- Page 1 Stand-on Floor Scale USER MANUAL MS6110 Please keep the instruction manual at hand and follow instruction for use.
-
Page 3: Table Of Contents
CONTENTS I. Explanation of Graphic Symbols on Label/Packaging ..... 4 II. Copyright Notice ..............6 III. Safety Notes ............... 7 A. General Information ............7 B. EMC GuidanceandManufacturer's Declaration ......11 IV. Installation ................ 15 A. Assembly ................ 15 B. Inserting Batteries ............15 C. -
Page 4: Explanation Of Graphic Symbols On Label/Packaging
I. Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use. - Page 5 Device complies with EC directives (verified models only) M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if...
-
Page 6: Copyright Notice
Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual. -
Page 7: Safety Notes
III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner. -
Page 8: Safety Instructions
(c) Language - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user. -
Page 9: Maintenance
Warranty/Liability If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid. -
Page 10: Incident Reporting
Warning Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction. Do not touch the power supply with wet hands. Do not crimp the power cable, and avoid sharp edges. -
Page 11: Emc Guidanceandmanufacturer's Declaration
B. EMC GuidanceandManufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic environment-guid... - Page 12 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance level Electromagnetic test level environment-guida...
- Page 13 Conducte 3 Vrms 3 Vrms Portable and mobile RF communications 150 KHz to 80 150 KHz to 80 d RF IEC equipment should be used no closer to 61000-4- any part of the product including cables, than the recommended separation 6 V in ISM bands 6 V in ISM distance calculated from the equation...
- Page 14 The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.
-
Page 15: Installation
IV. Installation A. Assembly Device does not require assembly, and can be used once power is supplied. B. Inserting Batteries Insert batteries in compartment 2. Turn on power to confirm that battery is correctly installed. C. Using Adapter 1. Connect adapter to device before connecting to mains power supply 2. -
Page 16: Indicator
V. Indicator A. Indicator and Key Functions Key Function 1. ON/OFF: Power button. Weighing results will face patient when device is initially powered on. 2. HOLD/BMI: Press once to Hold (determine stable weighing value - used when weight is unstable). Press and hold for 3 seconds to enter Body Mass Index (BMI) calculation mode. -
Page 17: Using Device
VI. Using Device A. Basic Operation Switch on the device using [ON/OFF] key. (To turn off device, press and hold [ON/OFF] key for 3 seconds) The device will automatically perform self-calibration, displaying software version. Once "0.00 kg" appears on indicator, device is ready for measurement. Note: If "0.00 kg"... -
Page 18: Tare
C. Tare The tare function allows the user to deduct the weight of objects from the device's measurement result. 1. Place object that needs to be tared onto measurement platform. 2. Press [ZERO/TARE]key after stable symbol appears on indicator. Display will indicate "0.00 kg". 3. -
Page 19: Device Setup
VII. Device Setup When the device is switched on, press and hold the [ZERO/TARE] key for 6 seconds, until the display shows the "SETUP”, followed by "A_OFF” (first option in setting menu). In device setup: [HOLD/BMI] select menu option [ZERO/TARE]confirm selection Auto-off: Instruct device to shut off automatically after a certain period of time. -
Page 20: Wireless Connection
[PRINT] key is pressed. VIII. Wireless Connection If the device has the wireless or bluetooth module installed, the indicator can transmit measurement results wirelessly. Please see Charder wireless or bluetooth software instructions for details. -
Page 21: Troubleshooting
Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit. - Page 22 properly as indicated in this manual Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key Broken or damaged wires causing short circuit or faulty connection ...
- Page 23 Error Messages Error Message Reason Action Low battery warning Replace batteries, or Voltage of battery is too plug in AC adapter low to operate device Overload Reduce weight on Total load exceeds measurement device's maximum platform and try again capacity Counting Error Error normally caused Signal from loadcells too...
-
Page 24: Product Specifications
X. Product Specifications A. Device Information Model MS6110 Weight Capacity 160 kg x 0.2 kg 200 kg x 0.2 kg Measurement Accuracy ± 1.5e OIML Class III LCD Screen 1.0-inch LCD screen (5 digits) Dimensions Overall 345(W) x 350(D) x 65(H) mm... -
Page 25: Power Adapter Standards
B. Power Adapter Standards Warning The device is only compatible with the power adapters specified in the dashed block below. DRAWING NO. CE APPROVED TYPE NO. TYPE Adapter plug VOLTAGE / MODEL NO. CD-AD-00041 12V 2A UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA CD-AD-00041 UES24LCP-120200SPA... - Page 26 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
- Page 27 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
-
Page 28: Declaration Of Conformity
XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
