Adaptive Recognition VIDAR User Manual

Hide thumbs Also See for VIDAR:
Table of Contents

Advertisement

Quick Links

Download this manual
VIDAR
User Manual
This manual contains instructions on accessing
the web interface, system settings and setup
guidelines, and usage and maintenance.
© Copyright Adaptive Recognition Inc.
All rights reserved.
17.12.2024.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the VIDAR and is the answer not in the manual?

Questions and answers

Related Manuals for Adaptive Recognition VIDAR

Summary of Contents for Adaptive Recognition VIDAR

  • Page 1 VIDAR User Manual This manual contains instructions on accessing the web interface, system settings and setup guidelines, and usage and maintenance. © Copyright Adaptive Recognition Inc. 17.12.2024. All rights reserved.

  • Page 2: Table Of Contents

    EXPOSURE CONTROL ..............................40 6.5. OPTICS ......................................41 6.6. SECONDARY SENSOR ..............................44 6.7. FLASH CONTROL ................................45 6.8. MISCELLANEOUS ................................46 EVENTS AND ANPR ..................................50 2/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 3 8.7. RECOVERY MODE ................................108 8.8. RESTART ..................................... 111 8.9. COMPLIANCES ..................................113 HOW TO SETUP YOUR VIDAR CAMERA TO GET THE MOST ANPR EVENTS ........115 9.1. RECOMMENDED CAMERA POSITION ........................115 9.2. SOFTWARE REQUIREMENTS ............................116 9.3. ACCESSING THE CAMERA ............................116 USE CASE .......................................117...
  • Page 4 BLACK/WHITELIST (SMART CAMERAS ONLY) ..................181 12.33. RESTART ..................................... 186 12.34. CAMERA MODULES ..............................186 13. CARMEN ANPR REFERENCE MANUAL ..........................187 CONTACT INFORMATION ..................................188 4/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 5: About This Manual

    ANPR data corresponding to the event. In the last section, the tools of camera maintenance (firmware update, logs, etc.) are • described. 5/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 6: Accessing The Camera

    From versions of Firefox (v. 56.0) it might be necessary to disable the feature "Use hardware acceleration when available" to avoid possible browser/machine hangs (Located at: Preferences/Performance/Use Recommended Performance Settings). 6/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 7: Web Interface

    WEB INTERFACE Main areas of the camera interface: Info bar Info bar Side menu Workspace The information bar displays: • Adaptive Recognition logo • Version number • Language selector • Camera type, name of the currently active page. Side menu •...
  • Page 8 Menu subpages can also be addressed via direct links, like http://192.0.2.3/#liveview/, http://192.0.2.3/#eventman, etc. For best user experience use a recent edition of Google Chrome, Mozilla Firefox or Microsoft Edge. 8/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 9: First Steps (Wizard)

    The Wizard will help with the initial configuration of the system settings of the camera. It will guide you through few steps: • Setting up an administrator user 9/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 10 The other sections will become inactive. o Get Client Time: Adjust the internal clock of the camera to the PC. • Set up the network 10/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 11 Displays a checklist of the settings: a properly configured entry is displayed in green. Entries that need further attention are displayed in red. All of these settings are also available as separate configuration pages (see System settings). 11/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 12: System Settings

    Before you set the time, please make sure that your time zone is valid (has the correct continent / Capital City). You can do this by using the Time zone’s drop-down list. Settings are applied after clicking SAVE. 12/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 13 In a power down state the battery is able to provide power to the RTC for approximately 2 weeks. It takes about 12 hours in a power up state for the battery to completely recharge. 13/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 14: Network

    VIDAR User Manual 5.2. NETWORK WEB INTERFACE > BASIC SETUP > NETWORK This page provides access to the network settings of the camera. 14/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 15 • Hostname: The name of the device in the network. Title of this site: • Textual description of the device, for example Adaptive Recognition, that will appear as the title of the browser tab. DHCP: • Check this checkbox to have the camera to operate in DHCP mode, that is to obtain its.
  • Page 16 After signing, upload it to your device with the public key of the RootCA certificate. • After installation and restart, your device is available with HTTPS protocol. 16/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 17 Accept All – in this case access is granted to all IPs except those listed The exceptions to the default policy can be added and removed in the Add IP Address to Filter List section. 17/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 18 Before clicking the Save button, make sure that all settings are configured correctly, an incorrect setup can block the user from accessing the camera. In this case Recovery Mode may be applied. 18/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 19 IP devices to correct the IP address. This can be accomplished using the so-called link-local IPv4 address of the network device. Enable Bonjour: The program is able to detect Adaptive Recognition (VIDAR) cameras on the Ethernet network using the Bonjour protocol.
  • Page 20 This SDP file can be opened in media player programs, for instance in VLC, and it contains the stream parameters, allowing the camera's image to be displayed in the player. 20/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 21 The camera does not check whether the uploaded private key is encrypted and does not validate the entered password). 21/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 22 The settings applied only after pressing the Apply button, and if this succeeded, the interface will offer to restart the camera. 22/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 23 Access level (Normal user, Read-only user, Superuser and Administrator) • Security level (Off, MD5, SHA1, MD5+DES, SHA1+DES, MD5+AES, SHA1+AES) • Settings will be applied only after click on SAVE button. 23/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 24: Dynamic Dns

    SNMP. You are able to download it and open it with any text editor. The function only works if the Enable NTCIP box is checked in the Advanced camera interface protocols menu. Settings are applied after clicking SAVE. 24/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 25: Users

    Users can be added , deleted and edited with the corresponding buttons. If you enable ‘User authentication’, all connections to the camera will require username and password. 25/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 26 Password should contain only letters of the English alphabet, numbers or underscore ('_') (with regular expression: /^[0-9A-Za-z_]*$/) • Confirm password: Confirm the given password to rule out mistyping. 26/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 27 Settings will be applied only after restarting the camera. If you click VALIDATE after modification the camera will automatically restart. 27/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 28: Image Setup

    There may be more than one pipeline: Source#1 for the primary and Source#2 for the secondary pipeline. The primary and secondary imaging pipelines are configured in the Stream Settings section. 28/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 29 Source#2: The resolution and FPS of the secondary imaging pipeline o Rotation, Horizontal and Vertical mirroring: Geometric transformations (shared by both pipelines) Stream X Settings: The settings of the selected stream are listed here 29/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 30 You will find the links that you can open, for example, with VLC. 30/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 31 Uses...: Uses I and P frames group size from above o If new...: The first frame of an event (see below) will be an I frame, all others will be P frames 31/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 32 JPEG quality: Default JPEG quality. The larger this number the better the quality. o JPEG quality on event: JPEG quality across the duration of an event. 32/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 33: Post-Processing

    Brightness: Increase/decrease the brightness of the image • Contrast: Increase/decrease the luminance contrast of the image • Saturation: Increase/decrease the chrominance contrast of the image 33/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 34 The difference between the two is that the automatic continuously adjusts to external changing conditions, while the manual is a fixed setting. The white balance tries to adjust the white balance. 34/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 35 White Level: Defines the pixel value above which all pixels will be mapped to white • Black level: Defines the pixel value below which all pixels will be mapped to black 35/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 36: Private Zones

    SAVE button, the defined area will be filled with black color, which you can be seen on the live view and on the streams as well. 36/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 37: Brightness Control

    Brightness control will also switch to night mode (engaging built in LEDs) if illumination levels fall to a level, where capturing a color image is not possible. 37/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 38 Please note that these conditions determine the maximal exposure time, limiting the illumination of the scene, under which night mode will be engaged. 38/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 39 Please note that in mobile mode, Vidar corresponds eventually to a lower speed, as on Freeway the velocity of the camera and the target vehicle is in the same direction, as opposed to Highway use, monitoring oncoming traffic.

  • Page 40: Exposure Control

    Shutter Max. is adjustable and Gain Max. is available in day/night mode, where a user defined value may be entered. Selecting Environment on the Mode tab affects these values. 40/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 41: Optics

    It follows from the 41/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 42 (Currently, the viewing angle can be specified in Plain config (URL: http://CAM_IP/#plainconfig) in the setup / geometry module with the parameters 'lane_width' and 'lane_count'. Their default values are 3 and 1.) 42/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 43 • Laser only: Fast distance-based focus adjustment using only the built-in laser unit. Both function keys are currently only displayed for cameras with LIDAR! 43/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 44: Secondary Sensor

    Auto Tracking, Auto Zoom-Focus Setup and Direct Focus can be adjusted the same method as Sensor 1. The secondary sensor box will be shown only if none of the on-screen tools are active. 44/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 45: Flash Control

    • Both Flash Intensity and Parity Flashing can be defined for day and night mode. • "Parity Flashing" is expressed as a percentage of "Flash Intensity”. 45/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 46: Miscellaneous

    To open live video stream in 1:1 full screen in a pop-up window, click on the icon in the top menu. To save snapshot from the live video stream, click on the icon in the top menu. 46/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 47: Visual Aids

    You can pause and jump between events with the appropriate buttons. You can click between tabs in the Live View menu, but if you click elsewhere in the sidebar, the feature will turn off. 47/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 48 VIDAR User Manual 48/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 49 Use the mouse to drag the frame on the image field to the required position. • Image Center: Black cross is positioned to the center of the image. 49/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 50: Events And Anpr

    Vehicle Detection with an instance of Scheduler set to be asserted during the required hour. This feature is configured in the EVENT MANAGER page. 50/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 51 (with the license plate in the best position), license plate and event data (textual form), and a license plate image as an output. 51/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 52 This is demonstrated in the Browse menu. Alternatively, in 'Push' mode, the camera can forward data using a given protocol (HTTP, FTP, SFTP). This is configured at the RESULT UPLOAD page. 52/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 53: Events

    The sources will be connected with an OR conjunction: the trigger will be asserted while any of the trigger sources are active. By selecting a trigger source its configuration will be available at the bottom of the screen. 53/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 54: Motion Detector

    MOTION DETECTOR 7.1.2. First you need to click on Configure button to guide you to Motion Detection settings. On this page you can set all parameters. 54/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 55 Trigger timing can be setup: • Trigger mode, Trigger start/end offset: Please check GPIO TRIGGER (Chapter 7.1.4.) where you will find the description of this section! 55/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 56: Software Trigger

    The only difference compared to the other trigger selectors is that there is no individual enabling option. Only the name of the ROI can be specified. You can set up ROI for 4 lanes, each separately. 56/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM...
  • Page 57 As an output parameter in the URL, the user receives which ROI the module is working on: http://cam_ip /trigger/swtrigger?wfilter=1&output=2&sendtrigger=1 Here, it is ROI number 3 (indexing starts from 0). 57/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 58: Gpio Trigger

    During this interval both high and low samples will be recorded. The device will consider the input as settled when the number of samples that agree (last n samples are low/high) exceeds the value given in Required samples. 58/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 59 Please note that at least one trigger (e.g., one passing vehicle) is required after adding the GPIO trigger to receive a valid status. • GP Output: Is used to toggle the state of the General Purpose Output pin. 59/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 60 Rising/Falling edge: the trigger is asserted both at the rising and at the falling edge of the input. Start/end offset: the interval during which the trigger is asserted can be extended in both directions with start and end offsets. 60/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 61 • numerals separated by semicolons (e.g., 6;9) • the word 'every' • hyphens to express intervals (e.g., 7-9) • combinations of the above e.g., 6;7;9-11;15 61/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 62: Uart Trigger

    Falling edge: the trigger is asserted only when TET is received • Rising/Falling edge: the trigger is asserted both when TST and when TET is received 62/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 63 '\n' byte) or check 'Start on first byte', which means, whatever byte comes first or follows the last end token will be the trigger start token. 63/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 64 As a first step, add Plate Finder as a trigger source. Add the new trigger source to Event Manager as follows: • Click on "+" to add a trigger source: 64/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 65 User Manual • In the drop-down menu, select the Plate Finder Trigger, then click Add. Do not forget to save trigger source(s) by clicking Save. 65/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 66 The Plate Finder and Object Detection Trigger cannot both be active at the same time as they are mutually exclusive trigger sources. Please regenerate the trigger accordingly, ensuring that only one of them is active at any given time. 66/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 67 As a first step, add Laser as a trigger source. Add the new trigger source to Event Manager as follows: • Click on "+" to add a trigger source 67/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 68 We can conclude from our measurements that it operates reliably up to a maximum distance of 20 meters. 68/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 69 (heavy rain, snowfall) this value will indicate if not enough good quality measurements could be taken, thus triggering may underperform. Do not forget to save trigger source(s) by clicking Save. 69/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 70 Name field. 70/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM...
  • Page 71 In the ANPR menu, on the Browse page, you can view the detected events. If you click on the Info button at the top of the image and switch the Data group field to Trigger data. 71/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM...
  • Page 72 The 'Object Detection Trigger' and 'Plate Finder' cannot both be active at the same time as they are mutually exclusive trigger sources. Please regenerate the trigger accordingly, ensuring that only one of them is active at any given time. 72/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 73: Anpr

    – List image data – Select/unselect all records – Delete record(s) – Reload list of entries – Search for: timeframe / license plate / vehicle category. 73/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 74 Overview image: the image of the overview sensor • LP image: the license plate • Strip image: the index images of the event containing all triggered images 74/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 75 MMR a corresponding MMR Hardware Key License must be purchased and installed in the device. Events and ANPR ANPR+ANPR - Two ANPR stages follow the (See Preselection stage for a use case). 75/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 76 In devices equipped with two image sensors, you can set up a secondary source functioning as either Overview or ANPR. In ANPR mode, the system will attempt to find a license plate in the secondary image. 76/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 77 • Duplicate timeout: the time frame in which the same license plate will not be registered again if once read. 77/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 78 Please note, that the time requirement of reading ADR/EADR plates is comparable to that of reading license plates, thus the net throughput (vehicles processed per seconds) will be affected. 78/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 79 VIDAR User Manual TITLE EDITOR 7.2.3. WEB INTERFACE > ANPR > TITLE EDITOR 79/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 80 Unknown vehicle direction: The string that gets printed in the subtitle when vehicle direction cannot be determined. In the Line Editor tab users can customize the subtitle using the wildcards listed below. 80/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 81 Currently used engines are listed in the Selected Engines tab. Engine properties are configured in the bottom tab. Please check the Carmen ANPR Manual details. 81/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 82 Expiration Date. Therefore, please contact your sales person or write to requestinfo@adaptiverecognition.com and request an update and your latest engine to keep the highest performance! 82/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 83 By default, there is a default Rule set. Additionally, multiple Rules can be defined. As a first step, a Rule needs to be added by pressing the Add button. In the following window, you can set which times the Rule should work. 83/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 84 Add button to specify this option. Press the Edit button to open a window where you can configure the Upload Settings - Upload Manager 0 settings if checked. 84/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 85 Username and Password*: User credentials this request upload using HTTPS protocol: http://cam_ip/lpr/cff?cmd=setproperty&name=/default/cfs/uplm/http/cert_vfy&value=0 **: only present in FTP, SFTP configuration Upload Content: The data and images will be uploaded 85/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 86 In case that you want to upload under an inadequate name or modify .sys file, it will not allow. If you change an active template, it will restart automatically afterwards. 86/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 87 2. plate_text=$DB2XML($(ANPR_TEXT)); 3. camera_location=$(location); 4. vehicle_image=$(normal_img); which will evalutate to: event_id=123456789 2. plate_text=ABC123 3. camera_location=Test Site 34b 4. vehicle_image=/9j/4AAQSkZJRgABAQAAAQABA[... a base 64 encoded image... 87/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 88 In the previous example it means that spaces will have to be replaced by '%20', filenames on certain systems can't contain ':', etc. 88/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 89 For example the following expression: ();$TEST(a ,,$(LP)); will evaluate as ();a$a,DATA provided that the function TEST concatenates its arguments and the field LP contains the text 'DATA'. 89/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 90 Tick in checkbox to activate the function. Under Upload Settings, enter the requested parameters and press the Save button to validate the changes. 90/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 91: Number Plates

    16:00), a license plate condition (ABC123 and DEF456) and an event notification (pull GP output to high or upload event data to an FTP server). If and only if both the time and license condition is satisfied, then the event notification will be executed. 91/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 92: Time Settings

    If a task has any settings, those are available clicking the Cogwheel icon beside the event notification task list entry. An entry can be removed by clicking the Trash bin icon. 92/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 93 Event Notifications, consequently those on this list will not be reported via the Upload feature. Edit time/date settings accordingly, for example if tolls apply only on weekdays uncheck Saturday and Sunday in both rules. 93/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 94 Results with plate text and jurisdiction: # of events where complete ANPR info is available • Results with ADR info: # of events where ADR info is available. 94/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 95: Maintenance

    • provide info about temperature, light levels and memory usage. It is normal to have both memory usage stats at or near to 100 %. 95/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 96: Sensors

    VIDAR User Manual 8.2. SENSORS WEB INTERFACE > MAINTENANCE > SENSORS The built-in accelerometer may provide help aligning the camera. 96/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 97: Camera Log

    Camera and ANPR logs provide information about the processes in the camera and the license plate recognition module respectively. Log entries can be copied to the clipboard attached to a bug report. 97/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 98: Update/Auto Update

    First step is to tap „Select” button to choose update package from your computer. When you have loaded, tap „Update” button to start installing the update package. 98/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 99 User Manual The total process may take up to 15 minutes. If you power off the camera or refresh the page, the firmware update will be aborted! 99/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 100 By clicking the Start Update button, the values are stored, and the update process starts. The camera starts in update mode, and if the package is not valid, the user receives a notification on that interface. 100/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 101: Auto Update

    • Smaller patch packages • License / certificate packages • Engines • Configuration packages • Custom OEM packages, additions Supported servers: • HTTP • HTTPS 101/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 102 First character 'N': normal mode, does not start the update process immediately. 'F': force - start immediately the downloaded update package. If there is no flag field, 'N' is the default value. 102/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 103 (this is a Linux scheduler, more complicated scheme can be specified as well, like the first day of the month and the middle day, every Wednesday, etc ...) Do not forget to save settings by clicking Save. 103/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 104: Backup/Restore

    A backup can only be restored on the same type of camera where the full hardware and software package are the same. 104/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 105 VIDAR User Manual This is the import process when we restore the backup file. Wait until the process is finished. 105/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 106: Factory Reset

    After every firmware update, it is strongly recommended to perform a factory reset, if possible, as it ensures stable and reliable operation. 106/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 107 IP address (192.0.2.3.). These two options should only be selected simultaneously if the camera is being uninstalled or being sold. Make sure to backup any important data before initiating the reset. 107/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 108: Recovery Mode

    VIDAR User Manual 8.7. RECOVERY MODE WEB INTERFACE > MAINTENANCE > RECOVERY MODE 108/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 109 VIDAR User Manual 109/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 110 VIDAR User Manual 110/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 111: Restart

    VIDAR User Manual 8.8. RESTART WEB INTERFACE > MAINTENANCE > RESTART 111/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 112 (for example due to a lost IP), Recovery Mode may also be entered applying the magnetic reset procedure. Entering Recovery mode to Vidar camera: Starting of the Recovery mode can be implemented by magnetization in the following way: By magnetization: 1.

  • Page 113: Compliances

    This declaration represents the Company's best knowledge, which is partially based on information provided by third party suppliers. Laser safety compliance: All models of VIDAR ANPR camera which are equipped with a measuring laser module are Class 1 laser products according to the IEC 60825-1:2014 standard. 113/188...
  • Page 114 FCC. Changes or modifications to product not expressly approved by Adaptive Recognition Hungary could void your right to use or operate your product by the FCC.

  • Page 115: How To Setup Your Vidar Camera To Get The Most Anpr Events

    A good installation site is the basis of reliable operation. This guide is going through step-by-step all crucial point of the menu to help to the user to setup Vidar camera properly for the first time. Parameters setting by hand via web interface of the camera.

  • Page 116: Software Requirements

    6. Start a browser then enter the default IP address of the camera into the address bar (http://192.0.2.3). After this, the camera starts with administrator privileges, ready to be set up and configured. 116/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 117: Use Case

    0° Tilt 37° Camera configuration VIDAR US 2xFHD, ANPR, Laser, IR, Radar The proper camera settings are the following: Users: WEB INTERFACE > BASIC SETUP > USERS First of all, set User Authentication. By default, this function is turned off, but if you tick in the checkbox, it will be turned on.
  • Page 118 Set the name of your device in the Hostname field (default is ARHInc.). Add textual description of the device in the Title of this site (default is Adaptive Recognition). Tick in DHCP mode to set your IP address, Netmask, Gateway and DNS (default is off).
  • Page 119 Gama: 1.5 (It could be up to 1.8 or at extreme low light situation 2.2) • JPEG Quality: 75 (Default is 80) • White Level: 1.0 • Black Level: 0.00 (Default is 0.02) 119/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 120 12. Black-, Whitelist: WEB INTERFACE > ANPR > BLACK-, WHITELISTS • Black-, Whitelist: Tick in (You have to tick it) • Rules: Default (No filter) 120/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 121: Programmer's Guide

    PROGRAMMER’S GUIDE GENERAL API SPECIFICATION Every operation on the VIDAR camera is done by setting and getting parameters. Camera functions are implemented by modules, modules are grouped in module groups. Camera parameters are organized in named sections within modules. Parameters are set and get by HTTP queries in the manner detailed in this chapter 11.1.
  • Page 122 • Only one section can be queried at a time. Setting parameter values: GET: http://[camera_ip]/[modulegroup]/[modulename]?[parametername1]=[parametervalue1]&[parame tername1]=[parametervalue1]&...&[sectionname]= [sectionvalue]&wfilter=X ANSWER: mimetype=text/plain\r\n ecode=0\r\n ANSWER: mimetype=text/plain\r\n ecode=-22\r\n eparams=parametername1,parametername1\r\n 122/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 123: Parameter Attributes

    If there is no section defined, the default section is applied • More parameters (of the same section) can be queried http://camera_ip/modulegroup/modulename?queryall[&sectionname=sectionvalue]&wfilt er=X • If there is no section defined, the default section is applied 123/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 124 • boundshutter=20,10000 The value of the shutter can be set between 20 and 10000. There are no recommended value and steps. 124/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 125 (e.g.: the i16[4] means 4 x 16-bit integer numbers). • unit: unit of measurement (optional) - arbitrary string • reboot: should the system be rebooted after rewriting the parameter 125/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 126 Tusername=rw,s32,,f The username is a readable and writable string type containing 32 characters. It does not have measurement, but the system has to be restarted in case of switching. 126/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 127: Answer Document

    Content-Length: 93123 Content-Type: image/jpeg The boundary will be written at the beginning of the answer, between the parts and at the end of the answer. 127/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 128: Answer Error Codes

    (do not fully match the original description). Input/output error In case of any error during communication hardware interface. 128/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 129: User Authentication

    API request. No cookie is involved in this method - every request has to have the following suffix at the end - '&p_urllogin=1&p_username=USER&p_passw=PASSWORD' For example: http://camera-ip/scapture?capture=last&p_urllogin=1&p_username=USER&p_passw=PASSWORD 129/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...

  • Page 130: Modules

    Parameter values with the same position/index in the lists belong to the same user. Passwords cannot be obtained. Response example: guestlevel=0 useridlist=1001,1002 nicknamelist=user00,user01 fullnamelist=, userlevellist=2,4 130/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 131: Image Resolution

    In case of two optical systems, each sensor can be controlled separately with the following optional parameter: & sensor = 1 or 2. If this parameter is not specified, the parameters for the main sensor are controlled. 131/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 132: Simple Retrieval Of An Image

    In case of two optical systems, each sensor can be controlled separately with the following optional parameter: & sensor = 1 or 2. If this parameter is not specified, the parameters for the main sensor are controlled. 132/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 133 (framemonotimems, imgframetimems) or frameindex value is too high (refers to a yet non-existing frame) then the newest frame from the buffer is returned. GET: http://camera_ip/capture/scapture?capture=best&framemonotimems=106964188&wfilter=X http://camera_ip/capture/scapture?capture=best&frameindex=193390&wfilter=X 133/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 134: Frequently Used Image Parameters

    SAVE: http://camera_ip/setup/profiles?save_imgparams&wfilter=1[&c_source=X] 12.5. FREQUENTLY USED IMAGE PARAMETERS Module: capture/scapture Manual: Get image parameters GET: http://camera_ip/capture/scapture?getall&wfilter=X[&source=X] ANSWER: imggamma=1.700\r\n gamma=1.700\r\n SET: http://camera_ip/capture/scapture?gamma=1.0&brightness=0.0&contrast=0.0&jpegquality=75&bl acklevel=0.0 &whitelevel=1.0&whitebalance=0.0,0.0,0.0&saturation=0.0&wfilter=1[&source=X] SAVE: http://camera_ip/setup/profiles?save_imgparams&wfilter=X[&c_source=1] 134/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 135: Capture Parameters

    12.7. AUTO BRIGHTNESS CONTROL Module: control/brightnesscontrol Manual: Get/Set Brightness Control Properties GET: http://camera_ip/control/brightnesscontrol?getall&wfilter=1 http://camera_ip/control/brightnesscontrol?queryall&wfilter=1 SET: 1. sensor settings: http://camera_ip/control/brightnesscontrol?enable_0=1&save&wfilter=1 http://camera_ip/control/brightnesscontrol?target_0=-20&save&wfilter=1 2. sensor settings: http://camera_ip/control/brightnesscontrol?enable_1=0&save&wfilter=1 http://camera_ip/control/brightnesscontrol?target_1=10&save&wfilter=1 135/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 136: Auto Focus

    ROI: operation area of the autofocus; x1, y1, x2, y2, where x1, y1 the upper left corner of the rectangle and x2, y2 the lower right corner of the rectangle 136/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 137: Auto Color Compensation

    12.9. AUTO COLOR COMPENSATION Module: control/colcorr Manual: 6.2.2 Get color correction state and properties GET: http://camera_ip/control/colcorr?getall&wfilter=1[ &sensor=X] ANSWER: mode=0\r\n SET: http://camera_ip/control/colcorr?mode=1&save&wfilter=1[&sensor=X] where X=1, sensor 1 X=2, sensor 2 137/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 138: Optics Control

    GET: http://camera_ip/control/focuscontrol?getall&wfilter=1 ANSWER: zfc_mode=0\r\n zfc_pairs=564,327;1120,213;\r\n SET: http://camera_ip/hwlayer/extopt?zoom_pc=10&focus_pc=20&iris_pc=30&zfcomovement=0&filte r=1&save&wfilter=1 http://camera_ip/control/focuscontrol?zfc_addpair=1120,213&save&wfilter=1 http://camera_ip/control/focuscontrol?zfc_rmpair=1120,213&save&wfilter=1 http://camera_ip/control/focuscontrol?zfc_mode=2&save&wfilter=1 • extopt/zfcomovement (can be 0,1) equal focuscontrol/zfc_mode, recommended to use zfc_mode (can be 0,1,2) 138/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 139: Flash Control

    • In case of cameras equipped with rolling shutter sensors the camera illumination can be only enabled or disabled. For enabling: led_pcdose=100 139/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 140: Event Manager

    General syntax sources=groupname/modulename[numberofoutputs](stringname),groupname/modulename[numb erofoutputs](stringname),...\r\n Get registered trigger sources and input configuration http://camera_ip/trigger/eventman?getconfig&wfilter=1 ANSWER: mimetype=text/plain\r\n config=trigger/swtrigger/0:A,__motdet/0:B,trigger/uarttrigger/0:C\r\n GENERAL SYNTAX: config= groupname/modulename/outputindex:assignedletter,groupname/modulename/outp utindex:assignedletter\r\n Get/set formula http://camera_ip/trigger/eventman?getformula&wfilter=1 ANSWER: mimetype=text/plain\r\n formula=C\r\n 140/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 141 The digit ID of each trigger source must be unique during the registration (recommended alphabetically, see above). The system will manage it automatically during registration via web interface. Start module http://camera_ip/trigger/eventman?formula=B&state=1&save&wfilter=1 Stop module http://camera_ip/trigger/eventman?state=0&save&wfilter=1 Reset module http://camera_ip/trigger/eventman?state=2&save&wfilter=1 141/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 142: Motion Detection Trigger

    12.13. MOTION DETECTION TRIGGER Module: capture/scapture Manual: 7.1.2 Get/set motion detection parameters GET: http://camera_ip/capture/scapture?queryall&wfilter=X http://camera_ip/capture/scapture?getall&wfilter=X&follow=0&frame=2 ANSWER: mdsensitivity=75\r\n mdspeed=75\r\n mdreslevel=50\r\n mdtriglevel=50,50\r\n SET: http://camera_ip/capture/scapture?mdsensitivity=80&mdspeed=80&mdreslevel=55&mdtriglevel= 55,55&wfilter=X&follow=0&frame=0 SAVE: http://camera_ip/setup/profiles?wfilter=X&save_motdets 142/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 143: Software Trigger

    In case of ANPR capable devices, trigger data will be available addressing the database column TRIGGER_DATA (See 21. Database contents) In both cases, trigger data will be encoded with Base64. 143/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 144: Uart Trigger

    • Start/End token can be decimal and hexadecimal (in case of hexadecimal the 0x prefix is needed) • The website returns the values in decimal 144/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 145: Gpio Trigger

    SET: http://camera_ip/trigger/gpiotrigger?gpout=1&wfilter=1 http://camera_ip/trigger/gpiotrigger?gpout=0&wfilter=1 http://camera_ip/trigger/gpiotrigger?gpout=0&samplerate=100&reqsamples=10&act_level=1&sav e&wfilter=1 http://camera_ip/trigger/gpiotrigger?start_offs=0&end_offs=0&mode=0&output=0&save&wfilter 12.17. SCHEDULER TRIGGER Module: trigger/scheduler Manual: 7.1.5 Get/set scheduler trigger properties GET: http://camera_ip/trigger/scheduler?getall&wfilter=1&output=0 http://camera_ip/trigger/scheduler?getall&wfilter=1&output=1 SET: http://camera_ip/trigger/scheduler?enabled=1&mode=1&wday=mon;tue;wed;thu;fri;sat;sun;&day= every&hour=every&min=0;5;10;30-35;50;&sec=0;5;50-55;&output=0&save&wfilter=1 http://camera_ip/trigger/scheduler?enabled=0&output=0&save&wfilter=1 145/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 146: Plate Finder

    12.20.UPLOAD MANAGER (NON-SMART CAMERAS ONLY) Module: upload/uploadman Manual: Hiba! A hivatkozási forrás nem található. Get log of event upload attempts GET: http://camera_ip/upload/uploadman?getlog ANSWER: 2,15-13/2221093.jpg,0,1,Couldn't resolve host name;0,15- 13/2331476.jpg,0,0,No error;0x00 146/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 147 Upload data to FTP server GET: http://camera_ip/upload/uploadman?getall&wfilter=X ANSWER: sections=default,protocol_smtp,protocol_ftp,protocol_post\r\n currentprotocol=0\r\n http://camera_ip/upload/uploadman?getall&wfilter=X&protocol=ftp http://camera_ip/upload/uploadman?content=0&currentprotocol=0&host=testserver&username= &password=&filenametemplate=$d-$h/$m$s$l&protocol=ftp&save&wfilter=X Upload Data to SMTP Server (e-mail) GET: http://camera_ip/upload/uploadman?getall&wfilter=X ANSWER: sections=default,protocol_smtp,protocol_ftp,protocol_post\r\n currentprotocol=0\r\n http://camera_ip/upload/uploadman?getall&wfilter=X&protocol=smtp http://camera_ip/upload/uploadman?content=0&currentprotocol=1&host=testserver&username= &password=&from=&to=user1@testserver;user2@testserver&filenametemplate=$d- $h/$m$s$l&protocol=smtp&save&wfilter=X 147/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 148 VIDAR User Manual Upload Data to HTTP Server GET: http://camera_ip/upload/uploadman?getall&wfilter=X ANSWER: sections=default,protocol_smtp,protocol_ftp,protocol_post\r\n currentprotocol=0\r\n http://camera_ip/upload/uploadman?getall&wfilter=X&protocol=post http://camera_ip/upload/uploadman?content=0&currentprotocol=2&host=testserver&filenamete mplate=$d-$h/$m$s$l&protocol=post&save&wfilter=X 148/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 149: Set/Get Anpr Properties (Smart Cameras Only)

    GET: http://[camera_ip]/lpr/cff?cmd=setproperty&name=[property path]&value=[property value] ANSWER: <ans>\r\n <ecode value ="0"/>\r\n </ans> Save properties of the License Plate Recognition module http://[camera ip]/lpr/cff?cmd=saveproperties ANSWER: <ans>\r\n <ecode value="0"/>\r\n </ans> 149/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 150: Browse The Database (Smart Cameras Only)

    <frametime value="2014.04.02 3:59:16.733"/> <frametimems value="1396403956733"/> <frameindex value="0"/> </capture> <anpr> <text value="ARH002"/> <type value="111"/> <frame value="578,443,734,412,730,445,574,476"/> <bgcolor value="16777215"/> <color value="0"/> <confidence value="94"/> <timems value="360"/> <resultcnt value="1"/> </anpr> 150/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 151 <gps_lon value="19.0234"/> </misc> </result> Get image corresponding to ID GET: http://camera_ip/lpr/cff?cmd=getimage&id=last http://camera_ip/lpr/cff?cmd=getimage&id=1396268058242 http://camera_ip/lpr/cff?cmd=getimage&id=1396268058242 (cropped license plate image, will not exist, if plate was not found) 151/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 152: Database Contents (Smart Cameras Only)

    TEXT (platetypeconf/platetypeinfos/category) ANPR_COLOR INTEGER License plate text color ANPR_CONFIDENCE INTEGER License plate confidence ANPR_FRAME TEXT License plate coordinates (x0,y0,...,x3,y3) ANPR_FRAME_X1 INTEGER LP frame coordinate x1 152/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 153 COUNTRY_LONG TEXT License plate jurisdiction/country, textual, long COUNTRY_SHORT TEXT License plate jurisdiction/country, textual, short UNSIGNED CTRL_AGAIN Image analog gain SMALLINT UNSIGNED CTRL_BLACKLEVEL Image blacklevel SMALLINT 153/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 154 EVTS_IMG0_ACK_TIME BIGINT Deprecated EVTS_IMG0_EXTID TEXT Deprecated UNSIGNED EVTS_IMG0_IS_ACK Deprecated SMALLINT UNSIGNED EVTS_IMG0_IS_FINISHED Deprecated SMALLINT UNSIGNED EVTS_IMG0_IS_SENT Deprecated SMALLINT EVTS_IMG0_SEND_TIME BIGINT Deprecated UNSIGNED EVTS_IMG0_TRYING Deprecated SMALLINT 154/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 155 Plate image x size [px] IMGSIZ_LP_Y INTEGER Plate image y size [px] IMGSIZ_NORM_X INTEGER Main image x size [px] IMGSIZ_NORM_Y INTEGER Main image y size [px] 155/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 156 MMR category confidence MMR_COLOR TEXT MMR color MMR_COLOR_CONF INTEGER MMR color confidence MMR_MAKE TEXT MMR make MMR_MAKE_CONF INTEGER MMR make confidence MMR_MODEL TEXT MMR model 156/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 157 TEXT Trigger source TRIGGER_SPEED UNSIGNED INT Vehicle speed TRIGGER_SPEEDLIMIT INTEGER Vehicle speed limit TRIGGER_TIMEMS BIGINT Trigger time [ms] TRIGGER_VCLASS INTEGER Vehicle class (user defined limits) 157/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 158: Query Database (Smart Cameras Only)

    1000. This value can be increased using the default/cfs/db/max_record parameter GET: http://camera_ip/lpr/cff?cmd=getresultlist&select=WHERE ID>1396465612672 ID<1396465612680 http://camera_ip/lpr/cff?cmd=getresultlist&select=WHERE ANPR_TEXT LIKE '%5%' • use '%25' instead of '%' in the web browser ex.: ... LIKE '%255%25' 158/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 159 <location value="Test location"/> <cameraid value="2200888"/> <ID value="1633966169894"/> <image_hash value="09147619822f582f10c75b1ae6b9b2baf12b2e61"/> <capture> <frametime value="2021.10.11 15:47:01.260"/> <frametimems value="1633967221260"/> <frameindex value="157191"/> </capture> <anpr> <text value="RIU701"/> <type value="101011"/> <country value="HUN"/> 159/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 160 '%MB%' ANSWER: <results> <row> <ID value="1633966169787"/> </row> <row> <ID value="1633966170001"/> </row> <row> <ID value="1633966170297"/> </row> <n_results value="3"/> </results> 160/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 161 +3600. The '+' sign with URL encoding is '% 2b' and the '-' sign is '% 2d'. ANSWER: <results> <row> <ID value="1633966169571"/> <FRAMETIMEMS value="1633966503733"/> </row> <row> <ID value="1633966169572"/> <FRAMETIMEMS value="1633966505533"/> </row> <row> <ID value="1633966169573"/> <FRAMETIMEMS value="1633966508033"/> </row> <n_results value="3"/> </results> 161/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 162: Templates (Smart Cameras Only)

    <location value="Test Site 34b"/> <image value="/9j/4AAQSkZJRgABAQAAAQABA[... a base 64 encoded image...]"/> </result> The same content in a different format might be: event_id=$(ID); plate_text=$DB2XML($(ANPR_TEXT)); camera_location=$(location); vehicle_image=$(normal_img); 162/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 163 - the overview image, Base64 encoded location - the location string as defined in default/cfs/db/location cameraid - the camera HW id, may be overridden with default/cfs/db/cameraid 163/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 164 Connection: keep-alive Content-Length: 889 Content-Type: multipart/form-data; boundary=---- WebKitFormBoundaryCAHOjxAq53NgEqQK Host: 121d219.ar.local Origin: http://121d219.ar.local Referer: http://121d219.ar.local/ User-Agent: Mozilla/5.0 (X11; Fedora; Linux x86_64) AppleWebKit/537.36 (KHTML, like Gecko) Chrome/92.0.4515.107 Safari/537.36 164/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 165 - formats the web search (getdata) with this template user_template - formats the files to be uploaded with this template filename_template - format the names of the files to be uploaded with this template 165/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 166: Engine Manager (Smart Cameras Only)

    This module will deliver its response in the binary part either as an XML document or a JPEG file. Pipeline The pipeline can be built freely, up to 8 elements, in any order. The following example can be configured. 166/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 167 Stages The following stages can be stitched in any order you like (most of the possible combinations are obviously meaningless, but this is the only way to ensure flexibility). 167/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 168 VIDAR User Manual Single Capture Its task is to receive and decompress the images and provide them with an event ID and index. 168/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 169 / priority - line priority • proc / port - the value of the image receiving port (this should also be used on the sending side if you change it) 169/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore...
  • Page 170 License plate position, syntax, etc. based on the pictures you get points and the license plate that gets the most points will be the selected picture. 170/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 171 (radar, virtual loop, vvq triggers) manually entered frames License plate frame found by previous stages Using a frame found by a vehicle detector (hydet) 171/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 172 / syntax00 / syntax - Syntax L - letter, D - digit, pl LLLDDD is the Hungarian license plate. • syntax / syntax00 / syntax_weight - Syntax weight (how many points the license plate gets if it matches the given syntax) 172/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 173 / lrtext - See above • lpr / min_confidence - Required ANPR confidence, discarding under it. Can be turned off with • proc_units / nthreads - See above 173/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 174 - the location of the hydetect engine in the property tree • minsizex, etc. - the minimum / maximum x or y object size specified in % of the image size 174/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 175 • postproc / titler / alt_charset - caption alternative font • postproc / titler / titler_grp - subtitle property group 175/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 176: Result Upload (Only Smart Cameras)

    <method value="-1"/> <maxtryconnect value="1"/> </general> <http> <host value="192.168.1.250"/> <content value="7"/> <timeoutms value="2000"/> </http> <ftp> <host value="192.168.1.250"/> <content value="7"/> <timeoutms value="2000"/> <username value="user"/> <password value="pass"/> </ftp> </uplm> 176/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 177 UploadMan:: Cannot initialize curl. • UploadMan:: Upload is disabled. • UploadMan:: No HTTP host defined. • UploadMan:: No FTP host defined. • UploadMan:: No FTP username defined. 177/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 178: Clear Database/Remove Record (Smart Cameras Only)

    This module will deliver its response in the binary part either as an XML document or a JPEG file. Restart license plate reading module http://[camera ip]/lpr/cff?cmd=restart ANSWER: <ans>\r\n <ecode value="0"/>\r\n </ans> 178/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 179: System Information

    VIDAR User Manual 12.30. SYSTEM INFORMATION Module: stat/identify, stat/system, hwlayer/cperiph Manual: Get information about system diagnostic values GET: http://camera_ip/stat/identify?getall&wfilter=X http://camera_ip/stat/system?getall&section=memory&wfilter=X http://camera_ip/hwlayer/cperiph?getcamtemp&panel=0&wfilter=X http://camera_ip/hwlayer/sensors?getEv&device=lightsensor&wfilter=X 179/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 180: Camera Log

    (It is possible to set the already queried rows to be deleted. See: plainconfig mode parameter) SET: http://camera_ip/logging/logstream?filter=uarttrigger&save&wfilter=X http://camera_ip/logging/logstream?filter=*&save&wfilter=X • '*' no filtering is applied Only Smart cameras: GET: http://camera_ip/lpr/cff?cmd=getfcontent&name=/mnt/data/cfreeflow/cff.log The answer is base64 encoded. • 180/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 181: Black/Whitelist (Smart Cameras Only)

    - rule identifier, the other tables refer to it • name • mode - whether black (0) or white (1) list • active - is the given rule active (1) 181/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 182 - within which (eg which from several UploadManagers - for example, in case of 3, it uses the Upload Manager configured under * default / cfs / uplm / extras / uplm3) 182/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 183 (whitelist, we do not penalize them, eg ambulance on the highway), and we define a default rule for all others (they can be penalized). 183/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 184 Listing the already existing rules (by default the list is empty) rules (e.g.: http://192.0.2.3/lpr/cff?cmd=querydb&sql=SELECT * FROM rules) SELECT * FROM • Delete a selected rule rules id='[rule id]' DELETE FROM WHERE (e.g.: http://192.0.2.3/lpr/cff?cmd=querydb&sql=DELETE%20FROM%20rules%20WHERE%20id=’ 9’) 184/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...
  • Page 185 [values 0 (column values separated by commas) [values 1 (comma-separated column values] (...) [values N (column values separated by commas) For example: vehicles (rule_id,plate) "2","ABC123" "2","DEF456" "2","GHI678" "2","JKL901" "2","MNO234" 185/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 186: Restart

    General syntax: mnXX=group of the module/ name of module\r\n mvXX=version of the module\r\n mdXX=description of the module\r\n where XX is the index of the module 186/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 187: Carmen Anpr Reference Manual

    VIDAR User Manual CARMEN ANPR REFERENCE MANUAL latest Carmen ANPR Reference Manual found this page: https://adaptiverecognition.com/app/uploads/DOC/Software/Carmen/ANPR/carmen_anpr_ref erence_manual.pdf 187/188 Adaptive Recognition America Adaptive Recognition Nordic REQUESTINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 188: Contact Information

    Web: adaptiverecognition.com/support/ Adaptive Recognition Hungary Technical Support System (ATSS) is designed to provide you the fastest and most proficient assistance, so you can quickly get back to business. Information regarding your hardware, latest software updates and manuals are easily accessible for customers via our Documents Site (www.adaptiverecognition.com/doc...
