  • Page 2 • RIGOL products are covered by P.R.C. and foreign patents, issued and pending. • RIGOL reserves the right to modify or change parts of or all the specifications and pricing policies at the company's sole decision. • Information in this publication replaces all previously released materials.

  • Page 3: Safety Requirement

    Indicates a potentially hazardous situation or practice which, if not avoided, will result in serious injury or death. CAUTION Indicates a potentially hazardous situation or practice which, if not avoided, could result in damage to the product or loss of important data. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 4: Measurement Category

    Measurement category III is for measurements performed in the building installation. Examples are measurements on distribution boards, circuit-breakers, wiring (including cables, bus-bars, junction boxes, switches and socket-outlets) in the fixed installation, and equipment for industrial use and some other Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 5: Ventilation Requirement

    Below +65℃: ≤90% RH (without condensation) WARNING To avoid short circuit inside the instrument or electric shock, never operate the instrument in a humid environment. Altitude • Operating: below 3 km • Non-operating: below 15 km Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 6: Care And Cleaning

    For example, outdoor areas. Safety Class Class 1 – Grounded Product Care and Cleaning Care Do not store or leave the instrument where it may be exposed to direct sunlight for long periods of time. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 7: Environmental Considerations

    RoHS&WEEE certification file. Keep Hands Clear WARNING While the main screen is opening or closing, keep hands clear from the inclination angle between the main screen and its instrument body to avoid being pinched. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 8: Document Overview

    This manual gives you a quick review about the front and rear panel of DS70000 series, the user interface, and the basic operation method. http:// For the latest version of this manual, download it from the official website of RIGOL ( www.rigol.com Publication Number...
  • Page 9 Document Overview Model Max. Analog Bandwidth No. of Analog Channels DS70304 3 GHz Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 10: General Inspection

    The consigner or carrier shall be liable for the damage to the instrument resulting from shipment. RIGOL would not be responsible for free maintenance/rework or replacement of the instrument. 2. Inspect the instrument In case of any mechanical damage, missing parts, or failure in passing the electrical and mechanical tests, contact your RIGOL sales representative.

  • Page 11: Product Overview

    Product Overview Product Overview DS70000 series is RIGOL's 7th generation of the digital oscilloscope. Built on RIGOL's "Phoenix" platform, it delivers excellent performance with a maximum sample rate of 20 GSa/s, 5 GHz real-time bandwidth. In addition to the improvement of hardware specification, the DS70000 series also has many user-friendly designs to ensure high- quality user experience.

  • Page 12: Rear Panel Overview

    Figure 4.2 Rear Panel Pulse Source Input (temporally unavailable)9 10 MHz IN Reference Clock Input Pulse Source Output (temporally USB DEVICE Interface unavailable) Pulse Source Reverse Output (temporally USB HOST Interface unavailable) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 13: User Interface

    Trigger Information Label Channel Operation Label Horizontal Position Label RTSA Label Sample Rate and Memory Depth Label Multi-window Display Area Horizontal Time Base Label Notification Area Operating Status Result Display Window Waveform Display Area Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 14: To Prepare For Use

    • Restart: Click or tap the function navigation icon at the lower-left corner of the screen to open the function navigation. Click or tap the Restart icon, then a Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 15: To Set The System Language

    > Utility > Setup > Language to set the system language. To Connect the Probe RIGOL provides the passive and active probes for the DS70000 series. For specific DS70000 Data Sheet . For detailed technical information probe models, please refer to of the probes, please refer to the corresponding Probe User Guide.
  • Page 16 Connect the Active Probe Take PVA8000 (active differential probe) as an example. 1. Connect the probe head to the preamp of the active probe, as shown in the figure below. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 17 Note that you need to push the probe to the due position to lock it firmly. Figure 5.4 Connect the Active Probe Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 18: Function Inspection

    4. Set the probe ratio based on the attenuation of the probe, and then click > Auto. 5. Observe the waveform on the display. In normal condition, the square waveform as shown in the figure below should be displayed. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 19: Probe Compensation

    1. Perform Step 1, 2, 3 and 4 in Function Inspection. 2. Check the displayed waveforms and compare them with the waveforms shown in Figure 5.7 Over compensated Perfectly compensated Under compensated Figure 5.7 Probe Compensation Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 20 3. Use the probe compensation adjustment tool provided in the accessories to adjust the low-frequency compensation adjustment hole on the probe until the displayed waveform is consistent with the "Perfectly compensated" waveform shown in the above figure. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 21: Touchscreen Gestures

    Use one finger to select the object, and then drag the object to a destination place, as shown in Figure 6.2 . With the drag gesture, you can perform the following operation: Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 22 • Pinching&stretching in the horizontal direction can adjust the horizontal time base of the waveform. • Pinching&stretching in the vertical direction can adjust the vertical scale of the waveform. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 23: Rectangle Drawing

    . Move your finger away from the screen, and then a menu is displayed on the screen. At this time, you can tap to select "Horizontal zoom out", "Vertical zoom out", "Waveform zoom out", or "Reset". Figure 6.4 Rectangle Drawing Gesture (a) Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 24 Click or tap the "DrawRect" icon, if is displayed, it indicates that the waveform operation mode is enabled. By default, the waveform operation mode is enabled. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 25: To Use The Built-In Help System

    > Help to enter the help system. Figure 7.1 Help Information After opening the help interface, you can get its help information by clicking on or tapping the link for the desired item. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 26: Parameter Setting Method

    • Delete the parameter value that has been input; • Set the parameter value to a maximum or minimum value; • Set the parameter to a default value; Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.
  • Page 27 Parameter Setting Method • Clear the parameter input field. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 28: Fuse Replacement

    WARNING To avoid electric shock, please ensure that the instrument has been turned off, the power source has been cut off, and the fuse to be used conforms to the fuse rating. Copyright ©RIGOL TECHNOLOGIES CO., LTD. All rights reserved.

  • Page 29: Remote Control

    • PC Software Users can use the PC software to send commands to control the instrument remotely. RIGOL Ultra Sigma is recommended. You can download the software http://www.rigol.com from RIGOL official website ( Operation Procedures: Set up communication between the instrument and PC.

  • Page 30: More Product Information

    User Guide. For more information about this instrument, refer to the relevant manuals by logging http://www.rigol.com in to the official website of RIGOL ( ) to download them. DS70000 User Guide introduces the functions of the instrument and the •...
