Summary of Contents for Mocka Hamptons Change Table
- Page 1 Hello, , I’ve arrived! Now that I’m here you are only one flat-pack away from transforming your home.
- Page 2 Thank you for supporting us. We believe design belongs to everyone. From materials and processes to safety testing, production and delivery, we are passionate and committed to bringing you the best possible product so you can create beautifully functional spaces to feel comfortably you. Here are a few assembly tips before you get started: Make Time Set The Mood...
- Page 3 Hamptons Change Table Thank you for your purchase. Please follow the instructions below for correct assembly. 48 x 48 x 40 x 32 x bolt locking dowel long small screw screw safety long strap screw 18 x medium screw handle...
- Page 4 Hamptons Change Table Attach 2 x bolts (A) to panel [1]. Insert 4 x locking nuts (B) into panel [1]. Insert 4 x Insert 4 x bolts (A) into panel [2] and [3]. Tighten with a screwdriver. dowels (C) into panels [2] and [3] to panel [1]. Making sure panel [2] is being attached close to the arrow or on the arrows side.
- Page 5 Hamptons Change Table Attach 3 x left slide rails (CL) to panel [5] and secure with 6 x small screws (E). Insert 2 x locking nuts (B) into panel [4]. Attach panel [4] to panel [1], using 2 x Attach 3 x right slide rails (CR) to panel [6] and secure with 6 x small screws (E).
- Page 6 Hamptons Change Table Attach 1 x left slide rail (CL) to panel [4] and secure with 2 x small screws (E). Attach 1 x right slide rail (CR) to panel [4] and secure with 2 x small screws (E). Insert 2 x dowels (C) into panels [4] and [24] and secure with 2 x long screws (D).
- Page 7 Hamptons Change Table Insert 9 x dowels (C) into panels [1], [7], [8] and [24]. Attach panel [6] to panels [1], [7], Insert 9 x dowels (C) into panels [1], [7], [8]and [24]. Attach panel [5] to panels [8] and [24] and secure with 5 x locking nuts (B). Tighten with a screwdriver.
- Page 8 Hamptons Change Table Insert 4 x dowels (C) into panels [5] and [6]. Attach panel [9] to panels [5] and Attach 14 x bolts (A) into panels [9] and [21]. Attach 4 x dowels (C) to panels [21] [6] and secure with 4 x long screws (D). Tighten with a screwdriver.
- Page 9 Hamptons Change Table Large Drawers x 2 Insert 6 x dowels (C) into panel [9]. Attach panel [21] and [22] to panels [9], Attach panels [12], [13] and [15] to panels [18], secure with 10 x medium screws (F). secure with 10 x locking nuts (B). Tighten with a screwdriver.
- Page 10 Hamptons Change Table Large Drawers x 2 Small Drawers x 2 Attach panels [12] and [13] to panels [17], secure with 8 x medium screws (F). Slide panels [14] between the grooves on panels [12], [13] and [18] to form the base of the drawer as shown.
- Page 11 Hamptons Change Table Small Drawers x 2 Drawers x 2 Slide panels [16] between the grooves on panels [12], [13] and [17] to form the Attach 18 x bolts (A) into panels [10] snd [11]. Tighten with a screwdriver. base of the drawer as shown.
- Page 12 Hamptons Change Table Large Drawers x 2 Large Drawers x 2 Attach 4 x slide rails (DL) and (DR) to panels [12] and [13], secure with 8 x small Attach panels [11] to panels [12] and [13], secure with 10 x locking nuts (B).
- Page 13 Hamptons Change Table Small Drawers x 2 Small Drawers x 2 Attach 4 x slide rails (DL) and (DR) to panels [12] and [13], secure with 8 x small Attach panels [10] to panels [12] and [13], secure with 8 x locking nuts (B).
- Page 14 Hamptons Change Table Strap Washer Wall anchor Wall screw Wall screw Once assembled lift furniture into place, do not drag. Use a drill to create a On the back side of Change Table, fit backing board [20] into grooves and slide panels [19] in between. Use small 20 x screws (J) all around to small hole lining up with the top of the safety stap (W).
- Page 15 Love it for longer. Remove all liquid and food spills immediately ONLY with a clean, damp, undyed white cloth. Do NOT use abrasives or common household detergents. Caring for our world. In the interest of our environment, please dispose of all packaging thoughtfully. Good news, you’re all done! Love it and share it on Instagram by tagging @mockaaustralia | @mockanz...
