Summary of Contents for Adaptive Recognition Einar 5

  • Page 2: Table Of Contents

    EINAR 5 USER MANUAL EINAR 5 USER MANUAL v. 1.0.1. Document version: 2021-07-20 Firmware version: 1.6.1.0 Table of Contents Overview ..............................4 1.1. Default IP Address ..........................5 1.2. Finding Cameras ..........................5 Overview of the Web Interface ........................ 6 Live ................................
  • Page 3 EINAR 5 USER MANUAL 6.4. System / Security ..........................21 6.5. System / Storage ..........................23 6.6. System / IO ............................27 6.7. System / Service..........................27 6.8. Media / Image ..........................28 6.9. Media / Video ........................... 32 6.10.

  • Page 4: Overview

    EINAR 5 USER MANUAL OVERVIEW The Einar cameras have their own web interface through which the camera settings, the LIVE, the PLAYBACK, the EVENTS and the SETTINGS interfaces are accessible. It is recommended to update the browser to the latest version in order to use properly the web interface of the Einar cameras.

  • Page 5: Default Ip Address

    EINAR 5 USER MANUAL 1.1. DEFAULT IP ADDRESS According to the factory setting of the Einar cameras, they request IP address from the DHCP server. The DHCP server lists the IP addresses of the DHCP clients, thus the received IP addresses belonging to the cameras connected to the network can be seen on that interface.

  • Page 6: Overview Of The Web Interface

    EINAR 5 USER MANUAL OVERVIEW OF THE WEB INTERFACE For the camera settings the following menu items are available on the web interface: 1. LIVE The live stream of the camera can be seen. 2. PLAYBACK The recordings stored on the SD card can be played.

  • Page 7: Live

    EINAR 5 USER MANUAL LIVE After logging in, the live stream of the camera can be seen which can be found on the LIVE tab. On this interface the current camera image can be seen. 3.1. FULL SCREEN MODE The live stream of the camera can be displayed in full screen by clicking on the icon located in the bottom-right corner of the image.

  • Page 8: Saving Live Stream

    EINAR 5 USER MANUAL 3.2. SAVING IMAGE Next to the Full screen icon can be found the Save image icon. By clicking on it an image of the current live stream with previously selected OSD information will be saved. The CTRL + S keyboard shortcut can be used as well.

  • Page 9: Overlay

    EINAR 5 USER MANUAL 3.5. OVERLAY In the middle at the bottom of the window the Overlay button is located where the OSD can be turned on/off and the masks of the applied detectors, image information, motion data etc. can be viewed.

  • Page 10: Playback

    EINAR 5 USER MANUAL PLAYBACK The PLAYBACK interface is accessible if the storage is turned on. By clicking on this tab, the recordings stored on the SD card will be listed and can be played by clicking on the required one.

  • Page 11: Search Among The Recordings

    EINAR 5 USER MANUAL 4.1. SEARCH AMONG THE RECORDINGS The searching among the recordings can be performed by using the timeline and calendar. The timeline is the black bar under the camera image. The blue or gold bands indicate those time intervals where recordings exist.

  • Page 12: Filtering The Detectors

    EINAR 5 USER MANUAL 4.2. FILTERING THE DETECTORS A list about the configured detectors and events related to them can be found on the right of the PLAYBACK interface. The display of the events can be turned on/off on the timeline and in the list by clicking on the detector.

  • Page 13: Exporting The Recordings

    EINAR 5 USER MANUAL 4.3. EXPORTING THE RECORDINGS The important video clips can be exported. The video clip can be saved as an mp4 file and can be played and viewed by most programs capable of playing videos. The "Export" button is located in the bottom-right corner of the PLAYBACK interface. By clicking on this button, a dialog box pops up, and 2 gold arrows appear on the timeline.

  • Page 14: Events

    EINAR 5 USER MANUAL EVENTS The EVENTS interface is accessible if the storage is turned on. By clicking on this tab, all events recorded by the camera will be listed. In the event browser the user can navigate between the recorded events with the scroll wheel.
  • Page 15 EINAR 5 USER MANUAL If the cursor is hovered over an event, the detector related to the event is highlighted in blue or gold in the list on the right and after a few seconds a video clip will be played.
  • Page 16 EINAR 5 USER MANUAL The configured detectors are displayed on the right. By moving the cursor over the detector, the events related to the detector will be highlighted in the event browser. By clicking on the detector, the display of its events can be turned on/off.

  • Page 17: Settings

    EINAR 5 USER MANUAL SETTINGS Under SETTINGS the parameters required for the optimal operation of the camera can be set. 6.1. SYSTEM / STATUS On this interface a summary about the important data of the camera, the installed detectors, the operating time and the ANPR licenses can be found.
  • Page 18 EINAR 5 USER MANUAL Date & time settings The current time of the camera is displayed at the Device time in the following format: year.month.day hour:minute:second. The device time can be set manually by clicking on the calendar icon. The device can be synchronized to the computer time with the Sync button next to the calendar icon.
  • Page 19 EINAR 5 USER MANUAL Firmware, ANPR, License update Click [Browse files…] on the field to be modified, then select the Firmware (.ifw), ANPR (.iep) or License (.ukeys) files to be uploaded. Finally, click on the corresponding upload button. The update process can be interrupted by clicking on the [Cancel] button located on the panel showing the status of the upload.

  • Page 20: Sytem / Network

    EINAR 5 USER MANUAL 6.3. SYTEM / NETWORK In the Network menu item, the network settings are available. The IP address assigned to the camera can be static or dynamic. Default DNS: 8.8.8.8 Fallback to static In the case of setting the device to DHCP, the "Fallback to static" option will be accessible.

  • Page 21: System / Security

    EINAR 5 USER MANUAL Monitoring On the Monitoring tab the media outputs (e.g., IVS connection) and their data can be viewed. Besides, all crossing data traffic can be seen sorted by adapters. 6.4. SYSTEM / SECURITY In the Users database the maintenance of the user data can be performed, like: •...
  • Page 22 EINAR 5 USER MANUAL Sessions At Lockout policy the maximum number of failed login attempts can be adjusted. After reaching the specified number, the device blocks that session. By default, after 3 failed login attempts the camera blocks the client for 1 minute. In order to enhance the network security, it is possible to modify these parameters.

  • Page 23: System / Storage

    EINAR 5 USER MANUAL 6.5. SYSTEM / STORAGE The settings related to the storage can be performed at Storage. After enabling the storage function, select a storage drive at Storage device where the images, video streams and events are to be saved.
  • Page 24 EINAR 5 USER MANUAL Recordings before and after activation (seconds) The time (in seconds) of the recording before and after the events can be regulated with the help of the sliders. Selected detectors It may not be necessary to record at every detector signaling thus the user can select which detector signals should trigger the recording.
  • Page 25 EINAR 5 USER MANUAL Setting of the GDS upload Enable the upload to the GDS at "Target", then enter the required data to set the GDS server. The following fields should be defined: • Server: Address (IPv4) of the GDS server •...
  • Page 26 EINAR 5 USER MANUAL Setting of the HTTP(s) upload Enable the upload to the HTTP POST at “Target”, then enter the Host IP address to set the HTTP event receiver. Page 26/38 SENDINFO@ADAPTIVERECOGNITION.COM Adaptive Recognition America Adaptive Recognition Nordic Adaptive Recognition Hungary Adaptive Recognition Singapore WWW.ADAPTIVERECOGNITION.COM...

  • Page 27: System / Io

    EINAR 5 USER MANUAL 6.6. SYSTEM / IO The I/O ports allow communication between the information processing system (in this case the camera) and the outside world (e.g., a person, computers, alarms, barriers etc). The conditions related to the information coming from the outside world to the camera through the input ports (input signals) can be adjusted by clicking on the [Edit] button at the Inputs tab.

  • Page 28: Media / Image

    EINAR 5 USER MANUAL • Service port: The service port of the Webserver can be specified by filling in the field. RTSP • Service port: The service port of the RTSP can be specified by filling in the field. •...
  • Page 29 EINAR 5 USER MANUAL The following elements can be fine-tuned: • Brightness: It sets the image brightness. • Brightness control speed: It sets the speed of adaptation to the changing lighting conditions (e.g., in a dark room the light is switched on and how quickly the camera can adapt to the new lighting condition).
  • Page 30 EINAR 5 USER MANUAL • Max WDR ratio: The WDR merges two images. One of the images adjusts the exposure time to the brighter and the other one to the darker spots. Therefore, the combination of the two images results in less burned bright spots and more visible dark spots. The Max WDR ratio adjusts the maximum overlap of the two images.
  • Page 31 EINAR 5 USER MANUAL Presets Pre-set values can be selected which are calibrated to different situations. These elements are not necessarily ideal settings for all cases, they are to be considered as guidelines. They show generally acceptable image settings for certain scenarios.

  • Page 32: Media / Video

    EINAR 5 USER MANUAL 6.9. MEDIA / VIDEO When clicking on the Video menu item the functions related to the video encoders are displayed. Above these the livestream of the camera remains visible. On this interface the settings (name, resolution, frame rate etc.) of the Stream 1 and Stream 2 can be performed separately.

  • Page 33: Media / Lens

    EINAR 5 USER MANUAL Encoders If it is enabled, the following can be fine-tuned: • Target bitrate (kbps): The bandwidth size can be adjusted. The values to be set alternate stream by stream. • I-frame interval (GOP): The density of the I frames can be specified.

  • Page 34: Analytics / Detectors

    EINAR 5 USER MANUAL 6.11. ANALYTICS / DETECTORS The camera detectors can be added, modified or deleted on this window. The list of the detectors differs by camera types except for Motion detector which can be found on all types.
  • Page 35 EINAR 5 USER MANUAL The mask can be modified by clicking on the green area. The mask can be deleted by clicking on the [Delete selection] button located under the live stream: Sensitivity: It sets the sensitivity of the motion detector.
  • Page 36 EINAR 5 USER MANUAL ANPR detector and ANPR engine The ANPR detector and the ANPR engine perform the reading of license plates in combination. The both must be present on the camera in order to operate the system. They are only present on the cameras designed to read license plate.
  • Page 37 EINAR 5 USER MANUAL ANPR detector The ANPR detector is responsible for transmitting the events. The ANPR detector must be defined separately. The primary functions of the detector cannot be set at ANPR detector section, but on the interface of the ANPR engine.

  • Page 38: Contact Information

    EINAR 5 USER MANUAL Contact Information Headquarters: Service Address: Adaptive Recognition, Hungary Inc. Adaptive Recognition, Hungary Inc. Alkotás utca 41 HU- Ipari Park HRSZ1113/1 HU 1123 Budapest Hungary 2074 Perbál Hungary Phone: +36 1 201 9650 Phone: +36 1 2019650...
