- Page 1 Quick Start Manual Quick Start TankPro Series Level Sensor + LED Display ® Designed by Icon Process Controls ™ (½) Corrosion- Free ICON Instrumentation Equipment PROCESS CONTROLS...
-
Page 2: Led Display
LED Display Continuous Level Transmitter Suitable For Foam | Vapor | Turbulence | Condensate PVDF PTFE 316SS Exceptional Chemical Resistance PTFE Teflon Jacketed Cable Seals: FFKM | FPM | EPDM The Solution to Tough Applications Where Ultrasonic Sensors Simply DO NOT WORK! 100 Series Submersible Sensor Before After... - Page 3 Series LED Display LED Display Continuous Level Transmitter Continuous Level Transmitter Wiring Power Supply 24 VDC 24VDC Connector 1 Connector 2 Exchange Gortex Breather Do Not Block...
-
Page 4: Application Details
Series LED Display Continuous Level Transmitter Understanding Level Measurement Submersible Sensors All Submersible Sensors have a Calibrated Range that is Based on O that has a Specific Gravity or Density = 1 Range Value | The Overall Measuring Distance that the Sensor has been calibrated to by 20mA Full the Factory - The Range will be Located on the Sensor Body... -
Page 5: Getting Started
Series LED Display Continuous Level Transmitter Getting Started Pressure are designed to be completely submersed within . The transmitters can rest along the bottom of the tank or be suspended at any desired level within the tank. Please note that the physical location of the level transmitter will indicate the lowest level of measurement within the tank. - Page 6 Series LED Display LED Display Continuous Level Transmitter Continuous Level Transmitter Calculating Max Range of Sensor Lets assume a the calibrated range of the s ' or . The range is always referenced H which has a specific gravity S.G or (Density) equal to 1 Calibrated Range/S.G = Liquid Level Measurement Range 34/1 = 34' or 408/1 = Liquid Level Range = 408"...
-
Page 7: Installation
Series LED Display Continuous Level Transmitter Installation Fig A The Submersible Level is designed to operate while immersed in liquid. Installing the level transmitter along the bottom of the tank if materials such as sludge will build up and coat/cover the transmitter. This also includes any debris that will settle along the bottom of the tank. -
Page 8: Programming Display
Series LED Display Continuous Level Transmitter Programming Display STEPS DISPLAY OPERATION Press and old oth Buttons Together uttons to nter the Release Buttons Enter Pass Code 1234 Using the UP rrow, Press 4 imes until the Password eads '1234' Press Click oth uttons at the ame ime to Proceed into the 4mA Empty... - Page 9 Series LED Display Continuous Level Transmitter Trouble Shooting the Sensor DIGITAL MULTIMETER First, verify that the sensor is wired correctly. Next, check if the power supply is providing the required power. 1000 24VDC POWER SUPPLY 2000 2000 24.0 2000k 200k 2000 NPN PNP SENSOR...
- Page 10 Breather to allow air to pass but not ® water. Please Ensure this Not Blocked Confirm Programming Input for for 20mA (d IH on Display) is Correct Confirm Specific Gravity of Liquid is Correct. Designed by Icon Process Controls...
- Page 11 Warranty Icon Process Controls Ltd warrants to the original purchaser of its products that such products will be free from defects in material and workmanship under normal use and service in accordance with instructions furnished by Icon Process Controls Ltd for a period of one years from the date of sale of such products.
