— ProPulse
2 Series
®
®
Mini Turbine Flow Meter
Quick Start Manual
1
24-0243
© Icon Process Controls Ltd.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Truflo ProPuIse 2 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for ICON Truflo ProPuIse 2 Series

Summary of Contents for ICON Truflo ProPuIse 2 Series

  • Page 1 — ProPulse 2 Series ® ® Mini Turbine Flow Meter Quick Start Manual 24-0243 © Icon Process Controls Ltd.

  • Page 2: Safety Information

    Always utilize the most appropriate PPE during installation and service of Truflo products. Please Ensure Full Pipe ProPulse2 Series can be installed in a horizontal or vertical direction. Please ensure enough length of straight pipe to avoid ® turbulence that can effect readings. 24-0243 © Icon Process Controls Ltd.

  • Page 3: Product Description

    M : LED Display with 4-20mA | NPN 04T : 1/4" Straight Tube 06F : 3/8" Flared PA : PFA R : LED Display with RS485 04F : 1/4" Flared P : LED Display with NPN | PNP 24-0243 © Icon Process Controls Ltd.

  • Page 4: Technical Specifications

    NPN Output White NPN Output White NPN Output White White NPN Output Blue -VDC Blue -VDC Blue -VDC Blue -VDC Blue -VDC Black PNP Output Black +mA Output Black PNP Output Black Black +mA Output 24-0243 © Icon Process Controls Ltd.
  • Page 5 In Setting Status : The Settable Digit is Flicker Key : To Change the Numerical Value Key : To Shift the Digit Key : To Enter into Setting Status or Load the Setting Value 24-0243 © Icon Process Controls Ltd.
  • Page 6 PV > AL + Hys or PV < SV - Hys Alarm OFF ALt = 4 AL + Hys AL - Hys Alarm OFF ; PV > AL + Hys or PV < SV - Hys Alarm ON 24-0243 © Icon Process Controls Ltd.
  • Page 7 Press 0~9999 Alarm Set Point Alarm Setting Status Press 0~9999 Enter Value Alarm Value Setting Press 0~9999 Alarm Hysterisis Alarm Hysteresis Setting Status Press Enter Value 0~9999 Alarm Hysteresis Prevents Relay Chatter Setting Press 24-0243 © Icon Process Controls Ltd.
  • Page 8 Press 0~9999 Alarm Set Point Alarm Setting Status Press 0~9999 Enter Value Alarm Value Setting Press 0~9999 Alarm Hysterisis Alarm Hysteresis Setting Status Press 0~9999 Enter Value Alarm Hysteresis Setting Prevents Relay Chatter Press 24-0243 © Icon Process Controls Ltd.

  • Page 9: Parameter Address

    00H 03H K Factor 00H 07H Decimal Point Selecting 00H 0BH Output status* 00H 04H Alarm Value Setting 00H 08H Unit Selecting 00H 0CH Output Status* Data Alarm Data Alarm 00H 00H 00H 01H 24-0243 © Icon Process Controls Ltd.

  • Page 10: Flow Range

    * Note : K factor can be modified to fit specific application Dimensions (mm) 31.7 Hose Barb : 03H Hose Barb : 06H Ø6.0 Ø9.0 Ø43.5 16.4 16.0 20.0 Straight Tube : 06T Straight Tube : 04T 14.5 Ø6.0 Ø9.0 20.0 20.0 Ø60.2 24-0243 © Icon Process Controls Ltd.
  • Page 11 Please adopt filtering device in the upstream to avoid the paddle wheel from be damaged by the solids or fibers. Please do not flush the pipe after the measuring unit being installed, if do that may crack the ceramic shaft. 24-0243 © Icon Process Controls Ltd.

  • Page 12: Warranty

    Warranty Icon Process Controls Ltd warrants to the original purchaser of its products that such products will be free from defects in material and workmanship under normal use and service in accordance with instructions furnished by Icon Process Controls Ltd for a period of one year from the date of sale of such products.
