the switch to the RJ45 port of a network camera (IPC) so as to supply power to the IPC. 4 Device Powering-On Please use the undetachable power cord to power on the device. Before powering on your device, make sure that: •...
