TXZ+ Family

TMPM4K Group (1)

Clock Control and Operating Mode
32-bit RISC Microcontroller
TXZ+ Family
TMPM4K Group (1)
Reference Manual
Clock Control and Operating Mode
(CG-M4K(1)-E)
Revision 1.0
2024-07
© 2023-2024
1 / 63
2024-07-22
Toshiba Electronic Devices & Storage Corporation
Rev. 1.0
