- Page 1 Ihr Ansprechpartner / dataTec AG Your Partner: E-Mail: info@datatec.eu >>> www.datatec.eu PREMIUM PARTNER User’s manual FLIR ETS3xx series...
- Page 2 Important note Before operating the device, you must read, understand, and follow all instructions, warnings, cautions, and legal disclaimers. Důležitá poznámka Před použitím zařízení si přečtěte veškeré pokyny, upozornění, varování a vyvázání se ze záruky, ujistěte se, že jim rozumíte, a řiďte se jimi.
-
Page 3: Table Of Contents
Screen elements ..............11 Handling the camera unit..............12 Charging the battery ..............12 8.1.1 Charging the battery using the FLIR power supply ....12 8.1.2 Charging the battery using a USB cable connected to a computer..............12 Turning on and turning off the camera.......... 12 Adjusting the position of the camera unit ........ - Page 4 15.1 Introduction ................38 15.2 Definition—what is calibration? ..........38 15.3 Camera calibration at FLIR Systems ........... 38 15.4 The differences between a calibration performed by a user and that performed directly at FLIR Systems........39 15.5 Calibration, verification and adjustment........39 15.6...
-
Page 5: Disclaimers
◦ No Liability for Certain Damages. EXCEPT AS PROHIBITED BY © 2022 FLIR Systems, Inc. All rights reserved worldwide. No parts of the LAW, MS SHALL HAVE NO LIABILITY FOR ANY INDIRECT, software including source code may be reproduced, transmitted, transcribed... -
Page 6: Safety Information
WARNING Applicability: Digital devices subject to 15.21. NOTICE: Changes or modifications made to this equipment not expressly approved by FLIR Systems may void the FCC authorization to operate this equipment. WARNING Applicability: Digital devices subject to 2.1091/2.1093/KDB 447498/RSS-102. - Page 7 High temperatures can cause damage to the camera. CAUTION Do not attach the camera unit directly to a car’s cigarette lighter socket, unless FLIR Systems supplies a specific adapter to connect the camera unit to a cigarette lighter socket. Damage to the camera unit can occur.
-
Page 8: Notice To User
3.6 Important note about this manual FLIR Systems issues generic manuals that cover several cameras within a model line. This means that this manual may contain descriptions and explanations that do not apply to your particular camera model. -
Page 9: Note About Authoritative Versions
Notice to user 3.7 Note about authoritative versions The authoritative version of this publication is English. In the event of divergences due to translation errors, the English text has precedence. Any late changes are first imple- mented in English. #T810252; r. AE/85858/85858; en-US... -
Page 10: Customer Help
• The communication protocol, or method, between the camera and your device (e.g., SD card reader, HDMI, Ethernet, USB, or FireWire). • Device type (PC/Mac/iPhone/iPad/Android device, etc.). • Version of any programs from FLIR Systems. • Full name, publication number, and revision number of the manual. 4.3 Downloads... -
Page 11: Introduction
Introduction 5.1 General description The FLIR ETS3xx is FLIR’s first electronic test bench camera, designed for a quick tem- perature check of PCB boards and electronic devices. The FLIR ETS3xx is sensitive enough to detect subtle temperature difference with an accuracy of ±3°C (±5.4°F), so you can quickly find hot spots and potential points of failure. -
Page 12: Quick Start Guide
• Charge the battery using a USB cable connected to a computer. Note Charging the camera using a USB cable connected to a computer takes considerably longer than using the FLIR power supply or the FLIR stand-alone battery charger. 2. Connect a ground cord to the ground stud on the ESD mat of the camera stand. -
Page 13: Description
Description 7.1 View from the front 1. LCD display. 2. Infrared camera lens. 3. Archive button. • Push to open the image archive. 4. Back/Cancel button. • Push to go back into the menu system. • Push to cancel a choice. 5. -
Page 14: View From The Rear
Note Charging the camera using a USB cable connected to a computer takes con- siderably longer than using the FLIR power supply. • Moving images from the camera to a computer for further analysis in FLIR Thermal Studio. Note Install FLIR Thermal Studio on your computer before you move the images. -
Page 15: Screen Elements
Description 7.4 Screen elements 1. Main menu toolbar. 2. Submenu toolbar. 3. Spotmeter. 4. Result table. 5. Status icons. 6. Temperature scale. #T810252; r. AE/85858/85858; en-US... -
Page 16: Handling The Camera Unit
WARNING Make sure that you install the socket-outlet near the equipment and that it is easy to get access to. 8.1.1 Charging the battery using the FLIR power supply Follow this procedure: 1. Connect the power supply to a mains socket. -
Page 17: Adjusting The Position Of The Camera Unit
Handling the camera unit 8.3 Adjusting the position of the camera unit Note Do not touch the lens surface. If this happens, clean the lens according to the in- structions in 13.2 Infrared lens, page 32. 1. Fine-adjustment knob. 2. Stand mount knob. 3. - Page 18 Handling the camera unit Follow this procedure: 1. Turn and remove the top of the stand. 2. Loosen the stand mount knob and remove the camera unit from the stand. 3. Turn the fine-adjustment knob counter-clockwise until you can see a screw. Remove the screw.
-
Page 19: Operation
Operation 9.1 Saving an image You can save multiple images to the internal camera memory. Approximately 1500 im- ages can be saved to the internal camera memory. The naming convention for images is FLIRxxxx.jpg, where xxxx is a unique counter. Follow this procedure: 1. -
Page 20: Measuring A Temperature Using A Spotmeter
Operation 9.5 Measuring a temperature using a spotmeter You can measure a temperature using a spotmeter. This will display the temperature at the position of the spotmeter on the screen. Follow this procedure: 1. Push the center of the navigation pad. This displays a toolbar. 2. -
Page 21: Working With Color Alarms
Operation 9.10 Working with color alarms By using color alarms (isotherms), anomalies can easily be discovered in an infrared im- age. The isotherm command applies a contrasting color to all pixels with a temperature above or below the specified temperature level. This table explains the different color alarms (isotherms). -
Page 22: Setting The Emissivity As A Surface Property
Operation Automatic Manual Follow this procedure: 1. Push the center of the navigation pad. This displays a toolbar. 2. On the toolbar, select Temperature scale . This displays a toolbar. 3. On the toolbar, select one of the following: • Auto •... -
Page 23: Changing The Emissivity As A Custom Value
Operation Follow this procedure: 1. Push the center of the navigation pad. This displays a toolbar. 2. On the toolbar, select Settings . This displays a dialog box. 3. In the dialog box, select Measurement parameters. This displays a dialog box. 4. -
Page 24: Performing A Non-Uniformity Correction (Nuc)
Operation 9.16 Performing a non-uniformity correction (NUC) When the thermal camera displays Calibrating... it is performing what in thermography is called a ”non-uniformity correction” (NUC). An NUC is an image correction carried out by the camera software to compensate for different sensitivities of detector elements and other optical and geometrical disturbances . -
Page 25: Updating The Camera
9.18 Updating the camera To take advantage of our latest camera firmware, it is important that you keep your cam- era updated. Download firmware updates from our Customer Support Center at http://support.flir.com. #T810252; r. AE/85858/85858; en-US... -
Page 26: Technical Data
10.2 Note about technical data FLIR Systems reserves the right to change specifications at any time without prior notice. Please check http://support.flir.com for latest changes. -
Page 27: Flir Ets320
Rev.: 84743 General description The FLIR ETS320 is FLIR’s first electronic test bench camera, designed for a quick temperature check of PCB boards and electronic devices. The FLIR ETS320 is sensitive enough to detect subtle tempera- ture difference with an accuracy of ±3°C (5.4°F), so you can quickly find hot spots and potential points of failure. - Page 28 Set-up commands Local adaptation of units, language, date and time formats Video streaming Radiometric IR video streaming Full dynamic to PC (FLIR Thermal Studio) using Non-radiometric IR video streaming Uncompressed colorized video using USB Storage of images File formats Standard JPEG, 14-bit measurement data...
- Page 29 • 4220500; FLIR Research Studio, Standard Edition - Perpetual License (online activation) • 4220646; FLIR Research Studio, Standard Edition - Perpetual License (USB dongle) • 4232591; FLIR ResearchIR to Research Studio, Professional Edition - 1 Year License Upgrade #T810252; r. AE/85858/85858; en-US...
-
Page 30: Mechanical Drawings
Mechanical drawings [See next page] #T810252; r. AE/85858/85858; en-US... -
Page 35: Ce Declaration Of Conformity
CE Declaration of conformity The full text of the Declaration of conformity is available at the following internet address: http://support.flir.com/resources/f73v. #T810252; r. AE/85858/85858; en-US... -
Page 36: Cleaning The Camera
Cleaning the camera 13.1 Camera housing, cables, and other items Use one of these liquids: • Warm water • A weak detergent solution Equipment: • A soft cloth Follow this procedure: 1. Soak the cloth in the liquid. 2. Twist the cloth to remove excess liquid. 3. -
Page 37: Thermographic Measurement Techniques
Thermographic measurement techniques 14.1 Introduction An infrared camera measures and images the emitted infrared radiation from an object. The fact that radiation is a function of object surface temperature makes it possible for the camera to calculate and display this temperature. However, the radiation measured by the camera does not only depend on the tempera- ture of the object but is also a function of the emissivity. - Page 38 Thermographic measurement techniques 14.2.1.1.1 Method 1: Direct method Follow this procedure: 1. Look for possible reflection sources, considering that the incident angle = reflection angle (a = b). Figure 14.1 1 = Reflection source 2. If the reflection source is a spot source, modify the source by obstructing it using a piece if cardboard.
- Page 39 Thermographic measurement techniques 3. Measure the radiation intensity (= apparent temperature) from the reflection source using the following settings: • Emissivity: 1.0 • D You can measure the radiation intensity using one of the following two methods: Figure 14.3 1 = Reflection source Figure 14.4 1 = Reflection source You can not use a thermocouple to measure reflected apparent temperature, because a thermocouple measures temperature, but apparent temperatrure is radiation intensity.
- Page 40 Thermographic measurement techniques 5. Measure the apparent temperature of the aluminum foil and write it down. The foil is considered a perfect reflector, so its apparent temperature equals the reflected appa- rent temperature from the surroundings. Figure 14.5 Measuring the apparent temperature of the aluminum foil. 14.2.1.2 Step 2: Determining the emissivity Follow this procedure: 1.
-
Page 41: Reflected Apparent Temperature
50%. 14.6 Other parameters In addition, some cameras and analysis programs from FLIR Systems allow you to com- pensate for the following parameters: • Atmospheric temperature – i.e. the temperature of the atmosphere between the cam- era and the target •... -
Page 42: About Calibration
15.3 Camera calibration at FLIR Systems Without calibration, an infrared camera would not be able to measure either radiance or temperature. At FLIR Systems, the calibration of uncooled microbolometer cameras with a measurement capability is carried out during both production and service. Cooled cam- eras with photon detectors are often calibrated by the user with special software. -
Page 43: The Differences Between A Calibration Performed By A User And That Performed Directly At Flir Systems
The calibration information, no matter if the calibration is done by FLIR Systems or the user, is stored in calibration curves, which are expressed by mathematical functions. As... -
Page 44: Non-Uniformity Correction
About calibration Calibration is also a prerequisite for adjustment, which is the set of operations carried out on a measuring system such that the system provides prescribed indications corre- sponding to given values of quantities to be measured, typically obtained from measure- ment standards. -
Page 45: About Flir Systems
• Extech Instruments (2007) Figure 16.1 Patent documents from the early 1960s FLIR Systems has three manufacturing plants in the United States (Portland, OR, Boston, MA, Santa Barbara, CA) and one in Sweden (Stockholm). Since 2007 there is also a manufacturing plant in Tallinn, Estonia. -
Page 46: More Than Just An Infrared Camera
16.1 More than just an infrared camera At FLIR Systems we recognize that our job is to go beyond just producing the best infra- red camera systems. We are committed to enabling all users of our infrared camera sys- tems to work more productively by providing them with the most powerful camera–... -
Page 47: Supporting Our Customers
16.3 Supporting our customers FLIR Systems operates a worldwide service network to keep your camera running at all times. If you discover a problem with your camera, local service centers have all the equipment and expertise to solve it within the shortest possible time. - Page 48 Disclaimer Specifications subject to change without further notice. Models and accessories subject to regional market considerations. License procedures may apply. Products described herein may be subject to US Export Regulations. Please refer to exportquestions@flir.com with any questions. Ihr Ansprechpartner /...
