Duo 2 WiFi
Duo 2 WiFi can stitch two views into one with no gap, realizing true two-camera
combination. It brings a smoother image with double field of view and without
overlapping part! It can not only detect moving people and vehicles, but also
detect your cats and dogs. Also, with the built-in mic and speaker, it's quite easy to
respond to the coming person, car, or pet.
1. Specs
1
Antenna
2
Lens
3
Daylight Sensor
4
Spotlight
5
IR LED
6
Mic
7
Mounting Bracket
Advertisement
Related Manuals for Reolink Duo 2 WiFi
Summary of Contents for Reolink Duo 2 WiFi
- Page 1 Duo 2 WiFi Duo 2 WiFi can stitch two views into one with no gap, realizing true two-camera combination. It brings a smoother image with double field of view and without overlapping part! It can not only detect moving people and vehicles, but also detect your cats and dogs.
- Page 2 And the actual package content are subject to the latest information on the product selling page. Duo 2 WiFi Surveillance Sticker*1 1m Network Quick Start Guide*1 Reolink Duo 2 WiFi*1 Cable*1...
- Page 3 Screwdriver*1 Mounting Hole Template Pack of Screws*1 Mounting Plate *1 Power Adapter Antennas *1 4.5m Power Extension Waterproof Lid *1 12V/2A *1 Cable *1 Set up the Camera on the App For initial setup, please power on this camera with a DC adapter and also connect the camera to your router LAN port with an Ethernet cable, and then follow the steps to set up your camera.
- Page 4 3 directly. Step 2. Scan the QR code on the back of the camera. You may tap Light to enable a flashlight when setting up the camera in a dark environment. If the phone doesn't respond, please tap Input UID/IP and then manually type in the UID (16-digit characters under the QR code of the camera).
- Page 5 Step 4. Name your camera. Then tap Next. Step 5. Tap the WiFi network you want to join, and enter the password of the WiFi network. Then tap Save to save the network configuration.
- Page 6 Step 6. Done! The initialization of your camera is finished. Note: If this device can't connect to the WiFi after you remove the Ethernet cable, you can connect it to the router again and see if it can pass the WiFi test. Install the Camera We offer you guides on different scenes in which the camera could be installed.
- Page 7 Step 2. Adjust the camera's view. Loosen the adjustment screw on the security mount with the screwdriver (also included in the box) and turn the camera until you get the ideal view. Step 3. Fix the camera firmly. Tighten the adjustment screw to keep the camera still. Done! You've successfully mounted your camera on the wall.
- Page 8 included in the box) and turn the camera until you get the ideal view. Step 3. Fix the camera firmly. Tighten the adjustment screw to keep the camera still. Finished! Now you may start using your camera.
