- Page 1 HYBRID INSTRUCTIONS HP290 MONOBLOC HEAT PUMP SYSTEM SCAN SCAN SCAN SCAN for Installation for Hybrid for Halo Lite for Hybrid & Maintenance RF Installation Instructions Schematics Guide Manual Manual Guide When replacing any part on this appliance, use only spare parts that you can be assured conform to the safety and performance specification that we require.
-
Page 2: Notes For The Installer
• Dispose of the batteries according to the local statutory commissioning& servicing of central requirements and not with the usual domestic refuse. heating systems NOTE TO INSTALLER: LEAVE THESE INSTRUCTIONS WITH APPLIANCE Ideal Heating reserve the right to vary specification without notice... -
Page 3: Table Of Contents
Section 2 - Product Information ....................5 2.1 Introduction ..........................5 2.2 Glossary of Terms ........................5 2.3 Kit Contents ..........................5 Section 3 - Installation ........................6 3.1 Installing the HP290 Hybrid Kit .....................6 Section 4 - Commissioning ......................9 4.1 HP290 Interface Layout ......................9 4.1.1 Hybrid Mode Settings .....................10 4.1.2 Configuring Hybrid Mode .................. -
Page 4: Section 1 - General
Section 1 - General 1.1 GENERAL SAFETY INSTRUCTIONS components. Failure to comply with this requirement can result in severe injury or death. Prior to installation and maintenance of the product, make If any of the supply cables are damaged, they must be sure that: replaced by the manufacturer, its service agent or similarly qualified persons in order to avoid a hazard. -
Page 5: Section 2 - Product Information
Section 2 - Product Information 2.1 INTRODUCTION This kit is required for all hybrid installations consisting of the HP290 monobloc heat pump. The HP290 monobloc heat pump is compatible with heat only, system and combination boilers in hybrid installations. All settings relating to hybrid installations should be set up and altered by a competent person. For full installation instructions, refer to the HP290 Installation &... -
Page 6: Section 3 - Installation
3. Remove the HP290 Monobloc top and side panels. Refer to the HP290 Installation & Maintenance manual 4.1.7 Accessing the Casing. 4. On the Outdoor PCB (Figure 2), set dip-switch S2 (switch 1) to ON. (Refer to the HP290 Installation & Maintenance manual Section 5.5). - Page 7 Thermistor to the outdoor unit, use the T1 thermistor (10 m) and connect to CN39. Connector CN39 Dip-switch S2 (switch 1) ⓘ IMPORTANT: Refer to the HP290 Installation & Maintenance manual Section 5.5. (Only applicable if you have the HP290 control box) Figure 2. HP290 Outdoor PCB Installation and Maintenance...
- Page 8 L Out Ground Room Stat Overheat 3 Way CH1 Pump CH2 Pump Backup Boiler Power Stat Valve or Valve or Valve Gland Gland Gland Gland Gland Figure 3. HP290 Control Box - Internal Wiring Installation and Maintenance...
-
Page 9: Section 4 - Commissioning
Section 4 - Commissioning 4.1 HP290 INTERFACE LAYOUT Screen Locked Silent Mode Active Wi-Fi Connected Smart Grid Active Outside Temperature Zone 2 Target Temperature (lights when Zone 2 On, grey when Zone 2 Off) Shown if controllled by Room Temperature... -
Page 10: Hybrid Mode Settings
Section 4 - Commissioning 4.1.1 Hybrid Mode Settings The settings in Table 1 must be inputted into the controller depending on the type of system. See sections 4.1.2 to 4.1.5 for setting instructions. Table 1 Hybrid Mode Controller Settings Hybrid System Type Controller Settings Boiler Function Heat Pump Function... -
Page 11: Configuring Hybrid Mode
Section 4 - Commissioning 4.1.2 Configuring Hybrid Mode From the Indoor Control Box Homepage display (Figure 4), set the Additional Heat Source (AHS) function as follows: Other heat source AHS function Heating and DHW AHS_Pump_I Control dT1_AHS_ON 5⁰C Zone1 t_AHS_Delay 30minutes Heating and DHW Heating In AHS function select either accordance with Table 1. -
Page 12: Setting The Heating Bivalent Point (T4Hmin)
Section 4 - Commissioning 4.1.3 Setting the Heating Bivalent Point 4.1.4 Setting the boiler heating mode activation (T4HMIN) temperature (T4_AHS_ON) Note: T4HMIN is the outdoor temperature below which the Note: T4_AHS_ON is the outdoor temperature below which the heat pump will not operate in heating mode. additional heating source is on. -
Page 13: Setting Domestic Hot Water Bivalent Point (T4Dhwmin)
Section 4 - Commissioning 4.1.5 Setting domestic hot water bivalent point 4.1.6 Setting DHW function to OFF (T4DHWMIN) Press together for 3S. Then the next screen will be shown. Note: T4DHWMIN is the outdoor temperature below which the heat pump will not operate in domestic hot water mode. T4DHWMIN From the service menu set the as follows:... -
Page 14: Turning Off Tbh Function
Section 4 - Commissioning 4.1.7 Turning off TBH function From the For Servicman menu, set the TBH function as follows: Other heat source Select For serviceman Room thermostat setting Other heat source Service call Restore factory settings TBH function to NO. For serviceman TBH function dT5_TBH_OFF... -
Page 15: Section 5 - Inspection And Maintenance
Section 5 - Inspection and Maintenance 5.1 SYSTEM SCHEMATICS For the HP290 Hybrid System Schematics refer to the HP290 Heat Pump Guides. SCAN for Hybrid Schematics Guide Installation and Maintenance... - Page 16 At Ideal Heating we take our environmental impact seriously, therefore when installing any Ideal Heating product please make sure to dispose of any previous appliance in an environmentally conscious manner. Households can contact their local authority to find out how.
