Summary of Contents for LaserPecker LP5
- Page 1 LaserPecker LP5 使用说明书 User Manual 使用說明書 v1.0 2024.05 取扱説明書 사용자매뉴얼...
- Page 2 简体中文 日本語 English 한국인 繁體中文...
-
Page 3: Table Of Contents
50–95°F (10–35°C) and 10–95% humidity. · DO NOT leave the machine una ended during operation. Meet the LP5 In the event of the following situations, please stop using the machine and cut o the power immediately: Before using the prodcut ·... -
Page 4: Safety Information
Laser Safety · The LP5 Basic is a Class 4 laser system. When assembled and locked with Warning and instruction labels are put on places that may pose a risk before a safety enclosure, the laser system is Class 1. -
Page 5: Software Download
Software Download Ge ing Help Download App Contact Us Scan the QR code below to download and install the LaserPecker Design If you encounter any issues, please do not hesitate to reach out to our Space App. customer support team at support@laserpecker.com... -
Page 6: Package List
Package List Laser Unit x 1 Electric Stand x 1 Base Plate x 1 Conical Protective Cover x 1 Power Cable x 1 /Power Adapter x 1 Cable Organizer x 1 Security Key x 2 Cable 1.5m x 1 & 1.0m x 1 Listed below are free gifts. -
Page 7: Quick Assembly
Quick Assembly Electric Stand Assembly Use the Hex key H2.5 to install the 4 M2.5 screws at the bo om of the 2. A ach the Laser unit to the Electric stand by turning the knob Base plate to secure the Electric stand. counter-clockwise. - Page 8 Quick Assembly Conical Protective Cover Installation Place the Conical protective cover below the Laser unit. Secure the cover A ach the Front light filter. to the Laser unit by tightening the 2 screws on top of the cover.
-
Page 9: Cable Connection
Quick Assembly Cable Connection Connect the power cable Connect the Conical and power adpater to a protective cover to the power supply. port. Connect one end of the the other end to the �.�m cable to the power power output on the port on the Electric Laser Unit. -
Page 10: Component Introduction
Component Introduction Preview button DC power port Up button Security key USB-C port for computer connection Electric stand indicator Power output for electric stand Accesory port Emergency stop button Conical protective cover port Down button USB port for flash drive Laser unit indicator Pause/Resume button Field lens cover... -
Page 11: Before Using The Prodcut
Before using the prodcut Check the Security Key Install the Pipe Ensure the Security key is inserted properly before use. The Protective cover has a built-in exhaust fan, which can be connected to a pipe or used with an air purifier. Please note the machine will not work if the Security key is not inserted. -
Page 12: Connect To App
Connect to App through Wi-Fi (First time WiFi setup or changing the network) Open the LaserPecker Design Space App, click the ""+"" in the upper right corner, select the machine model 'LP5' and follow the instructions to configure the WiFi network for the machine. - Page 13 Connect to PC Software Option 1: Option 2: Connect directly via a USB cable Connect to PC Software through WiFi(First-time WiFi setup or changing the network) Before se ing up the wireless connection, After connected, entering the machine you must first connect the machine to a se ing page on the upper right corner in the computer using a USB cable.
-
Page 14: Using The Product
Using the product Dual Red Spots Focusing (Manual Focusing) Emergency Stop Place the material on the Base plate. Initiate the preview Mode through APP If errors or machine faults occur during material processing, press the or PC software to observe the two spots. Adjust the height of the Electric emergency stop bu on to disconnect and stop the processing. - Page 15 Multiple application scenarios Bevel Engraving Using Accessories Batch Processing Loosen the electric stand knob clockwise to If accessories are needed, purchase them During batch processing, the L-shaped adjust the angle of the Laser unit. separately and refer to the accessory positioner can fix materials in the same Tighten the knob counterclockwise to fix the instructions for installation.
-
Page 16: Maintenance
Maintenance Field Lens Maintenance Conical Protective Cover Exhaust Fan Cleaning If laser power a enuation occurs, for example, engraved pa erns are If smoke runs out of the protective cover, the exhaust fan and smoke outlet shallow or uneven, the Field Lens may get dirty. Clean it with the lint-free may be blocked due to dust. -
Page 17: Technical Specifications
Technical Specifications Size Laser Unit: 255 x 98 x 183 mm Electric Stand: 198 x 286 x 323 mm Conical Protective Cover: 167 x 231 x 160 mm Net Weight Laser Unit: 3.36 kg Electric Stand: 2.28 kg Conical Protective Cover: 0.38 kg Total Weight: 6.02kg Laser Source &... -
Page 18: Statements
Disclaimer This document is copyrighted by LaserPecker with all rights reserved. Thank you for choosing LaserPecker LP5! This manual relates to your safety, legal responsibilities and rights. Please read and get familiar with all safety Unless otherwise authorized by LaserPecker, you are not eligible to use or allow others to use the document or any part of the document by precautions and procedures before using the product. -
Page 20: Fcc Warning
FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
