- Page 1 JRV4100 Installation and Owner’s Manual...
-
Page 2: Table Of Contents
Content Accessories ………………………………………………………………………………………………………………………………………... Unit Installation ……………………………………………………………………………………………………………………………….. Wire Connection ……………………………………………………………………………………………………………………………… Parking Brake Connection ……………………………………………………………………………………………………… Speaker connection ………………………………………………………………………………………………………………………. Button Description …………………………………………………………………………………………………………………………. Remote Control ……………………………………………………………………………………………………………………………….. Main Menu …………………………………………………………………………………………………………………………………………... Radio Operation ………………………………………………………………………………………………………………………………. USB /SD Operation ……………………………………………………………………………………………………………………….. Settings Operation ……………………………………………………………………………………………………………………….. Bluetooth Operation …………………………………………………………………………………………………………………….. Aux-In Operation ……………………………………………………………………………………………………………………………... -
Page 3: Accessories
Accessories Package contains the following accessories for installation and operation of the unit. Washer, Spring Washer, 1 each M5 Nut Metal Mounting Strap Hex Bolt Screw Max. 8mm (7/32 x max. 5/16 in) Metal Mounting Sleeve Release Key Tapping Screw Rubber Cushion Remote Control User Manual... -
Page 4: Unit Installation
Unit Installation Wire Connection The Description of the Input/Output Interface of the Rear Chassis. -
Page 5: Parking Brake Connection
Parking Brake Connection In order to view videos, the parking brake wire must be connected, and the vehicle is parked Connecting the reversing line to taillight on the car... -
Page 6: Speaker Connection
Speaker Connection Connect the speakers according to the following diagram, incorrect connections may damage the unit or your speakers. Do not chassis ground the speakers. Always observe correct polarity. Correct connection Left front - Right front | Left rear - Right rear Incorrect connections... -
Page 7: Button Description
Button Description 1. MIC 2. RETURN Button Press return button to go back to previous menu. 3. HOME BUTTON Press home button to return back to main menu. 4. SOURCE BUTTON Press source button to change mode. 5. POWER / MUTE Button /VOL Press it to turn on the unit. -
Page 8: Remote Control
Remote Control 1: POWER 2: MODE 3: LEFT 4: PREVIOUS/Accept 5: VOLUMN DOWN 6: MUTE/BLUETOOTH 7: UP 8: OK 9: DOWN 10: MENU 11: SERARCH 12: RIGHT 13: NEXT/REJECT 14: VOLUMN UP 1. POWER button Power on or power off. 2. - Page 9 Remote Control 10. MENU Press it to show main menu. 11. SEARCH button Press to auto store AM/FM stations. 12. RIGHT button Press it to move cursor right. 13. NEXT/REJECT button In USB / SD mode, , press button to skip to the next track In Radio mode, press to seek to next station.
-
Page 10: Main Menu
Main Menu The best way to discover the program is to explore each screen in detail, and to find out how to move from one to another. Read this chapter for a guided tour. Unit starts by displaying the main menu. This is the root of the screen hierarchy, and you can simply access all features by tapping on the touch screen buttons. -
Page 11: Usb/Sd Operation
USB/SD Operation When a file of USB or SD card is played (music, video, photo), the screen will show following interface: Music Controls Press to skip to the previous track. Play/pause button. Press to skip to the next track. Press to play track randomly Press to repeat (REP 1 =>... - Page 12 Settings Operation Tap Wallpaper button to setup wallpaper SWC: When the green cable for steering wheel control connected to the steering wheel, we can use the steering wheel to control unit Sound Control button to Sound Control page EQ : select User—Classic—Rock—Pop—Jazz—Flat Subwoofer Connect the subwoofer to the unit using sub output (see electrical diagram).
-
Page 13: Bluetooth Operation
Bluetooth Operation Warning: Driving and having a telephone conversation at the same time is dangerous, please park your car before having a telephone conversation. The supplier waves any and all liability when this warning is not followed. Bluetooth section To enter bluetooth mode, you can tap bluetooth icon on main menu or long press the mute/bluetooth button on the remote control or press mode button on remote. -
Page 14: Aux-In Operation
Bluetooth Operation (A2DP) Streaming Music Mode A2DP (Advanced Audio Distribution Profile) Music Player A2DP is a function which can receive the audio frequency signal from the mobile phone, amplified by the car audio and played out by the car speakers. Notice: your mobile phone need to support A2DP. - Page 15 Troubleshooting Symptom Cause Remedy Replace with fuse of the same amperage. If Power does not turn Fuse is blown the fuse blows again, consult your store of purchase (No sound is produced) Incorrect wiring Consult your local retailer 1. Turn off the unit 2.
-
Page 16: Troubleshooting
Troubleshooting symptom Cause Solution If the power supply is properly connected The car ignition is not on to the car accessory switch the ignition key to “ACC” No power The fuse is blown Replace the fuse Volume is in minimum Adjust volume to a desired level No sound Wiring is not properly... -
Page 17: General Specification
General Specification General Power supply 11~16V DC Current consumption Max. 10 A Maximum power output 45W x 4 channels (max) Compatible formats MP3,WMA,JPEG,AVI Dimensions (W x D x H) / weight 6.5” x 7.0” x 3.9” /4.15 lbs Working temperature range -4°F -- +140°F TFT display Screen size... - Page 18 FCC WARNING This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Any changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment.
