KA01332D/06/EN/02.24-00
71689987
2024-12-20
Products
Brief Operating Instructions
Proline 100
EtherNet/IP
Transmitter with
Coriolis sensor
These instructions are Brief Operating Instructions; they are
not a substitute for the Operating Instructions pertaining to
the device.
Transmitter Brief Operating Instructions
Contain information about the transmitter.
Sensor Brief Operating Instructions → 3
Solutions
Services
Advertisement
Related Manuals for Endress+Hauser Proline 100 EtherNet/IP
Summary of Contents for Endress+Hauser Proline 100 EtherNet/IP
- Page 1 Products Solutions Services KA01332D/06/EN/02.24-00 71689987 2024-12-20 Brief Operating Instructions Proline 100 EtherNet/IP Transmitter with Coriolis sensor These instructions are Brief Operating Instructions; they are not a substitute for the Operating Instructions pertaining to the device. Transmitter Brief Operating Instructions Contain information about the transmitter. Sensor Brief Operating Instructions →...
- Page 2 Proline 100 EtherNet/IP Order code: XXXXX-XXXXXX Ser. no.: XXXXXXXXXXXX Ext. ord. cd.: XXX.XXXX.XX Serial number www.endress.com/deviceviewer Endress+Hauser Operations App A0023555 Endress+Hauser...
- Page 3 These Brief Operating Instructions are the Transmitter Brief Operating Instructions. The "Sensor Brief Operating Instructions" are available via: • Internet: www.endress.com/deviceviewer • Smart phone/tablet: Endress+Hauser Operations App Detailed information about the device can be found in the Operating Instructions and the other documentation: • Internet: www.endress.com/deviceviewer...
-
Page 4: Table Of Contents
Table of contents Proline 100 EtherNet/IP Table of contents Document information ............5 Symbols used . -
Page 5: Document Information
Proline 100 EtherNet/IP Document information Document information Symbols used 1.1.1 Safety symbols Symbol Meaning DANGER! DANGER This symbol alerts you to a dangerous situation. Failure to avoid this situation will result in serious or fatal injury. WARNING! This symbol alerts you to a dangerous situation. Failure to avoid this situation can result in WARNING serious or fatal injury. -
Page 6: Tool Symbols
Document information Proline 100 EtherNet/IP Symbol Meaning Protective Earth (PE) A terminal which must be connected to ground prior to establishing any other connections. The ground terminals are situated inside and outside the device: • Inner ground terminal: Connects the protectiv earth to the mains supply. -
Page 7: Basic Safety Instructions
Proline 100 EtherNet/IP Basic safety instructions Basic safety instructions Requirements for the personnel The personnel must fulfill the following requirements for its tasks: ‣ Trained, qualified specialists must have a relevant qualification for this specific function and task. ‣ Are authorized by the plant owner/operator. -
Page 8: Workplace Safety
Verification for borderline cases: ‣ For special fluids and fluids for cleaning, Endress+Hauser is glad to provide assistance in verifying the corrosion resistance of fluid-wetted materials, but does not accept any warranty or liability as minute changes in the temperature, concentration or level of contamination in the process can alter the corrosion resistance properties. -
Page 9: It Security
Proline 100 EtherNet/IP Product description IT security We only provide a warranty if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the device settings. - Page 10 Installation Proline 100 EtherNet/IP Aluminum housing version 3 mm A0023192 Compact and ultra-compact housing versions 8 mm A0023195 Endress+Hauser...
-
Page 11: Electrical Connection
Proline 100 EtherNet/IP Electrical connection Electrical connection WARNING Live parts! Incorrect work performed on the electrical connections can result in an electric shock. ‣ Set up a disconnecting device (switch or power-circuit breaker) to easily disconnect the device from the supply voltage. -
Page 12: Terminal Assignment
Electrical connection Proline 100 EtherNet/IP Cable diameter • Cable glands supplied: M20 × 1.5 with cable ⌀ 6 to 12 mm (0.24 to 0.47 in) • Spring terminals: Wire cross-sections 0.5 to 2.5 mm (20 to 14 AWG) 5.2.3 Terminal assignment The terminal assignment for the electrical connection of the device can be found on the connection nameplate of the electronics module. - Page 13 Proline 100 EtherNet/IP Electrical connection Safety Barrier Promass 100 Power Modbus supply RS485 Safe area Power Lift panel for bus termination Communication Safety Barrier Promass 100 Hazardous area Power Modbus supply RS485 A0016922 2 Safety Barrier Promass 100 with terminals Non-hazardous area and Zone 2/Div.
-
Page 14: Connecting The Device
Electrical connection Proline 100 EtherNet/IP Device plug for signal transmission (device side) Assignment Coding Plug/socket Socket A0016812 5.2.5 Preparing the measuring device NOTICE Insufficient sealing of the housing! Operational reliability of the measuring device could be compromised. ‣ Use suitable cable glands corresponding to the degree of protection. - Page 15 Proline 100 EtherNet/IP Electrical connection A0016924 3 Housing versions and connection versions Housing version: compact, coated, aluminum Housing version: compact, hygienic, stainless Housing version: ultra-compact, hygienic, stainless Cable entry or device plug for signal transmission Cable entry or device plug for supply voltage...
- Page 16 Electrical connection Proline 100 EtherNet/IP 8 mm 8 mm 3 mm 10 (0.4) mm (in) A0017844 5 Device versions with connection examples Cable Device plug for signal transmission Device plug for supply voltage Depending on the housing version, disconnect the local display from the main electronics module: Operating Instructions for the device .
-
Page 17: Special Connection Instructions
Proline 100 EtherNet/IP Electrical connection Special connection instructions 5.4.1 Connection examples EtherNet/IP A0028767 6 Connection example for EtherNet/IP Control system (e.g. PLC) Ethernet switch Observe cable specifications Device plug Transmitter Hardware settings 5.5.1 Setting the device address EtherNet/IP The IP address of the measuring device can be configured for the network via DIP switches. -
Page 18: Ensuring The Degree Of Protection
Electrical connection Proline 100 EtherNet/IP Addressing mode ex works Software addressing; all DIP switches for hardware addressing are set to OFF. IP address ex works DHCP server active For device addressing via software Setting the address OFF ON - Write protection... -
Page 19: Post-Connection Check
Proline 100 EtherNet/IP Electrical connection To ensure that moisture does not enter the cable entry: Route the cable so that it loops down before the cable entry ("water trap"). A0029278 Insert dummy plugs into unused cable entries. Post-connection check Are cables or the device undamaged (visual inspection)? ... -
Page 20: Operation Options
Operation options Proline 100 EtherNet/IP Operation options Overview of operating options A0017760 Computer with Web browser (e.g. Internet Explorer) or with "FieldCare" operating tool Automation system, e.g. "RSLogix" (Rockwell Automation) and work station for measuring device operation with Add-on Profile Level 3 for "RSLogix 5000" software (Rockwell Automation) -
Page 21: Structure And Function Of The Operating Menu
Proline 100 EtherNet/IP Operation options Structure and function of the operating menu 6.2.1 Structure of the operating menu Operating menu for operators and maintenances Language Operation task-oriented Setup Diagnostics Operating menu for experts Expert function-oriented A0014058-EN 7 Schematic structure of the operating menu 6.2.2... -
Page 22: Computer Hardware
Operation options Proline 100 EtherNet/IP 6.3.2 Prerequisites Computer hardware Interface The computer must have an RJ45 interface. Connection Standard Ethernet cable with RJ45 connector. Screen Recommended size: ≥12" (depends on the screen resolution) Computer software Recommended operating systems Microsoft Windows 7 or higher. - Page 23 Proline 100 EtherNet/IP Operation options Device CDI-RJ45 service interface IP address If the IP address of the device is not known, communication with the Web server can be established via the default IP address 192.168.1.212. The DHCP function is enabled in the device at the factory, i.e. the device expects an IP address to be assigned by the network.
- Page 24 Operation options Proline 100 EtherNet/IP The measuring device works with the Dynamic Host Configuration Protocol (DHCP), on leaving the factory, i.e. the IP address of the measuring device is automatically assigned by the automation system (DHCP server). To establish a network connection via the service interface (CDI-RJ45): the "Default IP address"...
-
Page 25: User Interface
Proline 100 EtherNet/IP Operation options 6.3.5 User interface A0032879 Picture of device Device name Device tag Status signal Current measured values Navigation area Local display language Header The following information appears in the header: • Device tag • Device status with status signal •... -
Page 26: Navigation Area
Operation options Proline 100 EtherNet/IP Functions Meaning Data exchange between PC and measuring device: • Device configuration: • Load settings from the device (XML format, save configuration) • Save settings to the device (XML format, restore configuration) • Logbook - Export Event logbook (.csv file) Data •... -
Page 27: Access To The Operating Menu Via The Operating Tool
Proline 100 EtherNet/IP System integration Function scope of the "Web server functionality" parameter Option Description • The web server is completely disabled. • Port 80 is locked. • The complete functionality of the web server is available. • JavaScript is used. -
Page 28: Commissioning
Commissioning Proline 100 EtherNet/IP Commissioning Function check Before commissioning the measuring device: ‣ Make sure that the post-installation and post-connection checks have been performed. • "Post-installation check" checklist • "Post-connection check" checklist → 19 Setting the operating language Factory setting: English or ordered local language The operating language can be set in FieldCare, DeviceCare or via the Web server: Operation →... -
Page 29: Diagnostic Information
Proline 100 EtherNet/IP Diagnostic information Diagnostic information Any faults detected by the measuring device are displayed as a diagnostic message in the operating tool once the connection has been established and on the home page of the web browser once the user has logged on. - Page 32 *71689987* 71689987 www.addresses.endress.com...
