Powerline FA 500.3
english
1.990.999.110 E – 02/2018
OPERATING MANUAL
SHREDDER

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Powerline FA 500.3 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for HSM Powerline FA 500.3

Summary of Contents for HSM Powerline FA 500.3

  • Page 1 OPERATING MANUAL SHREDDER Powerline FA 500.3 english 1.990.999.110 E – 02/2018...

  • Page 2: Table Of Contents

    Transportation, installation ..................7 Operating and display elements ................. 9 Start-up ........................10 Shredding material ....................11 Malfunctions ......................12 Maintenance ......................14 Disposal / Recycling ....................16 Scope of supply, accessories ..................16 Technical data ......................17 EU declaration of conformity .....................18 HSM Powerline FA 500.3 02/2018...

  • Page 3: Basic Safety Instructions

    – It is prohibited to operate one only machine of a combination-version machine. NOTICE The safety distances are only guaranteed with is used when property damage may the combined document shredder and HSM occur by failure to comply. press. Note indicates information for the effective –...

  • Page 4: Proper Use, Warranty

    6 x 40 - 53 mm, 7.5 x 40 - 80 mm and 10.5 x 40 - 76 mm. The document shredder is supplied as a single or combined machine (with a HSM baling press). Please observe the applicable instructions in the operating manual.

  • Page 5: Overview

    3 Overview HSM GmbH + Co. KG Austrasse 1-9 88699 Frickingen / Germany Folie: Polycarbonat 125 mic Klebstoff: 3M 468 MP Datum Name Druck: Siebdruck Bearb. 7.11.2010 Hainke Aufkleber Sicherheitshinweise Gepr. Farbe: M 1:2 Norm Hintergrund: RAL 7035 lichtgrau Rest: schwarz ÄM 1807...

  • Page 6: Dimensions

    4 Dimensions 1168 1168 1797 HSM FA 500.3 3300 1797 1000 Space requirements for operation and maintenance HSM Powerline FA 500.3 02/2018...

  • Page 7: Transportation, Installation

    Make sure the power cable is un- obstructed and that nobody can tread on it. • Insert the plug (connection for emergency stop switch bar) into the socket next to the main switch and turn it to stop. HSM Powerline FA 500.3 02/2018...
  • Page 8 (5). • Insert the machine’s power plug into the connec- tion socket. NOTICE Extension cables are not permitted. Connect the power plug of the con- veyor belt using the coupling of the document shred- der. HSM Powerline FA 500.3 02/2018...

  • Page 9: Operating And Display Elements

    Function button “On/off/start” Indicator: Level 2 overload Indicator: Level 1 overload only for machines with 1.9 x 15 mm cutting widths Display with no function Indicator: Paper container full Indicator: Ready for operation HSM Powerline FA 500.3 02/2018...

  • Page 10: Start-Up

    Do not put the document shredder into operation until the loading tray is fitted. The safety distance to the cutting unit is not observed. Danger of injury from pinched fingers between feed belt and loading table HSM Powerline FA 500.3 02/2018...

  • Page 11: Shredding Material

    • You can now remove the material from the belt and start the shredder again by pressing the start button. Note If the cutting unit is running in the shred- ding direction, you can stop it by pressing the R button. HSM Powerline FA 500.3 02/2018...

  • Page 12: Malfunctions

    You can secure the main switch in this position using a padlock. Electric motor overheated  “Overload” display flashes.  The shredder switches off automatical- • Let the motor cool down for 20 – 30 minutes. • Press the start button. HSM Powerline FA 500.3 02/2018...

  • Page 13: Automatic Reversing

    4 hours of operation. The cutting apparatus and feed belt run in reverse for a short period. The machine then switches off. • Press the start button in order to start up again. HSM Powerline FA 500.3 02/2018...

  • Page 14: Maintenance

    Recommended lubricating grease: K2K in accord- ance with DIN 51502/DIN 51825 • Mount the inspection flaps onto the unit again. HSM Powerline FA 500.3 02/2018...
  • Page 15 Checking the feed belt for wear The surface of the feed belt can become worn after long periods of use. If you can see the fabric inlay in the belt, it must be replaced. Please notify our cus- tomer service. HSM Powerline FA 500.3 02/2018...

  • Page 16: Disposal / Recycling

    As the equipped with this type manufacturer, HSM would be glad to advise you on of conveyor belt (op- the disposal of your old machine. tional extra).

  • Page 17: Technical Data

    3 x 208 V, 60 Hz 3 x 200 V, 50-60 Hz Rated current 22 A 22 A 36 A 44 A 44 A Fuse 32 A gG/gl/C/K 32 A gG/gl/C/K 50 A gG/gl/C/K 50 A gG/gl/C/K 50 A gG/gl/C/K HSM Powerline FA 500.3 02/2018...

  • Page 18: Eu Declaration Of Conformity

    EU declaration of conformity The manufacturer HSM GmbH + Co. KG, Austrasse 1 - 9, 88699 Frickingen / Germany hereby declares that the machine document shredder HSM Powerline FA 500.3 corresponds to the health and safety requirements of the following EU directives listed below due to its conception and design of...
  • Page 19 HSM Powerline FA 500.3 02/2018...
  • Page 20 HSM GmbH + Co. KG Austraße 1-9 88699 Frickingen / Germany Tel. +49 7554 2100-0 Gratis Hotline Fax +49 7554 2100 160 DE, AT, BE, NL, LU, IT info@hsm.eu Tel. 00800 44 77 77 66 www.hsm.eu Fax 00800 44 77 77 67 HSM (UK) Ltd.
