V-TAC 23741 Instruction Manual

Dimmable microwave sensor
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

TECHNICAL DATA
SKU
FREQUENCY
MICROWAVE POWER
INSTALLATION HEIGHT
DETECTION DISTANCE
INPUT RANGE
INPUT VOLTAGE RANGE
INPUT CURRENT
OUTPUT SIGNAL
OUTPUT CONNECTION
SENSOR DATA
DETECTION AREA
HOLD TIME
DAYLIGHT DIMMING LEVEL 10%/20%/30%/50%
DAYLIGHT THRESHOLD
STANDBY DIMMING LEVEL
STANDBY PERIOD
MULTI-LANGUAGE
MANUAL QR CODE
Please scan the QR code
to access the manual in
multiple languages.
In case of any query/issue with the product, please reach out to us at: support@v-tac.eu
For More products range, inquiry please contact our distributor or nearest dealers.
V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B
INSTRUCTION MANUAL
DIMMABLE MICROWAVE SENSOR
23741
5.8Ghz ±75Mhz
<0.3mW
15m/49.2ft Max
≥3m/9ft
12VDC
10-15VDC
≥30mA
DIM 0-10V
12VDC Input/ Black
& White wire; DIM+/
Purple wire; DIM-/ Pink
Wire
25%/50%/75%/100%
5s/30s/1min/3min/5min/10min/2
0min/30min
Disable/ 2lux/ 10lux/ 30lux/
50lux/ 80lux/ 120lux
10%/20%/30%/50%
0s/10s/30s/1min/5min/10min/30
min/60min
COMPATIBLE HIGHBAY
23736, 23737, 23738, 23739
(PURCHASE SEPARATELY)
STAND BY POWER
DUST/DAWN
SENSING/
PHOTOCELL
DEFAULT PROGRAM
REMOTE CONTROL
WORKING
TEMPERATURE
STORAGE TEMPERATURE
<30mA Power Con-
sumption
Daylight Threshold as 30lux/50lux
/80lux/120lux
Standby Period as +∞;
Standby dimming level as
10%/20%30%
Detection Area- 100%
Holding Time - 5s
Daylight Threshold - Disable
Standby Period -0s
Standby Dimming Level - 10%
SKU-23743, With LCD Screen
display remote
(Purchase seperately)
-20°C to +60°C
-40°C ~+80°C Humidity: 85%
(non-condensation)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 23741 and is the answer not in the manual?

Questions and answers

Related Manuals for V-TAC 23741

Summary of Contents for V-TAC 23741

  • Page 1 In case of any query/issue with the product, please reach out to us at: support@v-tac.eu For More products range, inquiry please contact our distributor or nearest dealers. V-TAC EUROPE LTD. Bulgaria, Plovdiv 4000, bul.L.Karavelow 9B...

  • Page 2: Introduction & Warranty

    INTRODUCTION & WARRANTY Thank you for selecting and buying V-TAC product. V-TAC will serve you the best. Please read these instructions carefully before starting the installation and keep this manual handy for future reference. If you have any another query, please contact our dealer or local vendor from whom you have purchased the product. They are trained and ready to serve you at the best.
  • Page 3 TYPE-A-3 3 pogo-pin connection Wire color: Yellow PinkPurple The length of the wire: 200mm TYPE-A-3-1 3 pogo-pin connection Wire color: Yellow PinkPurple The length of the wire: 300mm TYPE-B Wire color: Black/white, PinkPurple The length of the wire: 330mm TYPE-C Wire color: Black/white, PinkPurple The length of the wire: 300mm TYPE-D...

  • Page 4: Detection Coverage

    DETECTION COVERAGE Ceiling Mounted Ceiling Mounted Well Detected Area Mounting Mounting Height Height Possibly Detected Area Highest mounting height is 15m This figure indicates the maximum distance at the highest mounting height with 100% sensitivity. DUSK/DAWN FUNCTION This sensor is able to differentiate arti- Precondition of Dusk/Dawn function: ficial light brightness from natural light 1.

  • Page 5: Application Notes

    2. WITHOUT DAYLIGHT DISABLED Sensor turns ON Sensor keeps for Sensor dims light to Sensor turns OFF light when motion is a hold time period standby dimming light after standby detected. after motion leaves level after hold time period if there is still no motion 3.
