- Page 1 — ProPulse 2 Series ® ® Mini Turbine Flow Meter Quick Start Manual Read the user's manual carefully before starting to use the unit. Producer reserves the right to implement changes without prior notice. 24-0510 © Icon Process Controls Ltd.
-
Page 2: Safety Information
Hall Effect Sensor, which converts the rotation into a square wave NPN pulse, 4-20mA, IO-Link or RS485 output that ProPulse ® can be sent directly to a metering pump, local display or PLC. Display 24-0510 © Icon Process Controls Ltd. -
Page 3: Application Example
Ultra Low Flow Ranges | 40 ml/min | 0.01 GPM Superior Mechanical Properties Variety of End Connections: Hose Barb | Threaded | Flared | Straight Pipe Pulse | 4 – 20mA | RS485 | IO-Link PVDF Compact Lightweight Design ⅛” to ½” Sizes 24-0510 © Icon Process Controls Ltd. -
Page 4: Electrical Connections
(no Internal wiring required) Keyed to ensure correct connection 31.7 Hose Barb : 03H Hose Barb : 06H Ø6.0 Ø9.0 Ø43.5 16.0 20.0 Straight Tube : 06T Straight Tube : 04T Ø6.0 Ø9.0 Ø60.2 20.0 20.0 24-0510 © Icon Process Controls Ltd. -
Page 5: Exploded View
LED: 4-20mA + Pulse PP-M-06T-PP PP-M-06T-PF ⅜” Tube x Tube PP2-TT38 ⅜” Hose Barb LED: 4-20mA + Pulse PP-M-06H-PP PP-M-06H-PF ¼” Tube x NPT PP2-TN14 ⅜” Flared LED: 4-20mA + Pulse PP-M-06F-PP ⅜” Tube x NPT PP2-TN38 24-0510 © Icon Process Controls Ltd. -
Page 6: Keypad Functions
ALt = 3 ≥ ≥ Alarm ON ; > < Alarm OFF AL + Hys AL – Hys AL + Hys SV – Hys ALt = 4 ≥ ≥ Alarm OFF ; > < Alarm ON 24-0510 © Icon Process Controls Ltd. - Page 7 Note: Set LK 19 in Lock Settings (Refer to Page 6) STEPS DISPLAY Range OPERATION Main Display ▶ 0~9999 Current Value �� 3 Sec. Transmitter Range ▶ 20mA (High) Range 20mA Value ▶ 0~9999 Set 20mA - Max. Flow Rate 24-0510 © Icon Process Controls Ltd.
- Page 8 Alarm Delay Time 00H 03H K Factor 00H 07H Decimal Point Selecting 00H 0BH Output Status* 00H 04H Alarm Value Setting 00H 08H Unit Selecting 00H 0CH Output Status* Data Alarm 00H 00H 00H 01H 24-0510 © Icon Process Controls Ltd.
- Page 9 4. Adopt filtering device in the upstream to avoid the paddle wheel from be damaged by the solids or fibers. Do not flush the pipe after the measuring unit being installed, if do that may crack the ceramic shaft. 24-0510 © Icon Process Controls Ltd.
- Page 10 Icon Process Controls Ltd for a period of one year from the date of sale of such products. Icon Process Controls Ltd obligation under this warranty is solely...
