HSM FA 400.2
english
Keep in a safe place for future use!
OPERATING MANUAL
SHREDDER
1.513.999.112 – 0702

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HSM FA 400.2 and is the answer not in the manual?

Questions and answers

Related Manuals for HSM HSM FA 400.2

Summary of Contents for HSM HSM FA 400.2

  • Page 1 OPERATING MANUAL SHREDDER HSM FA 400.2 english Keep in a safe place for future use! 1.513.999.112 – 0702...

  • Page 2: Table Of Contents

    WS7 3GJ Tel. +44(0) 1543.272.480 +44(0) 1543.272.080 info@hsmuk.co.uk www.hsmuk.co.uk HSM of America LLC 1075 Andrew Drive, Suite C West Chester HSM GmbH + Co. KG PA 19380 Bahnhofstrasse 115 88682 Salem / Germany Tel. (610) 918-4894 (800) 613-2110 (610) 918-4899 Tel.

  • Page 3: Proper Use, Warranty

    It is prohibited to operate one only machine of a combination-version machine. Only the combination of document shredder and Switch off the shredder and pull HSM baling press fulfi ls the requirements of out the power plug EN 294 (Safety clearances). before moving or cleaning the shred- •...

  • Page 4: Overview

    FA 400.2 3. Overview Main switch (only solo-version) Keypad Emergency stop button Loading tray Option: extra-wide work table Left cover panel Right cover panel Intake conveyor, paper feed opening Front door Braking swivel castors Oiler on particle cut machines Nameplate 0702...

  • Page 5: Dimensions

    FA 400.2 4. Dimensions 1157 1564 HSM FA 400.2 Solo version 1157 1644 HSM FA 400.2 Combi version 1262 2414 Transportation dimensions (without tray) Space requirements for operation and maintenance 0702...

  • Page 6: Transportation, Installation

    FA 400.2 5. Transportation, installation • The shredder may only be placed in dry rooms on a hard, level fl oor – not on carpets. The fl oor load on • Place the shredder in its packaging on a smooth, level each roller is approximately 107 kg.

  • Page 7: Operating And Display Elements On The Keypad

    FA 400.2 6. Operating and display elements on the keypad Paper jam or overload Ready for operation Red LED Green LED Door open Waste bag full Red LED Red LED Start button The shredder switches on. The feed belt moves in the intake direction.
  • Page 8 FA 400.2 Inspecting the safety devices Shredding material Check that the safety devices are working properly: • At the start of each shift • After any maintenance or repair work Do not start the machine until you have checked the emergency stop button and the door switch and found them to be in perfect working order.

  • Page 9: Malfunctions

    FA 400.2 Stopping the shredder 8. Malfunctions • Press the stop button. Check the following before calling customer service: The cutting block and feed belt stop. • Is the power plug connected? The shredder switches to standby mode. • Is the shredder switched on? •...

  • Page 10: Maintenance And Care

    FA 400.2 9. Maintenance and care Checking the chain tension (twice yearly) Cleaning the cutting block • Switch off the shredder. Strip cut machines: (1 x daily) • Switch off the shredder. • Pull out the power plug. • Squirt special cutting apparatus oil through •...
  • Page 11 FA 400.2 Greasing the drive chains and cogs (twice You must check that the feed belt runs straight: yearly) Switch on the shredder and let it run for 10 minutes. During this time, the feed belt • Switch off the shredder. must run in the middle of the snub roller.

  • Page 12: Scope Of Supply, Accessories

    FA 400.2 10. Scope of supply, accessories • Machine on pallet with a wooden frame, strapped with packing tape and packed in foil • 4 waste bags, order no. 1.513.995.000 for 2-chamber system (Solo version) • 1 waste bag, order no. 1.513.995.100 for 1-chamber system (Solo version) •...

  • Page 13: Electric Wiring Diagrams For Solo- And Combination-Version

    FA 400.2 12. Electric wiring diagrams Legend: =AV: Shredder in switch cabinet +MA: on machine +BF: Keypad Solo 400 V / 50 Hz 0702...
  • Page 14 FA 400.2 0702...
  • Page 15 FA 400.2 0702...
  • Page 16 FA 400.2 Combination 400 V / 50 Hz 0702...
  • Page 17 FA 400.2 0702...
  • Page 18 FA 400.2 0702...
  • Page 19 FA 400.2 0702...

  • Page 20: Declaration Of Conformity

    Low voltage directive 73 / 23 / EWG The manufacturer HSM GmbH + Co. KG, Bahnhofstrasse 115, D-88682 Salem declares herewith, that the paper shredder (Solo machine) HSM FA 400.2 corresponds with the above mentioned EC Machine Directive including all relevant modifi cations.
