ConvaTec Neria Guard Quick Start Manual

Neria Guard
TM
infusion set
Neria™Guard is an all-in-one,
automatic infusion set with an
integrated inserter and a soft
cannula. With just a few user steps
1
and a retractable inserter needle,
it has been designed to support
simplicity and home treatment.
Soft cannula Tubing
lengths lengths
6 and 9 mm 12, 30, 60,
80 and
110 cm
The Neria™Guard infusion sets are sold in
boxes containing 10 sets.
References
1. Convatec IC, data on file, D012-002912, 2023.
1
Priming
volumes
12 cm ~ 0.04 ml
30 cm - 0.06 ml
60 cm ~ 0.10 ml
80 cm ~ 0.12 ml
110 cm ~ 0.15 ml
Neria
Guard
TM
Product specifications
Cannula
Soft
Insertion angle
90 degrees
(straight in)
Disconnection Yes, at site
Introducer G27
needle gauge
Soft cannula
0.68 mm (≈ G23)
diameter
Adhesive
Built-in, non-woven
polyester, acrylic
adhesive
Hidden needle
Yes, needle not
visible before, during
and after insertion
Insertion device Yes, incorporated in
the product
