- Page 1 ” 1 DIN CAPACITIVE TOUCH SCREEN MULTIMEDIA MECHLESS RECEIVER AM-FM-RDS SXM-READY USB Multimedia Player Front / Rear Camera Inputs INSTALLATION & OWNER’S MANUAL...
- Page 2 INFORMATION Copyright and Trademark Apple CarPlay is a trademark of Apple Inc. / Use of the Apple CarPlay logo means that a vehicle user interface meets Apple performance standards. Apple is not responsible for the operation of this vehicle or its compliance with safety and regulatory standards.
- Page 3 JENSEN dealer or call tech assistance @ 1-888-921-4088. surface of the panel and/or remove the printing. screen will become darker than usual. Normal brightness will return after the unit is in use for a while.
- Page 4 INSTALLATION Preparation Please read and understand entire manual before installation. assistance. Before You Start temperatures, such as from direct sunlight, or where it would be Getting Started are unsure. harness adapter (sold separately).
- Page 5 (1) 15 amp ATO blade-type fuse located on the back of the unit. Wiring Notes: Front / Rear camera inputs Up to two cameras (not included) can be used. We recommend optional JENSEN Backup Camera Part # BUCAM200J for FRONT CAMERA and BUCAM300AJ or BUCAM400AJ for REAR CAMERA SiriusXM For more information on how to install the SiriusXM Connect Vehicle tuner, consult the installation guide included with the tuner.
- Page 6 OPERATION Getting Started - First Time Setup Wizard SETUP WIZARD will help guide you through the main radio system settings and connect to your Bluetooth Device. STEP 1 STEP 2 Select Language Set the Clock STEP 3 STEP 4 Set Radio Region Set RDS Functions STEP 5 STEP 6...
- Page 7 OPERATION Main Control Locations ⑤ ⑥ ⑥...
- Page 8 OPERATION Source Menu Operation Full Screen Clock Home Source Menu Press for Top 3 Sources in use Quick Select Sources Radio Tuner Direct Access Radio Main Media Player Direct Access Media Player BT Phone Handsfree Calling Direct Access Press for full screen Clock -> press Full Screen Clock anywhere again to return to previous mode Direct access to System Setup Menu...
- Page 9 OPERATION AM/FM Tuner Operation Full Screen Clock Loc/Dx Home Source Menu Press for Top 3 Sources in use Quick Select Sources Press for AM | FM | SXM Radio BAND Selector (Optional SXM Tuner required) To store Channel Presets - Press and HOLD 3 seconds BAND 1 2 3 Presets 1~18 Stereo | Mono Indicator Stereo | Mono...
- Page 10 OPERATION Media Player - USB / BT Music / AV AUX Input Media Player - USB Music Media Player - BT Music Media Player - AV AUX Input...
- Page 11 OPERATION SiriusXM Satellite Radio Activation ® Only SiriusXM Satellite Radio brings you more of what you love SiriusXM Radio ® ® to listen to, all in one place. Get over 140 channels, including Activating commercial-free music plus the best sports, news, talk, comedy and entertainment.
- Page 12 OPERATION SiriusXM Satellite Radio Operation - Part 1 ® Full Screen Clock Home Source Menu Band Selector Press for SXM Band 1 | Band 2 | Band 3 Satellite Strength Satellite Signal Strength Indicator BAND Presets 1~6 To store Channel Presets - Press and HOLD 3 seconds Channel Info Current Channel number Indicator File Information...
- Page 13 OPERATION SiriusXM Radio Operation - Part 2 ® Channel Manager Home Source Menu Press for any of Top 3 Sources in use Quick Select Sources Channel Information Channel List Press to return to SXM mode Media Player Channel | Artist | Song | Info Info Selection Drag up or down for quick page scrolling Page Scrolling...
- Page 14 OPERATION SiriusXM Radio Operation - Part 3 ® Favorite Selection Press here to select Alert is active when a Favorite Song or Artist is available Favorites Manager Home Source Menu Press for any of Top 3 Sources in use Quick Select Sources Stored Favorites List Favorites List Press to return to SXM mode...
- Page 15 OPERATION SiriusXM Parental Control ® Settings Menu 1. On the SirusXM menu touch Parental Control. The Enter password Screen appears. 2. Enter your 4-digit password. The following screen appears: Lock / Unlock Screen 3. Touch to Station lock, touch lock icon to unlock, the icon will disappear. Channel is unlocked.
- Page 16 OPERATION SiriusXM Radio Advisory Messages ® SiriusXM Recommendation Advisory Message The radio has detected a fault with the SiriusXM antenna. The antenna cable may be either disconnected or damage. Verify that the antenna cable is connected to the SiriusXM Connect Vehicle Tuner.
- Page 17 OPERATION iDatalink Maestro This Jensen receiver connects with a compatible iDatalink Maestro programmable interface (optional, purchased separately * ), allowing the unit to display OEM features and functions such as Vehicle Info, Parking Assistance, and Climate Control, as well as retaining other capabilities which could include steering wheel controls and voice commands.
- Page 18 OPERATION 10-BAND Equalizer 10-Band Sliders Press to custom adjust frequencies 7 Presets + 1 Custom Flat | R&B | Rock | Pop | HipHop | Jazz | Custom RESET RESET all frequencies to Flat Press to return to previous Source Mode Tips Each SOURCE will remember their respective EQ settings System Audio Settings...
- Page 19 OPERATION Bluetooth - Handsfree Operation Home Source Menu Top Used Sources Press for Direct Access to Top Sources Signal Strength Carrier Signal Strength Indicator Keypad Press to Dial the Call Contacts Press to see Contact List Recent Calls Press to see most recent Received / Missed Call List Device Press for Device Setup Number to Dial...
- Page 20 OPERATION Media Player - USB Top 3 Sources Home Source Media Player Menu USB Playback Press desired option to select between audio sources for Source Selector only available for USB playback. Track Number Elapsed Time Press to access and adjust audio settings. Audio Tune/Track Up forward through the current track.
- Page 21 OPERATION Media Player - BT Music / AV AUX Input Media Player - Bluetooth Music Press desired option to select between audio sources for Source Selector only available for USB playback. Track Number Elapsed Time Press to access and adjust audio settings. Audio Tune/Track Up forward through the current track.
- Page 22 OPERATION Bluetooth - Handsfree Operation Top 3 Sources Home Source Menu Before you can use a Bluetooth device, it must be Preparation paired and connected. Make sure that Bluetooth is activated on your device before you begin the pairing process. The unit broadcasts the pairing signal constantly Pairing a New when no devices are currently connected.
- Page 23 OPERATION Press to display a list of paired devices, and select desired device to connect. Use the keypad to dial a number. Keypad Press to connect a call to the number entered. Talk Press to backspace when using the keypad. Backspace Phone Number Press to end a call.
- Page 24 OPERATION Connected Mobile Devices - Apple CarPlay Apple CarPlay. The ultimate copilot. CarPlay is a smarter, safer way to use your iPhone in the car. CarPlay takes the things you want to do with your iPhone while driving and puts them right on your display.
- Page 25 CarPlay feature. Any other devices connected via Bluetooth will be disconnected during CarPlay use. Exit CarPlay manually while your phone is still connected, press the Jensen button momentarily, and the unit’s main SOURCE menu will be displayed.
- Page 26 OPERATION Connected Mobile Devices - Android Auto Android Auto brings the most useful apps to your phone screen or units display, in a format that makes it easy for you to keep your main focus on driving. You can control things like navigation distraction so you can stay focused on the road.
- Page 27 OPERATION Starting Android Auto Connect an Android Auto compatible device to the unit via USB cable. Android Auto will launch automatically, or it can be accessed at any time from the main menu. Note: When the device for Android Auto is connected to this unit, the device is also to delete the device, touch [Agree].
- Page 28 OPERATION Connect an optional rear camera to the Rear Camera Rear Camera RCA connector for audio). Refer to the wiring diagram for details. Manual selection - Touch the REAR CAMERA icon from the Main Menu or from any operational mode (when enabled) to select camera mode.
- Page 29 OPERATION Media Compatibility File Type FAT 12 File System FAT 16/FAT 32 .mp3/.MP3/.Mp3/.mP3 File Extension .rmp/.m4a MPEG 1 MPEG MPEG 2 Format MPEG 2.5 MPEG 1 32/44.1/48kHz Sampling MPEG 2 12/16/22.05/24kHz Frequency MPEG 2.5 8/11.025/12kHz MPEG 1 32 ~ 320kbps Bitrate MPEG 2 8 ~ 160kbps...
- Page 30 OPERATION Settings Menu From the Main Menu, press the gear icon to access the Setup menu and Swipe down for more settings General: • Time ime - Pres set the time. • • • • • • K K ey Beep - urn the key beep on or off.
- Page 31 OPERATION Settings Menu Radio: • • • Traffic Announcements - Enable or disable this feature. • Alternate Frequencies - Enable or disable this feature. Bluetooth: • Bluetooth - Turn Bluetooth signal on or off. • Auto Answer - Turn auto answer feature on or off. •...
- Page 32 OPTIONS Steering Wheel Controls A third-party adapter must be used in order for the to be compatible with any OEM steering wheel controls. has a built-in 3.5mm SWC interface that compatible with many popular 3rd party SWC control modules, such as PAC, METRA, and others. 3.5mm SWC port located on the rear of the unit, on the MAIN POWER I/O Harness Replace with...
- Page 33 WARRANTY Limited One Year Warranty vary from state to state. Namsung America Inc. warrants this product to the original purchaser to be free from defects in material and workmanship for a period of one year from the date of the original purchase. Namsung America Inc.
- Page 34 Please keep your original sales receipt and be prepared to provide this receipt in the event you require service, as your original receipt is considered the best proof of purchase and indicates the date you purchased your JENSEN product. Dealer Info Dealer Name:...
- Page 35 GENERAL FM Tuner US Tuning Range: 87.5MHz-107.9MHz EU Tuning Range: 87.50MHz-108.00MHz Usable Sensitivity: 8.5dBf 50dB Quieting Sensitivity: 10dBf Stereo Separation@ 1kHz: 30dB Frequency Response: 30Hz-13kHz AM Tuner Tuning Range: 530kHz-1710kHz Usable Sensitivity: <42dBu Frequency Response: 30Hz-2.2kHz Bluetooth Version: 4.1 + EDR HFP / A2DP / PBAP Range: Up to 33ft / 10m...
- Page 36 INSTALLATION & OWNER’S MANUAL Customer Support 1-888-921-4088 (Monday-Friday, 9AM-5PM EST) Visit https://www.jensenmobile.com Designed and Engineered in USA All rights reserved. No part of this publication may be reproduced, distributed, or transmitted in any form or by any means, including photocopying, recording, or other electronic or mechanical methods, without the prior written permission of NAMSUNG AMERICA INC.
