Charder MS6111 Manual

Stand-on floor scale
Hide thumbs Also See for MS6111:
Table of Contents

Advertisement

Quick Links

Download this manual
Stand-on Floor Scale
Benutzerhandbuch
MS6111
Please keep the instruction manual at hand and follow instruction for use.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the MS6111 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Charder MS6111

Summary of Contents for Charder MS6111

  • Page 1 Stand-on Floor Scale Benutzerhandbuch MS6111 Please keep the instruction manual at hand and follow instruction for use.

  • Page 2: Table Of Contents

    CONTENTS I. Explanation of Graphic Symbols on Label/Packaging ..... 3 II. Copyright Notice ..............5 III. Safety Notes ................6 A. General Information ............6 B. EMC Guidance and Manufacturer's Declaration ...... 10 IV. Installation ................ 14 A. Assembly ................. 14 B.

  • Page 3: Explanation Of Graphic Symbols On Label/Packaging

    I. Explanation of Graphic Symbols on Label/Packaging Text/Symbol Meaning Caution, consult accompanying documents before use Separate collection for waste of electrical and electronic equipment, in accordance with Directive 2002/96/EC. Do not dispose of device with everyday waste Name and address of device manufacturer, and year/country of manufacture Carefully read user manual before installation and usage, and follow instructions for use.
  • Page 4 M: Conformity label in compliance with Directive 2014/31/EU for non-automatic weighing instruments 20: Year in which conformity verification was performed and the CE label was applied. (ex: 16=2016) 0122: Identifier for metrology Notified Body Device is a Class III scale in compliance with Directive 2014/31/EU (verified models only) Name and address of entity importing device (if applicable)

  • Page 5: Copyright Notice

    Copyright© Charder Electronic Co., Ltd. All rights reserved. This user manual is protected by international copyright law. All content is licensed, and usage is subject to written authorization from Charder Electronic Co., Ltd. (hereinafter Charder) Charder is not liable for any damage caused by a failure to adhere to requirements stated in this manual.

  • Page 6: Safety Notes

    III. Safety Notes A. General Information Thank you for choosing this Charder Medical device. It is designed to be easy and straightforward to operate, but if you encounter any problems not addressed in this manual, please contact your local Charder service partner.

  • Page 7: Safety Instructions

    - Able to read the language of instruction manual and on-screen instructions (d) Qualifications - No special certifications or qualifications required Residual Risk Evaluation (a) All foreseeable risks have been evaluated and considered acceptable. Generally speaking, the most likely risk caused by incorrect usage of the device is less accurate measurement (or inability to use device to acquire measurement), which does not pose imminent physical risk to patient or user.

  • Page 8: Maintenance

    Warranty/Liability If Charder is responsible for a fault or defect present upon receipt of  the unit, Charder shall either repair the fault, or supply a replacement unit. Should the repairs or replacement delivery fail, statutory provisions shall be valid.

  • Page 9: Incident Reporting

    Warning  Only the original adapter should be used with the device. Using an adapter other than the one provided by Charder may cause malfunction.  Do not touch the power supply with wet hands.  Do not crimp the power cable, and avoid sharp edges.

  • Page 10: Emc Guidance And Manufacturer's Declaration

    B. EMC Guidance and Manufacturer's Declaration Guidance and manufacturer’s declaration-electromagnetic emissions The product isintended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Emission test Compliance Electromagnetic...
  • Page 11 Guidance and manufacturer’s declaration-electromagnetic immunity The product is intended for use in the electromagnetic environment specified below. The customer or the user of the product should assure that it is used in such an environment. Immunity IEC 60601 Compliance level Electromagnetic test level environment-guida...
  • Page 12 Conducte 3 Vrms 3 Vrms Portable and mobile RF communications 150 KHz to 80 150 KHz to 80 d RF IEC equipment should be used no closer to 61000-4- any part of the product including cables, than the recommended separation 6 V in ISM bands 6 V in ISM distance calculated from the equation...
  • Page 13 Recommended separation distance between portable and mobile RF communications equipment and the product The product is intended for use in an electromagnetic environment in which radiated RF disturbances are controlled. The customer or the user of the product can help preventelectromagnetic interference by maintaining a minimum distance between portable and mobile RF communications equipment (transmitters) and the product as recommended below, according to the maximumoutput power of the communications equipment.

  • Page 14: Installation

    IV. Installation A. Assembly Device does not require assembly, and can be used once power is supplied. B. Inserting Batteries Insert 4 AA batteries into compartment 2. Turn on power to confirm that battery is correctly installed. C. Using Adapter 1.

  • Page 15: Indicator

    V. Indicator A. Indicator and Key Functions Key Function 1. ON/OFF(reverse):Power button. Weighing results will face patient when device is initially powered on. 2. HOLD/BMI: Press once to Hold (determine stable weighing value - used when weight is unstable). Press and hold for 3 seconds to enter Body Mass Index (BMI) calculation mode.

  • Page 16: Using Device

    VI. Using Device A. Basic Operation Switch on the device using [ON/OFF] key. The direction of the display is determined by which [ON/OFF] key pressed. (To turn off device, press and hold [ON/OFF] key for 3 seconds) The device will automatically perform self-calibration, displaying software version.

  • Page 17: Tare

    C. Tare The tare function allows the user to deduct the weight of objects from the device's measurement result. 1. Place object that needs to be tared onto measurement platform. 2. Press[ZERO/TARE] key after stable symbol appears on indicator. Display will indicate "0.00 kg". 3.

  • Page 18: Device Setup

    VII. Device Setup When the device is switched on, press and hold the [ZERO/TARE] key for 6 seconds, until the display shows the "SETUP”, followed by "A_OFF” (first option in setting menu). In device setup: [HOLD/BMI] select menu option [ZERO/TARE]confirm selection Auto-off: Instruct device to shut off automatically after a certain period of time.

  • Page 19: Wireless Connection

    (e.g. after inputting Year, press [ON/OFF] to input month). Order is YYYY.MM.DD.HH.DD (Year, Month, Day, Hour, Minute) (24 hour format). VIII. Wireless Connection If the device has the optional bluetooth module installed, the indicator can transmit measurement results wirelessly. Please see Charder wireless/bluetooth software instructions for details.

  • Page 20: Troubleshooting

    Warranty Program & Return Policy. 1. If Charder is responsible for a fault or defect present upon receipt of the unit, Charder shall either repair the fault, or supply a replacement unit.
  • Page 21  required to correct weighing accuracy Distributor support required If the following errors occur, we recommend contacting your local Charder distributor for repair or replacement services: 1. Device will not power on Faulty on/off key  Broken or damaged wires causing short circuit or faulty connection ...

  • Page 22: Product Specifications

    X. Product Specifications A. Device Information Model MS6111 Weight Capacity 0-20 kg x 0.01 kg Measurement 20-250 kg x 0.1 kg Accuracy ±1.5e Unit kg/lb LCD Screen 1.0-inch LCD screen (5 digits) Dimensions Overall 345(W) x 350(D) x 45(H) mm...

  • Page 23: Power Adapter Standards

    B. Power Adapter Standards Warning The device is only compatible with the power adapters specified in the dashed block below. DRAWING NO. CE APPROVED TYPE NO. / TYPE Adapter 12V 1A plug VOLTAGE MODEL NO. CD-AD-00044 UES12LCP-120100SPA CD-AD-00044 UES12LCP-120100SPA CD-AD-00044 UES12LCP-120100SPA CD-AD-00044 UES12LCP-120100SPA...
  • Page 24 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
  • Page 25 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
  • Page 26 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________...
  • Page 27 Notes _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _______________________________________________________ _____________________________________________________...

  • Page 28: Declaration Of Conformity

    XI. Declaration of Conformity This product has been manufactured in accordance with the harmonized European standards, following the provisions of the below stated directives: (EU) 2017/745 Regulation on Medical Devices 2014/31/EU Non-automatic Weighing Instruments Directive (OIML models only) RoHS Directive 2011/65/EU and Delegated Directive (EU) 2015/863 Radio Equipment Directive 2014/53/EU (applicable if wireless module is used)
