JE1569FDM
OPERATING MANUAL
Overhead 15" 16:9 Monitor
15
Before operating the unit, please read these instructions carefully.
OT01005419- 06'10
Safety Precautions:
1. Ensure the plug is securely plugged into the main socket before operating
the unit.
2. Ensure the Voltage on the main socket is the same as specified on the unit.
3. Use parts only manufactured by the unit manufacturers.
4. Ensure the battery is correctly installed before using the unit.
In case of the following emergencies, remove plug from the main socket
immediately:
1. Plug or cables are damaged.
2. Any form of foreign objects dropped inside the enclosure.
3. Unit is being exposed to rain and/or water.
4. Unit unable to operate under normal operation.
Notices:
1. Any changes or modifications made to this unit will void the users warranty.
2. To comply with the FCC RF exposure compliance requirments , no change
to the antenna or the device is permitted. Any change to the antenna or
the device could result in the device exceeding the RF exposure
requirements and void user's authority to operate the device.
This device complies with part 15 of the FCC RULES. Operations is subject to
the following two conditions:
(1) This device may not cause harmful interference and
(2) This device must accept any interference received, including interference that
may cause undisried operation.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER - SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL
The lighting flash with Arrowhead Symbol within an equilateral
triangle is intended to alert the user to the presence of "uninsulated
" dangeros voltage" within the product's enclosure that may be of
sufficient magnitude to consistute a risk of electric shock to persons.
The exclamation point within an equilater triangle is intended to alert
the user to the presence of important operating and maintenace
(servicing) instrucion in the literature accopmpanying the appliance.
