Sherco SE125 Factory
What's in the box ?
2 NE01-11-001 - THF 6x25mm screws
3 NE01-04-002 - Clamped bolts
2 NE01-02-002 - TFHC 6x20mm screws
1 NE01-02-003 - TFHC 6x25mm screw
4 NE01-02-004 - TFHC 6x30mm screws
6 NE01-04-003 - EM6F bolts
6 NE01-03-001 - M6 washers
2 PM01-04-288 - HDPE rear hooks
1 NE04-01-275 - Sticker
1 PM01-06-085 - Rear plate n°50
The paper instructions may be limitless, scan the QR
code to watch the tutorial video online.
Approximate time of assembly: 15 minutes.
A skid plate is made to protect the vital components of your bike and does not have a « life warranty ».
However, production default may happen and we cover it during the first year of use.
In case of premature breakage, please write to contact@axpracing.com
AX1760
Xtrem skid plate
Assembling
instructions
Advertisement
Related Manuals for aXp RACING AX1760
Summary of Contents for aXp RACING AX1760
- Page 1 Assembling AX1760 Xtrem skid plate instructions Sherco SE125 Factory What’s in the box ? 2 NE01-11-001 - THF 6x25mm screws 3 NE01-04-002 - Clamped bolts 2 NE01-02-002 - TFHC 6x20mm screws 1 NE01-02-003 - TFHC 6x25mm screw 4 NE01-02-004 - TFHC 6x30mm screws...
- Page 2 Follow the steps ! Fix the rear hooks on the skid Place one clamped bolt on the rear of the frame, and 2 on the plate using TFHC 6x30mm front for the fixation. screws + washers and bolts and tighten. Clip the plate on the frame Tighten the screw.
