PRODUCT DESCRIPTION Console Console Cover Safety Right Upright Left Upright Motor Upper Cover Folding Lever Running Belt Side Cover Side Rail Cushion End Cap Main Frame Rear Stabilizer Foot...
Page 3
ASSEMBLY INSTRUCTIONS ATTENTION: Do the following operations after checking all screws are tightened and everything is OK. Before you use the treadmill, please read the instructions carefully. STEP 1:Open the carton, and move out all the parts listed in below chart. Treadmill Frame: 1 SET B8 Rear Stabilizer C13 Safety Key: 1 PC...
Page 4
STEP 3 Turn both Folding Levers (B157) on Left/ Right Uprights (A3L/ A3R) counter- : clockwise. Hold and lift Left/ Right Uprights (A3L/ A3R), and rotate both Folding Levers (B157) clockwise to lock both Uprights. B157 B157 STEP 4: Hold left and right Handlebar (A4) and push it down until hearing a “clock” sound for lock it into position.
Page 5
STEP 5: Place on Power Cable (C15), and Safety Key (C13). STEP 6: After installation, press start button, adjust speed level under 3km/h. Then check the running belt to see if it runs smoothly or not. The tightness level is decided based on the situation of slippery and deviation.
FOLDING INSTRUCTION STEP 1: Rotate Console (B1) backward to be horizontal with Handlebar (A4). STEP 2: Slightly push down the Handlebar (A4) and press Folding Button (B156) on left/ right sides at the same time. Once the Handlebar (A4) is un-locked, rotate it back to attach Left/ Right Uprights (A3L/ A3R).
Page 7
STEP 3: Rotate Folding Lever (B157) counter-clockwise for 1 turn in order to loosen Left/ Right Uprights (A3L/ A3R) and push them down to attach the Treadmill Frame. Loosen Tighten B157 STEP 4: Rotate Folding Lever (B157) clockwise for 1 turn in order to tighten the Left/ Right Uprights (A3L/ A3R).
Page 8
STEP 5: To move the treadmill forward and backward, lift the end of treadmill frame and have transport wheels touch on the ground/ floor. To move the treadmill to the left and right, have the treadmill stand with motor cover end closer to the ground / floor. STEP 6 (for storage): Place treadmill at standing position against wall for storage, or place it under the bed for space saving.
GROUNDING METHODS This product must be grounded. If it should malfunction or breakdown, grounding provides a path of least resistance for electric current to reduce the risk of electric shock. This product is equipped with a cord having an equipment-grounding conductor and a grounding plug. The plug must be plugged into an appropriate outlet that is properly installed and grounded in accordance with all local codes and ordinances.
MAINTENANCE INSTRUCTION WARNING:Please make sure pull out the treadmill's power plug before cleaning or maintaining the product. CLEANSING:General cleaning or the unit will greatly prolong the treadmill's life. Keep treadmill clean by dusting regularly. Be sure to clean the exposed part of the deck on either side of the walking belt and also the side rails.
BELT ADJUSTMENT Place treadmill on a level surface. Make treadmill run at approximately 6-8 km/h, observe the running belt deviate condition. If the belt has drifted to the right, unplug the safety lock and power switch, and turn the right adjusting bolt 1/4 turn clockwise, then insert the power switch and safety lock, make the treadmill running, observe the running belt deviate condition.
PARTS LIST A. Welding Parts DESCRIPTION Main Frame Left Upright Right Upright Handlebar Incline Bracket Belt Fixation Bracket Safety Key Pin Stopper Pin PU Roller Spacer Upright Folding Bracket Folding Lever Sleeve Resistance Plate Safety Key Pin Holder (delete this part) Inductor &...
Page 14
Motor Upper Cover Motor Bottom Cover Side Rail B16L Left End Cap B16R Right End Cap Silicon Lubrication Cable Clip Wire Protection Plug Squared-shaped Tube Plug Squared-shaped Cushion Oval-Shaped Cushion Console Large Back Cover Water Bottle Holder Ring Safety Key Holder Water Bottle Holder B101 Transportation Wheel Cover...
Page 15
Drive Belt Power Switch Controller Pulse Sensor on Left Handlebar Pulse Sensor on Right Handlebar Incline Motor Safety Key Single Cable (Brown) Power Cord Upper Section Cable Lower Section Cable Magnetic Ring Inductor Filter Single Cable (Blue) Ground Wire Power Plug Brushless Motor Large Magnetic Ring Rectangle Shaped Magnet (delete this part)
Page 16
Flat Washer, M10 Flat Washer, M6 Flat Washer, M8 Spring Washer, M5 Bowl Washer Socket Head Cap Screw, M6x45mm Socket Head Cap Screw, M6x60mm Phillips Rounded Washer Head Screw, M4x10mm Phillips Rounded Washer Head Screw, M5x12mm Phillips Rounded Washer Head Screw, M5x15mm Phillips Pan Head Self-Tapping Screw, ST4.2x16mm Phillips Flat Head Self-Drilling Screw, ST3.5x16mm Socket Head Cap Screw, M6x25mm...
Page 17
D200 Button Head Cap Screw, M10x40mm D204 D Shaped Screw Lock, M8x40mm D206 Socket Head Cap Screw, M10x75mm D207 Socket Head Cap Screw, M6x35mm (Reverse Thread) D208 Flat Washer, M6 D214 Phillips Flat Head Self-Tapping Screw, ST4.0x6mm...
Page 18
Operation Guide 1. DISPLAY DEFINITION (1) SPEED Show current running speed of the exercise. (2) CALORIE Show total consumed calories during the exercise. (3) INCL. (INCLINE) Show the incline level set for the exercise. Incline unit = 0 – 12 levels (4) PROG.
Page 19
Show duration of the exercise. (6) Distance Show accumulated distance of the exercise. (7) Pulse Once heart rate signal detected, display shows pulse data. Please noted pulse data is only for reference, not for medical purpose. (8) ODO Show total accumulated distance of this treadmill by pressing PROG and MODE buttons together for at least 3 seconds.
Page 20
to appropriate setting. (5) QUICK SPEED Quick speed has 5 buttons for 2 km/h, 4 km/h, 6 km/h, 8 km/h, and 10 km/h (when it’s in imperial setting). (6) QUICK INCLINE Quick incline has 5 buttons for level 2, level 4, level 6, level 8, and level 10. (7) SPEED CONTROL BUTTONS Press “Increase”...
Page 21
flashes. (4) To start pre-set programs, press “Program” buttons to choose any of the 15 programs, and the corresponding program number will be displayed on “PROG.” display window. To adjust the default time setting, press “Speed Control Buttons” or “Incline Control Buttons” to set the total time duration.
Speed Incline Speed Incline Speed Incline Speed Incline 4. PULSE To detect a pulse, both hands hold the heart rate sensor pads on left/ right handlebars for over 5 seconds. Pulse window displays the spotted pulse value. To have more accurate pulse data on the display, it’s recommend to hold heart rate sensor pads for 30 seconds or above.
Under “Standby Mode”, press “Program” button and choose “FAT” program. Press “MODE” button to enter basic data, including Gender / Age / Height / Weight. The corresponding codes displayed on console for these 4 categories are M or F / WEIGHT / HEIGHT / AGE.
When one segment is completed, console automatically runs the setting speed and incline based on the next segment. User can adjust the speed and incline to fit one’s personal condition after training starts. When User Program is completed, there’s beep sound alarms and window display flashes. Default speed under U01 is 1 km/h.
Page 25
11. BLUETOOTH APP & BLUTOOTH HEART RATE This treadmill provides Bluetooth app connectivity, including KINOMAP and ZWIFT. This treadmill provides Bluetooth heart rate connectivity. Wear a chest belt, which is equipped with Bluetooth function, and start to exercise on the treadmill, and then treadmill would pair with your chest belt automatically and display defected heart rate data on the console window.
Page 26
GARLANDO SPA Via Regione Piemonte, 32 - Zona Industriale D1 15068 - Pozzolo Formigaro (AL) - Italy www.everfit.it - info@everfit.it...
