Ideal Heating ECOMOD 290HT Installation & Servicing

Hide thumbs Also See for ECOMOD 290HT:
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLATION
& SERVICING
ECOMOD 290HT HEAT PUMP
AHP-70-40 - AHP-70-50
40 & 50KW
When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance
specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.
For the very latest copy of literature for specification and maintenance practices visit our website idealheating.com
where you can download the relevant information in PDF format.
Data Plate marker. If no data plate is to be
12/2024
placed here then this marker can be removed

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ECOMOD 290HT and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ideal Heating ECOMOD 290HT

Summary of Contents for Ideal Heating ECOMOD 290HT

  • Page 1 When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require. Do not use reconditioned or copy parts that have not been clearly authorised by Ideal Heating.

  • Page 3: Table Of Contents

    Installation, Use and Maintenance - ECOMOD-40/50 CONTENTS 1. REGULATIONS, RECOMMENDATIONS AND WARNINGS ..........5 1.1. Regulatory compliance ..........................5 1.2. Recommendations and warnings ........................ 5 2. DESCRIPTION OF THE EQUIPMENT ................17 2.1. Designations, definitions and scope ......................17 2.2. Packaging ..............................17 2.3. Technical data ............................18 2.4.
  • Page 4 ECOMOD-40/50 - Installation, Use and Maintenance 8. END OF PRODUCT LIFE ....................89 9. SPARE PARTS LIST ......................90 10. ANNEX A - .................102 DATA FOR PRODUCTS ≤ 70KW Symbols used in this document INFORMATION: This symbol draws attention to comments. Failure to comply with these instructions may cause damage to the CAUTION: installation or to other objects.

  • Page 5: Regulations, Recommendations And Warnings

    REGULATIONS, RECOMMENDATIONS AND WARNINGS 1.1. Regulatory compliance This outdoor unit has been designed in compliance with the regulations in force, and must be used within the framework of those regulations. In particular, it complies with the Machinery Directive, the Pressure Equipment Directive, and the Electromagnetic Compatibility Directive. It has also been designed in accordance with the Directives relating to eco-design and energy labelling.

  • Page 6: Unpacking The Appliance

    In the event of a dispute, write to the carrier within 48 hours mentioning all reserves and send a copy of this letter to the SATC department of the Ideal Heating. Before unpacking the appliance, check that there are no refrigerant leaks using a suitable detector. Check that there are no ignition sources near the unit.
  • Page 7 Designation R290 INDICATION OF DANGERS Main dangers: Highly flammable and explosive class A3 fluid. R290 vapours are heavier than air and can cause asphyxiation due to an oxygen concentration level reduced to a level at which the fluid can stagnate. Specific dangers: Contact with R290 fluid in liquid form can cause frostbite. FIRST AID MEASURES General information In case of a high concentration, the fluid can cause asphyxiation. Loss of mobility and/or consciousness are characteristic symptoms. A narcotic effect may be observed at a lower concentration level. Inhalation Wear a self-contained breathing apparatus, and transport the victim to an uncontaminated location.
  • Page 8 CONTROLLED EXPOSURE/INDIVIDUAL PROTECTION Control parameters OEL: No data available DNEL: No data available PNEC: No data available Respiratory protection Filter masks may be used where ambient conditions or duration of use are known. Protection of the eyes Safety glasses Hand protection Rubber work gloves Hygiene measures Do not smoke PHYSICAL AND CHEMICAL PROPERTIES Colour Colourless. Odour Odourless Boiling point -42.1°C at atmospheric pressure Flash point 470°C Relative density in gaseous form (air = 1) Relative density in liquid form (wa-...
  • Page 9 Warning specific to the R290 refrigerant This appliance functions with class A3 R290 fluid (ISO817:14 classification). In the event of a leak, the diffusion of R290 into the environment can lead to the formation of a highly flammable and explosive atmosphere. R290 refrigerant has no odor.
  • Page 10 Pump down and refrigerant fluid charge Refrigerant pump down, charging and recovery procedures may only be performed by specialised technicians or qualified personnel who have received adequate training in the handling of flammable gas, have specific skills, and comply with local laws. The refrigerant fluid charging procedure is described in paragraph 7.1. of this document. Below is a list of safety precautions that is not necessarily exhaustive: Ensure that no other substance is contaminating the R290 fluid. To recover the refrigerant fluid, use bottles with a left-hand fitting and a suitable screw thread. The maximum filling capacity must be 0.42kg/l.
  • Page 11 Precautions related to the installation of the refrigerant If local construction codes or safety standards do not exist, the information shown below, which is taken from standard EN 378:2016, may be used for information purposes only; it can be used as a guide for the safe use of machines that use a refrigerant. This unit must be installed in such a way that no refrigerant leaks can be introduced into the building and/or endanger people and property. Therefore: It must not be possible for the refrigerant to spill into a ventilation duct, under a door, hatch or similar opening in case of a leak.
  • Page 12 Controller Control of the installation Outdoor sensor QAC 34 Controller/HP communication bus B10 (QAZ 36) Electrical Electrical cabinet back-up Control/ No. 1 Power IHM PAC Electrical back-up No. 2 Charging tank No.1 Heat pump Motorised 3-channel NOMENCLATURE Temperature sensor Thermostatic mixing Direct-reading Safety group valve valve balancing valve...
  • Page 13 A refrigerant fluid degassing device is supplied with this appliance. Its installation is mandatory to limit the propagation of fluid in case the CAUTION: plate exchanger breaks. It must be immediately connected to the water outlet of the appliance. DANGER: The introduction of R290 fluid into the building may generate a highly flammable or explosive atmosphere and is STRICTLY PROHIBITED.

  • Page 14: General Safety Rules

    1.2.5. General safety rules Before starting any work on the units, each operator must be thoroughly familiar with how the machine operates and its controls and must have read and understood all the information contained in this manual. The removal and/or handling of any safety device is strictly prohibited. Unaccompanied children and persons with disabilities are not allowed to use the appliance. Touching the appliance with bare feet or with wet or damp body parts is prohibited.
  • Page 15 1.2.6. Worker safety The European Community has published a number of directives concerning the safety and health of workers, including: 89/391/EEC, 2016/425, 2009/104/EC, 2003/10/EC, and 95/58/EEC, and successive integrations/amendments which each employer is obliged to respect and enforce. We would therefore like to remind you that : It is forbidden to replace or modify parts that are not original manufacturer's parts. In this case, the Ideal Heating disclaims any civil or criminal liability. Any person involved in handling in the danger zone must have received specific training on the risks associated with the use of R290 in thermodynamic equipment.

  • Page 16: Personal Protective Equipment

    1.2.7. Personal protective equipment When using and maintaining the units, personal protective equipment must be used, such as : Leak detector: When approaching the unit and before any operation, check that there are no gas leaks on the unit. Clothing: Persons performing maintenance or working on the system should wear clothing that does not leave any parts of the body uncovered, as during maintenance there is the possibility of coming into contact with hot or sharp surfaces. Clothing that can get caught or be sucked in by the air flow should be avoided.

  • Page 17: Description Of The Equipment

    Installation, Use and Maintenance - ECOMOD-40/50 DESCRIPTION OF THE EQUIPMENT 2.1. Designations, definitions and scope Ecomod AHP70: Monobloc inverter heat pump operating with R290 refrigerant. This unit is suitable for producing hot water to irrigate heating networks, or domestic hot water separated by a heat exchanger. The heat pump is sometimes also referred to as an outdoor unit. Air/Water: The outdoor air is the energy source.

  • Page 18: Technical Data

    ECOMOD-40/50 - Installation, Use and Maintenance 2.3. Technical data 2.3.1. Technical Specifications This product is designed to be installed at a maximum altitude of 2000m AHP70-40 AHP70-50 TECHNICAL CHARACTERISTICS Unit 40Kw 50Kw Minimum/nominal thermal power (1) 40.0 50.1 Absorbed power (1) 9.76 11.9 COP (1) 4.21 Minimum/nominal thermal power (2) 38.1 47.9 Absorbed power (2) 13.4 16.5 COP (2) 2.84 2.90 Minimum/nominal thermal power (7) 38.5 45.9 Heating Absorbed power (7) 16.3...
  • Page 19 Installation, Use and Maintenance - ECOMOD-40/50 Noise level Lw (9) dB (A) Acoustic emissions Acoustic pressure at a distance of 10 m dB (A) Lp1 (10) Length 1895 Width 1110 Height 1920 Length packed 1980 Dimensions and weight Width packed 1110 Height packed 2040 Weight for shipping Weight in service The above performances are given for the following operating conditions, as per the standard EN 14511:2022: (1) Heating: external air temperature 7°C dry temperature (dT) 6°C humid temperature (hT); inlet/outlet water...
  • Page 20 ECOMOD-40/50 - Installation, Use and Maintenance 2.3.2. Ancillary electrical data V/~/Hz unit power supply 3P+N / ~400V / 50HZ V/~/Hz user interface circuit 2 / ~12V / 50Hz V/~/Hz fan power supply 2 / ~230V / 50Hz * Acceptable variations: +/- 10% REMARK: The electrical data may be modified. You must consequently refer to the data label on the RH side panel of the appliance. 2.3.3.

  • Page 21: Description

    Installation, Use and Maintenance - ECOMOD-40/50 2.4. Description 2.4.1. Dimensions IN/OUT : 1 1/2” grooved E: electricity supply input 1750 1110 figure 2 - Dimensions of the appliance only, in mm 2.4.2. Position of the barycentre and the anti-vibration elements The position of the centre of gravity of each machine is indicated in the tables, with reference to the dimensions indicated on the image.
  • Page 22 ECOMOD-40/50 - Installation, Use and Maintenance The positions laid down for the installation of the vibration shock absorbers for each type of machine are presented in the images below. Model A (mm) B (mm) C (mm) D (mm) 40kW 1410 50kW 1410 2.4.3. Dimensions of the zones around the heat pump The appliances contain R290 refrigerant. Since the density of this gas is higher than that of air, it tends, in the event of a leak, to disperse and stratify, accumulating in recesses or on the ground.
  • Page 23 Installation, Use and Maintenance - ECOMOD-40/50 A danger zone (X) is defined as an area circled in red around the machine in which, in the event of a refrigerant leak, a flammable atmosphere is formed for a short time, and in which it is necessary to implement all the precautions described in the manual. In the absence of specific standards or regulations, when using the unit in an industrial or working environment, it is advisable to classify the places that have...
  • Page 24 ECOMOD-40/50 - Installation, Use and Maintenance Open field installation For units installed in open field, the danger zones (solid red line) and the vigilance zones (dotted black line) are shown in the figures below: Dimension Limit ( mm) 1500 3000 4850 7850 4110 7110 Installation against a wall (near door, window, low point, etc.) In the case of units installed on the ground in front of a wall, the danger zones (solid red line) and the vigilance zones (dotted black line) are shown in the figures below: Dimension Limit ( mm) 1500 3000 4850 7850 1500 24 / 104 00U07782290-D_EN...

  • Page 25: Multiple Installations

    Installation, Use and Maintenance - ECOMOD-40/50 Installation in a corner For units installed on the ground in a corner, the danger zones (solid red line) and the vigilance zones (dotted black line) are shown in the figures below: Dimension Dimension Limit Limit ( mm) ( mm) 1000 2750 1500 4250 Installation on a flat roof The installation on a flat roof is similar to that on open ground, however some additional aspects must be taken into account: Position the machine away from the exterior walls of the building and any protrusions, beyond the safety zone. Ensure that the roof and building structures are strong; choose a location where snow, dust or leaves do not accumulate. Bear noise emissions in mind and keep a sufficient distance from surrounding buildings. If high air speeds are encountered, install shields to reduce the wind speed (see 3.3.1). It is not advisable to have drains in the heat pump’s vigilance zone.

  • Page 26: Access To Internal Components

    ECOMOD-40/50 - Installation, Use and Maintenance Valori Rif. Misura 1500 MODEL AHP-70 3000 2200 40kW 1500 3000 1500 50kW 1500 3000 1500 For other types of installation not covered by this manual, contact the pre-sales service. If in doubt about the installation of the appliances, ask the fire department or a fire prevention expert for a technical assessment. 2.4.4.
  • Page 27 Installation, Use and Maintenance - ECOMOD-40/50 2.4.5. Position of the thermostat and the temperature sensors The safety thermostats are located on the compressor discharge tubes (positions D and D’ in the figure). To access them, remove the insulation from the component. Inside the machine there are 6 temperature sensors: the inlet and outlet sensors on the water side (positions B, C) and the compressor suction and discharge sensors (positions A, E, E’), while the outside air sensor (position F ) is on a dedicated support. The sensors on the compressor piping are secured with clips to their respective thermowells.

  • Page 28: Operating Principle

    ECOMOD-40/50 - Installation, Use and Maintenance 2.5. Operating principle 2.5.1. Heat production When the heat pump is operating in heat production mode, other than in the start-up and transition phases, the inlet water temperature must not fall below the lower line in Figure 3. A lower value can cause system anomalies, including compressor damage. At the same time, the output temperature must not exceed 75°C.

  • Page 29: Installation

    Installation, Use and Maintenance - ECOMOD-40/50 Water flow rate on the condenser The nominal water flow rate is determined for a temperature difference of 5°C between the inlet and the outlet of the evaporator. The maximum authorised flow rate is that with a temperature difference of 3°C whereas the minimum is that with a temperature difference of 10°C in nominal conditions, as shown on the data sheet. For more detailed information, the table below indicates the minimum flow rates to the condenser to be guaranteed in order to ensure that it operates correctly according to the model, and the disconnection and restart flow rates of the appliance depending on the flow rate. Insufficient water flows can cause condensation temperatures that are too high, causing the intervention of the safety devices and CAUTION: the switching off of the unit and, in some extreme cases, severe refrigeration circuit failures.

  • Page 30: Lifting Method

    ECOMOD-40/50 - Installation, Use and Maintenance 3.1.2. Lifting method The authorised lifting methods are: • fork lift truck, • ropes/chains. Lift progressively and check that the ropes/chains are in the correct position. figure 5 - Lifting with ropes/chains figure 4 - Lifting with a fork lift truck 30 / 104 00U07782290-D_EN...

  • Page 31: Installation

    Installation, Use and Maintenance - ECOMOD-40/50 3.2. Installation The choice of the position for installation is particularly important insofar as any later movement is a delicate operation requiring the intervention of a qualified person. Comply with the maximum and minimum distances for the outdoor unit (see next paragraph); the performance and service life guarantees depend on this. 3.3. Installing the outdoor unit 3.3.1.
  • Page 32 ECOMOD-40/50 - Installation, Use and Maintenance for the appliance. • Do not install the appliance in a passageway. • For correct operation and an optimal life span of your equipment, it is necessary to have a quality of water that complies with the general conditions of sale. •...
  • Page 33 Installation, Use and Maintenance - ECOMOD-40/50 Industries / risk zones Incinerators Agriculture Paper / Salt Swimming Treatment Type Corrosive product & other Cleaning & fertiliser wood extraction pools plants manufacturers combustions Nitrogen oxides (NOX) Sulphur oxides Oxides (SxOy) Carbon oxides Sulphurs Hydrogen fluoride Volatile gases or liquids Ozone Methane...
  • Page 34 ECOMOD-40/50 - Installation, Use and Maintenance It is recommended that you conduct a noise pollution risk assessment. This should take into account the residual noise without the heat pump, the machine data, the place of installation, the distance to the point of measurement, without this list being exhaustive.
  • Page 35 Installation, Use and Maintenance - ECOMOD-40/50 3.3.2. Minimum technical clearances • By following the installation precautions, it is absolutely essential to ensure the following minimum service clearances are respected. The distances B1 and B2 are required for the maintenance of the unit. The other distances are required for the unit to operate correctly.
  • Page 36 ECOMOD-40/50 - Installation, Use and Maintenance Free field above and at the level of A Free field above and at Free field above and at the level of A the level of A 36 / 104 00U07782290-D_EN...

  • Page 37: Hydraulic Connections

    Installation, Use and Maintenance - ECOMOD-40/50 3.4. Hydraulic connections 3.4.1. Accessories to be connected to the external unit - In the same way, the hydraulic connections must comply with good engineering practices ac- cording to the regulations in force. - Before making the hydraulic connections, the supply pipes must be cleaned to avoid contaminat- ing the tank with metal or other types of particles.
  • Page 38 Flow adjustment and checking are the responsibility of the installer/ operator and will not be performed by Ideal Heating. When the system is CAUTION: commissioned, a balance check will be required by Ideal Heating. If no check is performed, commissioning will be refused.

  • Page 39: Water Quality

    Installation, Use and Maintenance - ECOMOD-40/50 3.4.5. Water quality • Preparing the water system before putting the heat pump into service For any installation (new or renovation), the water pipes must be thoroughly cleaned The purpose of this initial cleaning is to eliminate germs and residue that can cause deposits to form. In new installations in particular, residue from grease, oxidised metal, and even copper micro-deposits must be scrupulously removed.

  • Page 40: Connecting Water Supply

    ECOMOD-40/50 - Installation, Use and Maintenance If there is a chance that oxygen could enter the unit, you must take additional precautions. Adding an oxygen scavenger (ex. sodium sulphite) is highly recommended. We recommend directing any water treatment questions to specialists, which can provide the appropriate treatment based on the characteristics of the installation, and a monitoring agreement with a guarantee as to the results.
  • Page 41 Installation, Use and Maintenance - ECOMOD-40/50 3.4.6.1. Precautions when connecting the water supply • Supervise all of the operations for connecting the water supply and filling. • Before connecting the water supply and filling the system, disconnect the electrical power supply to the units. • The connection of the water supply and filling of the installation must always be carried out under controlled pressure conditions (2 bar for commissioning and min. 1 bar in operation). Ensure that a pressure reducer and a safety valve have been fitted on the loading/reintegration line.
  • Page 42 ECOMOD-40/50 - Installation, Use and Maintenance Injecting additives into the hydraulic circuit that tend to foam, even slightly, can reduce the efficiency of the gas separator, or even cancel INFORMATION : its action and consequently damage the system. For example, a glycol concentration greater than 10% cancels the degassing effect, which is why this product is prohibited.
  • Page 43 Installation, Use and Maintenance - ECOMOD-40/50 POUR INFORMATION : - The moving parts that control gas/water separation can be accessed by removing the bottom cover. - The front plug marked DR is used to fit a thermometer (not supplied). - The deaerator is fitted with a magnetic bar. - There is no direction of water flow in / out. Below is the correct mounting direction: - To clean the gas separator, the system must first be partially drained. Next, unscrew the part of the body containing the vent valve and the fluid separator element. The latter cannot be removed separately. Anyone working on the HP must be trained and ATTENTION : equipped to handle the R290. 3.4.6.3. Degassing function This function is used to drain the system, using the circulator at maximum speed.

  • Page 44: Electrical Connections

    ECOMOD-40/50 - Installation, Use and Maintenance 3.5. Electrical connections Ensure that the general electrical power supply has been switched DANGER: off before starting any repair work. The protective earth conductor must be longer than the phase and neutral conductors. Furthermore, the main earth conductor and the power supply conductors must have a double attachment very close to their connections. The electrical panel is located under the cover. The minimum spaces indicated in paragraph 3.3.2 must be respected for the electrical connections.

  • Page 45: Accessing The Electrical Panel

    Installation, Use and Maintenance - ECOMOD-40/50 3.5.2. Accessing the electrical panel The electrical panel is accessible when the unit is off and is positioned on the compressors’ side. To open the panel door, you must turn the disconnect switch to the OFF position and use a double-bit key in both of the locks present. All of the installation operations must be carried out when the heat pump is stopped, and after disconnecting the electrical power supply.

  • Page 46: Current Source

    ECOMOD-40/50 - Installation, Use and Maintenance 3.5.3. Current source Electrical connections must only be carried out by QUALIFIED PERSONNEL, in compliance with the legislation in force. Ensure that an adequate earth connection is installed, as inadequate earthing CAUTION: can cause electrical shocks. The manufacturer cannot be held responsible for damage caused by ineffective or absence of earthing.
  • Page 47 Installation, Use and Maintenance - ECOMOD-40/50 12-12-2024 47 / 104...

  • Page 48: User Terminal

    ECOMOD-40/50 - Installation, Use and Maintenance 3.5.4. User terminal The terminal board is located beneath the cover of the machine. To access it, refer to the chapter 3.7.2. The board must be connected in accordance with the notes below. The connections shown below are standard. CAUTION: It is important to separate high voltage cables from very low voltage cables Morsettiera di potenza XF-1 XF-2 XF-3 XF-1 XF-2 XF-3 Control terminal block Power terminal block 8A fuse holder terminal block XF1 / XF2 / XF3 Power supply to fans Morsetti XF-1...
  • Page 49 Installation, Use and Maintenance - ECOMOD-40/50 Connection Type Terminals Connect the earth cable Connect the neutral cable from the main power supply 3-Ph/N/PE power supply, Connect the L1 phase cable from the main power supply 400 Vac, 50Hz. Connect the L2 phase cable from the main power supply Connect the L3 phase cable from the main power supply XC-1.1 Controller / OCI 351 GND terminal use a 3x0.5mm shielded stranded cable XC-1.2 Controller / OCI 351 terminal B - MAX length: 1000 m Bus terminator: 120 Ohm XC-2.1 Controller / OCI 351 terminal A+ and 1 nF...
  • Page 50 ECOMOD-40/50 - Installation, Use and Maintenance 3.5.5. Refrigerant fluid leak detection sensor Each unit is equipped with an independent refrigerant fluid detection system inside the refrigerant circuit compartment to monitor any gas leaks. The R290 sensor is to be recalibrated at least every 12 months, we recommend doing this at the beginning of the heating seasons. To carry out INFORMATION : this operation, you will require which can be obtained by contacting Ideal.
  • Page 51 Installation, Use and Maintenance - ECOMOD-40/50 CAUTION: Exposure to silicones, silicates, silanes, substances containing chlorine, iodine, bromine, fluorine and other halides significantly inhibits sensor performance, which can lead to sensor failure. CAUTION: When the sensor detects very high gas concentrations (out-of-range status), its sensitivity or zero point may vary: always have the sensor checked by a qualified support centre after each intervention on the instrument, and, if necessary, proceed with recalibration or possible replacement.

  • Page 52: Pre-Requisites Before Commissioning

    ECOMOD-40/50 - Installation, Use and Maintenance Pre-requisites before commissioning 4.1. Verification before switching on • Check that there are no leaks. Each operator must be equipped with a personal explosimeter for R290 gas and a leak detector. • Remove the protective cap from the R290 detector of the HP. Check that the electrical and hydraulic diagrams of the installation the machine is •...

  • Page 53: Switching On

    Installation, Use and Maintenance - ECOMOD-40/50 4.2. Switching On Switching on with an incorrect power supply will result in the immediate IMPORTANT: destruction of some electronic components. To switch on the machine, turn the outer handle of the isolator switch to the ON position (shown by “I”). The display on the machine will only be switched ion if the order of the phases is correct (to be checked when switched on for the first time) and the sensor has completed its warm-up phase (5 min.). After powering down, wait for at least 1 minute...

  • Page 54: Operating Diagram

    ECOMOD-40/50 - Installation, Use and Maintenance 4.4. Operating diagram figure 9 - Operating diagram SIGN DESCRIPTION SIGN DESCRIPTION INVC Variable speed compressor Liquid and humidity indicator CO/EV Condenser/evaporator on the source side Non-return valve EV/CO evaporator/condenser on usage side High pressure transducer Liquid receiver Low pressure transducer Liquid separator...

  • Page 55: Navigating The User Interface

    Installation, Use and Maintenance - ECOMOD-40/50 4.5. Navigating the User Interface U: user S: Specialist protected by password (195) * Only if fault in progress ** Only if USB drive detected with suitable files 12-12-2024 55 / 104...

  • Page 56: Control Interface

    ECOMOD-40/50 - Installation, Use and Maintenance CONTROL INTERFACE 5.1. Recommendations and warnings The removal and/or handling of any safety device is strictly prohibited. This appliance should only be used by authorised persons. Working on the appliance when it is in operation is prohibited. The modification of the programming of the appliance by an unauthorized person is prohibited. Touching the appliance with bare feet or with wet or damp body parts is prohibited. Cleaning is prohibited when the appliance is powered on. Pulling, disconnecting or twisting the electrical cables coming out of the appliance, even if the appliance is disconnected from the power supply, is prohibited. Do not stand on the appliance, sit on it and/or place objects of any kind on it. Do not splash the appliance or spray water onto it. Do not disperse, put down or leave within the reach of children the packing material (cardboard, staples, plastic bags, etc.) as it can be a potential source of danger. All of the operations described below must be carried out BY QUALIFIED PERSONNEL ONLY.
  • Page 57 Installation, Use and Maintenance - ECOMOD-40/50 Install a suitable protective device and power switch upstream of each unit, with a delayed characteristic curve, a contact opening of at least 3 mm and adequate breaking capacity and residual current protection. The size of the circuit breaker must comply with the absorption of the unit. See the TECHNICAL DATA in the user/installer manual that accompanies the unit. Also take back-up heaters into account. Before carrying out any work on the electrical panel, IT IS MANDATORY to: - Turn off the appliance from the control panel (“OFF” is displayed). - Set the protection device to "OFF". - Wait 15 seconds before accessing the electrical panel.

  • Page 58: User Interface

    ECOMOD-40/50 - Installation, Use and Maintenance 5.2. User interface The unit is equipped with a screen placed under a hinged door made of transparent polycarbonate with an IP67 protection rating. The interface consists of a variable text part and a series of icons identifying the operation of the unit as shown in the table below. The keys have specific functions as shown below Description Select the operating mode and reset the alarms with manual reset if the External Controller is not connected and powered on.

  • Page 59: Description Of The Ui

    Installation, Use and Maintenance - ECOMOD-40/50 5.3. Description of the UI 5.3.1. MENUS The items managed by the main menu are listed below. Some of them are only visible to the installer, who will have to access the PSS menu to enter the password (0195) and allow access with greater privileges. Menu Label Password level Other conditions Setpoint User Password User Alarms User Only if alarms are active Sensors Installer Digital inputs Installer Settings Installer...
  • Page 60 ECOMOD-40/50 - Installation, Use and Maintenance 5.3.1.4. Sensor Menu [tP] By logging in with the installer password, in this menu it is possible to read the values of the temperature and pressure sensors present. DESCRIPTION Unit Input water temperature °C Water outlet temperature °C Compressor suction temperature °C Compressor discharge temperature °C Outside air temperature °C Compressor discharge temperature °C No function °C...
  • Page 61 Installation, Use and Maintenance - ECOMOD-40/50 5.3.1.7. Operating times Menu [oHr] By logging in with the installer password, you will be able to view in this menu the compressor (OH1 and OH2) and circulation pump (Ohp1) operating hours, as well as the number of compressor starts (cC1 and cC2). You can reset the displayed counter by pressing and holding the ESC button for 3 seconds 5.3.1.8. History Menu [Hist] This menu appears, after entering the installer password, only if there is data in the alarms history. Display of alarm label Exxx. Pressing the Up and Down keys will scroll through the menu, displaying the sequence of stored events. By pressing the Prog key, you enter the time reference display (after how...

  • Page 62: Controller Functions

    ECOMOD-40/50 - Installation, Use and Maintenance 5.4. Controller functions 5.4.1. Activation of digital outputs 5.4.1.1. Blocking fault report Configured by default, a voltage output signalling the presence of an alarm. Output parameter DO7 Value Function Alarm report 5.4.1.2. Defrosting A digital output can be configured to signal defrosting in progress. Output parameter DO6 Value Function Warning that defrosting is in progress 5.4.2.

  • Page 63: Troubleshooting

    Installation, Use and Maintenance - ECOMOD-40/50 TROUBLESHOOTING 6.1. Problem-solving without error code Problems encountered Cause Solution Electrical power supply absent Check the system voltage Check the protective systems The appliance does not upstream of the unit start up Electronic board damaged Replace the damaged part Compressor faulty Insufficient performance Insufficient quantity of refrigerant Check the installation of the...

  • Page 64: Error Codes And Diagnostic Assistance

    ECOMOD-40/50 - Installation, Use and Maintenance 6.2. Error codes and diagnostic assistance Code Descriptif Cause What to check What to do i-290 0240-0250 TROUBLESHOOTING PER COLLAUDO FUNZIONALE E000 Remote ON/ Digital input activated as ON/ Check the causes of the ON/ Close digital input...
  • Page 65 0 TROUBLESHOOTING PER COLLAUDO FUNZIONALE Installation, Use and Maintenance - ECOMOD-40/50 occo Causa Cosa controllare Code Descriptif Cause What to check What to do E006 Flow alarm If the flowmeter diagnoses a • Check the system pressure. • If air is present in the lack of flow for a consecutive •...
  • Page 66 è inferiore a 45°C  Verificare che siano state rispettate le regole di installazione descritte nel manuale MUI ECOMOD-40/50 - Installation, Use and Maintenance Code Descriptif Cause What to check What to do E020 Reversed When compressors have • Check correct positioning •...
  • Page 67 Installation, Use and Maintenance - ECOMOD-40/50 Code Descriptif Cause What to check What to do E631 The ST1 sensor is defective • Check that Suction sensor failure sensor securely sensor attached terminals temperature CNSG-39 CNSG-40 sensor E641 The DT1 sensor is defective. •...
  • Page 68 ECOMOD-40/50 - Installation, Use and Maintenance i-290 0240-0250 TROUBLESHOOTING PER COLLAUDO FUNZIONALE Code Descriptif Cause What to check What to do Descrizione Blocco Causa Cosa controllare Cosa fare E691 Failure Transducer connected to the • Check that • If the connection is good, of the ST9 input not connected or transducer is connected to...
  • Page 69 Installation, Use and Maintenance - ECOMOD-40/50 Code Descriptif Cause What to check What to do E802 • The compressor has not • Check the communication Timeout responded to the command cable between the Timeout for for more than 30 seconds. CN15 connector communication The communication cable CNTR1 control board and...
  • Page 70 ECOMOD-40/50 - Installation, Use and Maintenance Number of flashes Control Causes Solutions error Error description One or more power phases Check inverter of the inverter are not power phase wiring Lack of power supply phases connected E891 Defective inverter Change inverter Power phase problem (software) E911 The compressor rotor is...

  • Page 71: Maintenance Of The Outdoor Unit

    Installation, Use and Maintenance - ECOMOD-40/50 MAINTENANCE OF THE OUTDOOR UNIT During all maintenance operations, it is strictly forbidden to climb INFORMATION: onto the product. 7.1. Procedure for charging the machine The unit is delivered already filled with refrigerant fluid. If it is necessary to recharge it, after maintenance or after a leak, follow the steps below in the order indicated: • Before undertaking any work, a risk analysis should be performed and the work area should be delimited. Check that there are no potential ignition sources in the appliance. The minimum space around the unit, which must not include manholes , drains or other low points where refrigerant fluid can settle, must be greater than the danger...
  • Page 72 ECOMOD-40/50 - Installation, Use and Maintenance • Connect two hoses to the pressure sockets (positions A and B in the previous image) of the circuit and recover the totality of the refrigerant fluid. Use a suitable recovery machine (ATEX). In order not to contaminate the recovered gas, retrieve the equipment by vacuuming the pipes and the recipient. Check the condition of seals and filters frequently. It is recommended to remove the pin using a pin puller in order to significantly reduce the suction and charging time of the system; • Flush the circuit by introducing nitrogen and raising the pressure to 4-5 bar. Expel the nitrogen from the appliance keeping it away from heat sources, ignition points, wells and other possible stagnation points;...

  • Page 73: Draining Water From Outdoor Unit

    Installation, Use and Maintenance - ECOMOD-40/50 7.2. Draining water from outdoor unit If the unit has to be completely drained, first close the manual inlet and outlet valves (not supplied) and then disconnect the pipes provided on the outside of the water inlet and outlet so that the liquid contained in the unit can be evacuated (to make this easier, we suggest installing two drain taps on the outside of the water inlet and outlet between the unit and the manual valves). Unscrew the plug of the service valve and connect a 14 or 12 mm hose (inner diameter - check the type of valve installed on the unit) connected to the water mains, then charge the...
  • Page 74 ECOMOD-40/50 - Installation, Use and Maintenance All of the operations described in this chapter MUST ALWAYS BE CARRIED OUT BY QUALIFIED PERSONNEL. Before carrying out any work on the appliance or accessing internal components, make sure that the electrical power supply has been disconnected. Before starting work, safety checks must be carried out to ensure that there is the least risk of combustion possible.
  • Page 75 Installation, Use and Maintenance - ECOMOD-40/50 OPERATIONS month months months months Fill the water circuit (R) Presence of air bubbles in the water circuit (R) Check the control and safety devices are working correctly (M) Check for oil leaks from the compressor (R) Check for water leaks in the hydraulic circuit (R) Check that flow controller is operating correctly (M) Check if the crankcase resistors are powered and operating (R) Clean the metal filters on the hydraulic circuit (M) Clean the finned battery and the ventilation holes with compressed air (R) Check if the electrical terminals inside the electrical cabinet and on the compressor terminals are attached correctly (M) Tighten the hydraulic connectors (R) Factory tightening torque (M) Check that the fans are attached and balanced (R) Clean the air filters in the electrical cabinet or replace them if necessary (if present) (M) Check the evacuation of condensation (R) Check the electrical voltage and phase unbalance (no load and load) (R)

  • Page 76: Periodic Checks

    ECOMOD-40/50 - Installation, Use and Maintenance 7.5. Periodic checks 7.5.1. CLEANING THE EVAPORATOR Follow the instructions below to clean correctly: a) Remove any surface dirt. Deposits such as leaves, fibres... etc., must be used with a vacuum cleaner (use a brush or a spray, carefully avoiding rubbing with metal parts or abrasives). If compressed air is to be used, ensure that the air stream is kept pointing perpendicularly to the surface of the battery to avoid bending the aluminium fins. Take care not to bend the fins with the nozzle of the compressed air gun. b) Rinse with water. Chemicals may be used (specific products for finned batteries). Rinse it by running water through each of the finned passages until they are completely clean. Ensure that the water stream is kept pointing perpendicularly to the surface of the battery to avoid bending the aluminium fins. Do not touch the evaporator with the end of the water inflow hose. It is recommended to limit the pressure of the jet so as not to damage the fins by putting your finger on the end of the water inflow hose.

  • Page 77: Cleaning The External Surfaces

    Installation, Use and Maintenance - ECOMOD-40/50 7.6. Cleaning the external surfaces The outer panels must be properly cleaned in order to avoid the accumulation of dust/dirt that can lead to the appearance of corrosion. The paint protects against atmospheric agents, but we recommend cleaning these surfaces as frequently as possible with a neutral detergent and water, especially if the unit is installed in an aggressive atmosphere (high pollution level, salt, etc.). 7.7. Maintenance of the outdoor unit All extraordinary maintenance operations must be carried out by persons trained in the handling of R290. 7.8. Heavy maintenance work Some maintenance work may involve the replacement of broken components, which can be heavy.

  • Page 78: Residual Safety Risks

    ECOMOD-40/50 - Installation, Use and Maintenance 7.9. Residual safety risks The residual risks associated with the handling, installation and normal operation of the appliance are listed below. Failure by the user and the installer to comply with the instructions/indications in the manual (the references of which are given in the table) leads to the persistence of these risks, which cannot be eliminated by the manufacturer, which has already taken all necessary design measures to ensure that each risk is minimised. User / Activity Operator User Danger Indications/Instructions Residual risk...
  • Page 79 Installation, Use and Maintenance - ECOMOD-40/50 User / Activity Operator User Danger Indications/Instructions Residual risk Chapter 7 of the Mechanical: projection of User-Installer manual Indicates Simultaneous damage to parts or fluids caused by op- the correct maintenance procedures. both types of protective erating pressure limits being Paragraph 1.2.7 recommends the equipment. exceeded. use of appropriate personal protec- tive equipment.
  • Page 80 ECOMOD-40/50 - Installation, Use and Maintenance User / Activity Operator User Danger Indications/Instructions Residual risk Chapter 7 of the User-Installer Failure by the main- manual tenance technician to Thermal: burns from contact provides the safety measures to be observe the procedures with hot surfaces. taken when maintaining, cleaning or and/or to use checking the unit and the personal PPE.
  • Page 81 Installation, Use and Maintenance - ECOMOD-40/50 User / Activity Operator User Danger Indications/Instructions Residual risk Chapter 7 of the User-Installer manual Generated by materials/ Failure to comply with the provides the safety measures to be substances: burns due to instructions taken when maintaining, cleaning or refrigerant leakage. in the manual. checking the unit and the personal protective equipment to be worn.
  • Page 82 ECOMOD-40/50 - Installation, Use and Maintenance User / Activity Operator User Danger Indications/Instructions Residual risk Paragraph 3.7.3 of the User-Installer Generated by the environ- manual recommends that power ment in which the machine is should be supplied to the unit via a Failure to comply with used: electromagnetic distur- dedicated line and with protective the recommendations bances caused by interfer- devices. It is also advisable to use...

  • Page 83: Maintenance" Check List

    Installation, Use and Maintenance - ECOMOD-40/50 7.10. “Maintenance” check list ■ Before starting any work on equipment containing flammable refrigerant, safety checks must be performed to minimise the risk of ignition. Take the following steps before working on the cooling system: Measure Performed Comment General working environment ■ Inform all of the following persons of the type of work to be carried out: – All of the maintenance personnel. – All persons near to the installation. ■ Prohibit access to the heat pump. ■ Check for flammable materials and ignition sources in the immediate vicinity of the heat pump: remove all flammable materials and ignition sources. Check that the refrigerant is present ■ To detect a flammable atmosphere in good time: check for refrigerant leaks in the environment before, during and after the work using an explosion-proof refrigerant detector suitable...
  • Page 84 Only replace defective components with original parts. ■ Replace the components according to the instructions in the manual. Where necessary, call on the Ideal Heating's technical department. Carry out the following checks: ■ The refrigerant load must not exceed that allowed for the installation room.
  • Page 85 ■ Only components suitable for a flammable atmosphere may be powered up in the vicinity of such an atmosphere. ■ Use only suitable original parts or components approved by the Ideal Heating. Other components may cause the refrigerant to ignite if leaked. Wiring ■ Check if the wiring is subject to wear, corrosion, traction, vibrations, sharp edges or other unfavourable surrounding influences.
  • Page 86 ECOMOD-40/50 - Installation, Use and Maintenance Measure Performed Comment ■ The refrigerant detector must be suitable for the R290 refrigerant to be detected. ■ The refrigerant detector must not contain any potential source of ignition. ■ Calibrate the refrigerant detector to suit the refrigerant used. Set the response threshold to < 3 g/a, suitable for propane. Leak detection using leak detection liquids: ■ Leak detector liquids associated with most refrigerants are suitable. Warning Liquid leak detectors containing chlorine react with the refrigerant, causing corrosion.
  • Page 87 Installation, Use and Maintenance - ECOMOD-40/50 Measure Performed Comment Topping up the refrigerant Filling with refrigerant fluid In addition to the usual filling procedure, the following requirements must be satisfied: - you must make sure that the filling valve is not used for different refrigerant fluids. The pipes should be as short as possible to minimise the amount of refrigerant fluid contained in them. - the refrigerant fluid bottles must remain in a vertical position. - make sure the refrigerant fluid circuit is earthed before filling it. - the appliance may be marked (if not already marked) when the filling process is complete. - take special care not to overfill the appliance. Before the appliance is filled, a pressure test with nitrogen must be carried out. The leak test can be performed on the filled appliance, but it must be done before commissioning. A final leak test must be performed before leaving the facility.
  • Page 88 ECOMOD-40/50 - Installation, Use and Maintenance Measure Performed Comment Marking (on the heat pump) If the heat pump has been taken out of service, affix the following marking, along with the date and signature, prominently on the heat pump: ■ The refrigerant is inflammable. ■ The installation is not in service. ■ The refrigerant has been removed. Recovering the refrigerant fluid and the compressor oil Recovery If the refrigerant fluid has to be recovered for repair or decommissioning, care must be taken to ensure that this is done safely.

  • Page 89: End Of Product Life

    The equipment is manufactured in accordance with the European Directive on Waste Electrical/Electronic Equipment and the adverse effects of improper disposal are indicated in the user/installation manual. The manufacturer or its importer/distributor is available to answer any request for further information. Ideal Heating has signed up to the Eco-systems service which collects, recycles and cleans our used electrical equipment, according to the highest environmental requirements. Eco-systems is an eco-organisation which is approved by the public authorities for the WEEE (Waste Electrical and Electronic Equipment) sector.

  • Page 90: Spare Parts List

    ECOMOD-40/50 - Installation, Use and Maintenance SPARE PARTS LIST 90 / 104 00U07782290-D_EN...
  • Page 91 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW INSULATED COMPRESSOR + RESISTOR 200668 200777 HIGH PRESSURE SENSOR 0-34 BARS 200581 COOLING NON-RETURN VALVE 200669 200778 SENSOR + SUPPORT 200670 OIL NON-RETURN VALVE + SUPPORT 200671 OIL EQUALISATION SUPPORT 200672...
  • Page 92 ECOMOD-40/50 - Installation, Use and Maintenance 92 / 104 00U07782290-D_EN...
  • Page 93 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW RIGHT FRONT PANEL 200680 RIGHT REAR PANEL 200681 FRONT CONDENSER 200682 200779 REAR CONDENSER 200683 200780 LEFT REAR PANEL 200685 LEFT FRONT PANEL 200686 RIGHT FRONT SIDE PANEL 200687 RIGHT REAR SIDE PANEL 200688...
  • Page 94 ECOMOD-40/50 - Installation, Use and Maintenance 94 / 104 00U07782290-D_EN...
  • Page 95 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW V4V COIL + SENSORS AND CABLES 200701 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW INSULATED EXCHANGER + RESISTOR 200702 200781 EXCHANGER THIMBLE 200705 R290 INTERNAL PROPANE SENSOR 200708 INSULATED ANTI-FLOODBACK FLUID BOTTLE 200709...
  • Page 96 ECOMOD-40/50 - Installation, Use and Maintenance 96 / 104 00U07782290-D_EN...
  • Page 97 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW DEGASSER + SEAL 200718 SAFETY VALVE 6B 200719 FLOW RATE CONTROLLER 200720 UPPER EXCHANGER TUBING 200721 PUMP INLET TUBING 200722 PUMP OUTLET TUBING 200723 INSULATED PUMP + RESISTOR 200724 PUMP INSULATION 200725...
  • Page 98 ECOMOD-40/50 - Installation, Use and Maintenance 98 / 104 00U07782290-D_EN...
  • Page 99 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW COMPLETE DOOR ELEC BOX + IDEAL LOGO IDEAL LOGO ORANGE LED ELEC PANEL 200742 RED LED ELEC PANEL 200743 PROTECTIVE COVER FOR SCREEN 200744 EXTERNAL DISCONNECTOR 200745 COMPLETE AIR FILTER 200746 SCREEN + CARD + FITTINGS 200747 ATEX CABLE GLAND M25 (X2) 200748...
  • Page 100 ECOMOD-40/50 - Installation, Use and Maintenance 100 / 104 00U07782290-D_EN...
  • Page 101 Installation, Use and Maintenance - ECOMOD-40/50 REF. FOR MODELS ITEM DESCRIPTION 40 kW 50 kW INVERTER BOARD FOR COMPRESSOR 1 200753 200782 INVERTER BOARD FOR COMPRESSOR 2 200754 200783 TRANSFORMER 200755 CONTROL CARD 200756 200784 RELAY 24V 200757 POWER SUPPLY 200758 INTERNAL DISCONNECTOR 200759...

  • Page 102: Product Reference

    ECOMOD-40/50 - Installation, Use and Maintenance 10. Annex A - Data for products ≤ 70kW Product reference Trademark Ideal Model ECOMOD AHP-70-40 ECOMOD AHP-70-50 Heat pump Air-Water Nominal power (average / cool / hot climatic conditions) 39 / 44 / 39 43 / 51 / 47 Rated heat output (35°C) Element Symbol Unit...
  • Page 103 Installation, Use and Maintenance - ECOMOD-40/50 Product reference Trademark Ideal ECOMOD AHP-70-40 ECOMOD AHP-70-50 Model Heat pump Air-Water Nominal power (average / cool / hot climatic conditions) 38 / 43 / 37 44 / 52 / 46 Rated heat output (55°C) Element Symbol Unit Rated heat output nominal Declared heating capacity at partial load for an indoor temperature of 20°C and an outdoor temperature Tj Tj = - 7°C 33,7...
  • Page 104 At Ideal Heating we take our environmental impact seriously, therefore when installing any Ideal Heating product please make sure to dispose of any previous appliance in an environmentally conscious manner. Households can contact their local authority to find out how.
